Ag Neovo SC2402 24" Full HD Surveillance Monitor
(No reviews yet)
Write a Review
- SKU:
- 21082730
- MPN:
- 275483
- Availability:
- Usually ships the same or next business day. In stock at our CA warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 02/05/2026 05:11:02 PM PST
- Stock Update:
- 02/05/2026 05:11:02 PM PST
Description
This item is brand-new, factory sealed.
24-Inch 1080p Surveillance Monitor with BNC ConnectorSC-2402
Full HD 1920 x 1080 resolution Connector
Versatile connectivity: VGA, HDMI, Composite (BNC) inputs
Composite (BNC) passive loop-through output port
Quick Image settings: CCTV Mode, Gamma Selection, Black-level Adjustment, Contrast Enhancer
Designed and developed for continuous 24/7 operation
The SC-2402 24-inch surveillance monitor with BNC connector features 3-sided bezel-less specifically designed for security operators especially those with a 24/7 operating multi-screen setup who are looking for efficient video monitoring. The SC-2402 provides value-added video enhancement controls that help create detailed images for low-light footage. Its optional monitor mounting solutions support single or multiple monitor setups. In terms of cost-to-performance, this model is the solution for productivity in modern operator workstations.3-Sided Bezel Less Monitor Increase Productivity
The SC-2402 adopts a seamless 3-sided bezel-less design to create a productive work environment and reduce gaps between monitors. Perform rapid analysis, manage, and control video sources from all locations. Evolving situations require quick decisions, which seamless monitors can help with.Multiple Monitor Setups Made Easy
With VESA 100 x 100mm, the SC-2402 is compatible with AG Neovos mounting portfolio of desk and wall mounts. Whether youre looking for a dual, quad, or more monitor set-up, AG Neovo is a one-stop-shop for creating ergonomic workstations in a control room.Higher Cost Performance
Designed with long-hour monitoring in mind, you can expect a reduction in system maintenance efforts and consequentially higher cost performance. The SC-2402 is commercial grade and meant to work 24/7, 365 days a year. Static images that would otherwise cause screen burn-in are gone with AG Neovos patented Anti-Burn-in technology. Expect prolonged life for LCD screens.Panel
Panel Type
LED-Backlit TFT LCD
Size
23.8"
Max. Resolution
FHD 1920 x 1080
Pixel Pitch
0.275 mm
Brightness
250 cd/m2
Contrast Ratio
20,000,000:1 (DCR)
Viewing Angle (H/V)
178o/178o
Display Colour
16.7M
Response Time
5 ms
Surface Treatment
Anti-Glare Treatment (Haze25%),3H Hard CoatingFrequency
Frequency (H)
30 kHz-85 kHz
Frequency (V)
48 Hz-75 HzSignal Input
HDMI
1.4 x 1
VGA
15-Pin D-Sub x 1
Composite
BNC x 1Signal Output
Composite
BNC x 1Audio
Audio In
Stereo Audio Jack (3.5 mm)
Internal Speakers
2W x 2Power
Power Supply
InternalPower Requirements
AC 100-240V
50/60 Hz
On Mode
15W (On)
Standby Mode
< 0.5W
Off Mode
< 0.3WOperating Conditions
Temperature
5oC-35oC (41oF-95oF)
Humidity
20%-85% (non-condensing)Storage Conditions
Temperature
-20oC-60oC (-4oF-140oF)
Humidity
10%-90% (non-condensing)Mounting
VESA FPMPMI
Yes (100 x 100 mm)Stand
Tilt
-5o to 20oSecurity
Kensington Security Slot
YesRegulation Approval
Certifications and Compliance
CE
LVD
WEEE
RoHS
REACH
UKCA
EAC
FCC
ICES-003Accessories
Supplied
Audio Cable
Power Cord
Quick Start Guide
VGA CableOptional Accessories
Ceiling Mount (Landscape only)
CMP-01 + WMK-03
Wall Mount (Landscape only)
PMK-01
WMA-01
WMK-01
WMK-03
Desk mount (Landscape only)
DMC-01
DMC-02D
DMS-01D
ES-02Item Dimension (L"xW"xH")
24 x 19 x 5
Weight
17 lbs
Warranty Information
3 YEARS
Specs
| Physical Characteristics | |
| VESA Mount Compatible | Yes |
| Weight (Approximate) | 6.61 lb |
| Height with Stand | 16.10" |
| VESA Mount Standard | 100 x 100 |
| Depth with Stand | 8.90" |
| Height | 12.7" |
| Width with Stand | 21.30" |
| Color Family | Black |
| Width | 21.3" |
