MSI MPG Z790 CARBON WIFI Gaming Desktop Motherboard - Intel Z790 Chipset - Socket LGA-1700 - ATX (z790carbwifi)
- SKU:
- 19307587
- MPN:
- z790carbwifi
- Availability:
- Usually ships the same or next business day. In stock at our GA, PA warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 04/25/2024 07:01:39 AM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
Buy 3 or above | and pay only $392.43 each 392.43 |
- Stock Update:
- 04/25/2024 07:01:39 AM PST
Description
This item is brand-new, factory sealed.
MPG Z790 CARBON WIFISupports 13th /12th Gen Intel Core / Pentium / Celeron processors for LGA 1700 socket
Supports DDR5 Memory, up to 7600+(OC) MHz
Fast Game experience: PCIe 5.0 slot, Gen 5 x4 M.2, USB 3.2 Gen 2x2
Enhanced Power Design: Direct 19+1+1 phases power, Core Boost, Memory Boost
Premium Thermal Solution: Enlarged heatsink with heat-pipe, MOSFET thermal pads rated for 7W/mk, additional choke thermal pads and M.2 Shield Frozr are built for high performance system and non-stop gaming experience
2.5G LAN and Intel Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
AUDIO BOOST 5: Reward your ears with studio grade sound quality for the most immersive gaming experience
High Quality PCB: 8-layer PCB made by server grade level material
Pre-installed I/O Shield: Better EMI protection and more convenience for installation
BE AHEAD, POP YOUR STYLE
The MPG series brings out fashionable products by showing extremely unique styles and expressing a conceited attitude towards the challenge of the gaming world. With extraordinary performance and style, the MPG series defines the future of gaming fashion. CHIPSET
INTEL Z790 CPU SUPPORT
Supports 12th/13th Gen Intel CoreTM Processors, Pentium Gold and Celeron Processors
LGA 1700 MEMORY
4x DDR5, Maximum Memory Capacity 192GB
Memory Support 7600+(OC)/ 7400 (OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
- 1DPC 1R Max speed up to 7600+ MHz
- 1DPC 2R Max speed up to 6600+ MHz
- 2DPC 1R Max speed up to 6400+ MHz
- 2DPC 2R Max speed up to 5600+ MHz
Supports Intel XMP3.0 OC
Supports Dual-Controller Dual-Channel mode
Supports non-ECC, un-buffered memory ONBOARD GRAPHICS
1x HDMITM
Support HDMITM 2.1 with HDR, maximum resolution of 4K 60HzNote
Note: Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. EXPANSION SLOT
2x PCI-E x16 slot
1x PCI-E x1 slot
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) STORAGE
5x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_2 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260 devices
6x SATA 6G
Note: PCI_E1 slot will be Gen5x8 when installing M.2 SSD in the M2_2 slot. RAID
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices
Note: SATA_A1A2 do not support RAID function. USB
4x USB 2.0 (Front)
2x USB 3.2 Gen1 Type A (Rear)
2x USB 3.2 Gen1 Type A (Front)
6x USB 3.2 Gen2 Type A (Rear)
1x USB 3.2 Gen2 Type C (Rear)
1x USB 3.2 Gen2x2 Type C (Rear)
1x USB 3.2 Gen2x2 Type C (Front) LAN
Intel 2.5Gbps LAN WIRELESS / BLUETOOTH
Intel Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz Note1 (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth 5.3Note2, FIPS, FISMA
Note1: Wi-Fi 6E 6GHz may depend on every countrys regulations and will be ready in Windows 11.
Note2: Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11. AUDIO
Realtek ALC4080 Codec
7.1-Channel USB High Performance Audio
Supports up to 32-Bit/384 kHz playback on front panel INTERNAL I/O
1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
5x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x TBT connector (JTBT, supports RTD3)
1x Tuning Controller connector(JDASH)
2x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
2x USB 3.2 Gen1 Type A ports
1x USB 3.2 Gen 2x2 Type C ports LED FEATURE
1x EZ LED Control switch
1x 2-Digit Debug Code LED
4x EZ Debug LED BACK PANEL PORTS
Clear CMOS / Flash
USB 3.2 Gen 1 5 Gbps (Type-A)
2.5G LAN
USB 3.2 Gen 2 10Gbps (Type-A)
Audio Connectors
Smart Button
HDMITM
USB 3.2 Gen 2 10Gbps (Type-A)
USB 3.2 Gen 2 10Gbps (Type-C)
USB 3.2 Gen 2x2 20Gbps (Type-C)
Wi-Fi / Bluetooth
Optical S/PDIF Out PCB DIMENSION (W x L)
ATX
243.84mmx304.8mmItem Dimension (L inchxW inchxH inch)
14 x 11 x 3
Weight
4.64 lb
Warranty Information
3 Years
Features
Package Contents:
Intel
China
- MPG Z790 CARBON WIFI Gaming Desktop Motherboard
- European Union Regulatory Notice
- Quick Installation Guide
- Wi-Fi Antenna
- 2 x SATA Cables
- Cable Stickers
- 4 x EZ M.2 Clip Packages
- USB Drive
- JARGB Extension Cable
- JARGB Extension Cable (1 to 2)
Brand Compatibility:
Intel
Country of Origin:
China
Specs
Physical Characteristics | |
Form Factor | ATX |
Product Color | Carbon Black |
Width | 12" |
Depth | 9.6" |
Warranty | |
Limited Warranty | 3 Year |
I/O Expansions | |
Number of PCI Express x1 Slots | 1 |
Number of PCI Express x16 Slots | 2 |
Number of Total Expansion Slots | 3 |
Total Number of PCI Express Slots | 3 |
Memory | |
Memory Technology | DDR5 SDRAM |
Number of Memory Slots | 4 |
Memory Speed Supported |
|
Memory Form Factor |
|
Maximum Memory Supported | 128 GB |
General Information | |
Brand Name | MSI |
Manufacturer Website Address | http://www.msi.com |
Marketing Information | MPG Z790I EDGE WIFI MPG Z790 CARBON WIFI employs carbon black color scheme and RGB lighting to show off different personality and identity. Besides being stylish, it is also powerful. BE AHEAD, POP YOUR STYLE The MPG series brings out fashionable products by showing extremely unique styles and expressing a conceited attitude towards the challenge of the gaming world. With extraordinary performance and style, the MPG series defines the future of gaming fashion. |
Product Type | Gaming Desktop Motherboard |
Product Name | MPG Z790 CARBON WIFI Gaming Desktop Motherboard |
Manufacturer | MSI |
Manufacturer Part Number | Z790CARBWIFI |
Product Model | Z790 CARBON WIFI |
Product Line | MPG |
Processor & Chipset | |
Chipset Manufacturer | Intel |
Processor Generation Supported | 13th Gen |
Processor Supported |
|
Total Processor Supported | 1 |
Processor Socket | Socket LGA-1700 |
Chipset Model | Z790 |
Onboard Interfaces | |
Number of SATA Interfaces | 6 |
Total Number of Onboard USB Ports | 7 |
Number of Onboard USB 3.2 Ports | 3 |
Number of M.2 Interfaces | 5 |
Number of Onboard USB 2.0 Ports | 4 |
Interfaces/Ports | |
Number of USB 3.2 Gen 2 Type-A Ports | 6 |
S/PDIF | Yes |
Number of USB 3.2 Ports | 2 |
HDMI | Yes |
Total Number of USB Ports | 10 |
Number of USB 3.2 Gen 1 Ports | 2 |
Number of Network (RJ-45) Ports | 1 |
I/O Controller | |
RAID Supported | Yes |
Controller Type | Serial ATA/600 |
RAID Levels |
|
Video | |
Onboard Video | CPU Dependent Video |
Network & Communication | |
Wireless LAN | Yes |
Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/ax |
Bluetooth | Yes |
2.5Gigabit Ethernet | Yes |
Audio | |
Audio Channels | 7.1 |