| Weight with Stand (Approximate) | 7.50 lb |
| Depth | 1.7" |
| Interfaces/Ports | |
| VGA | Yes |
| Number of HDMI Inputs | 1 |
| HDMI | Yes |
| Video | |
| Brightness | 250 Nit |
| Maximum Resolution | 1920 x 1080 |
| Dynamic Contrast Ratio | 20,000,000:1 |
| Color Supported | 16.7 Million Colors |
| General Information | |
| Brand Name | AG Neovo |
| Manufacturer Website Address | http://www.agneovo.com |
| Marketing Information | The SC-2402 24-inch surveillance monitor with BNC connector features 3-sided bezel-less specifically designed for security operators - especially those with a 24/7 operating multi-screen setup who are looking for efficient video monitoring. The SC-2402 provides value-added video enhancement controls that help create detailed images for low-light footage. Its optional monitor mounting solutions support single or multiple monitor setups. In terms of cost-to-performance, this model is the solution for productivity in modern operator workstations. 3-SIDED BEZEL LESS MONITOR INCREASE PRODUCTIVITY The SC-2402 adopts a seamless 3-sided bezel-less design to create a productive work environment and reduce gaps between monitors. Perform rapid analysis, manage, and control video sources from all locations. Evolving situations require quick decisions, which seamless monitors can help with. MULTIPLE MONITOR SETUPS MADE EASY With VESA 100 x 100mm, the SC-2402 is compatible with AG Neovo's mounting portfolio of desk and wall mounts. Whether you're looking for a dual, quad, or more monitor set-up, AG Neovo is a one-stop-shop for creating ergonomic workstations in a control room. HIGHER COST PERFORMANCE Designed with long-hour monitoring in mind, you can expect a reduction in system maintenance efforts and consequentially higher cost performance. The SC-2402 is commercial grade and meant to work 24/7, 365 days a year. Static images that would otherwise cause screen burn-in are gone with AG Neovo's patented Anti-Burn-in technology. Expect prolonged life for LCD screens. PERFECT MATCH TO CCTV IMAGES There is a special pre-configured CCTV Mode that maximises image clarity in low-light footage. Quickly fine-tune your video footage with adjustments for sharpness, saturation, contrast, brightness, and more. Don't waste time testing and re-adjusting constantly, this product already has it all figured out! ENHANCED GAMMA SELECTION Offering an enhanced gamma selection makes for amazing visual optimization. Improve the light, shadow, and colour balance quality of your videos with ease. MISSING DETAILS IN DARK SCENES IS A THING OF THE PAST More detail from black-level adjustment means improved visibility of dark images. CONTRAST ENHANCER By coming with a contrast enhancer, the surveillance monitor enables low-contrast images to become more clear and defined. ADAPTABLE TO SURVEILLANCE ENVIRONMENT NEEDS Tailor the display to your needs with on/off toggles for the blue screen. When there is no signal available, a blue screen will show that is ideally designed for dark and low-light environments. |
| Product Type | LCD Monitor |
| Product Name | 24 Inch 1080p Surveillance Monitor With BNC Connector |
| Manufacturer | AG Neovo Technology Corporation |
| Manufacturer Part Number | SC2402 |
| Product Model | SC-2402 |
| Technical Information | |
| Viewable Screen Size | 23.8" |
| Response Time | 5 ms |
| Aspect Ratio | 16:9 |
| Panel Technology | Thin Film Transistor (TFT) |
| Pixel Pitch | 0.27500 mm x 0.27500 mm |
| Vertical Viewing Angle | 178° |
| Mount Type |
|
| Horizontal Frequency | 30 kHz to 85 kHz |
| Screen Mode | Full HD |
| Number of Screens | 1 |
| Features |
|
| Vertical Frequency | 48 Hz to 75 Hz |
| Horizontal Viewing Angle | 178° |
| Backlight Technology | LED |
| Screen Size Class | 24" |
| Audio | |
| Number of Speakers | 2 |
| Speakers | Yes |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
View AllClose
Ag Neovo SC2402 24" Full HD Surveillance Monitor
$241.33
