Asrock X870TAICHICREATOR X870 ATX Motherboard

This item is brand-new, factory sealed.

• Supports AMD Ryzen 9000/8000/7000 Series Processors (AM5)
• PCIe 5.0 x8/x8 slot supports dual GPU
• Uses Ultra USB Power to provide stable 5V power to peripheral devices
• 18+2+1 phase design provides stable power
• Equipped with an aluminum heatsink for excellent heat dissipation

• Package Dimensions: 13.7 x 11.18 x 3.5 inches
• Item Weight: 0.002 ounces
• Manufacturer: ASRock

Socket: AM5
Chipset: AMD X870
Form Factor: ATX
Memory Specifications 1: 4 x DDR5 DIMM Slots.
Memory Specifications 2: Dual Channel DDR5 Memory Technology.
- 4 x DDR5 DIMM Slots
- Supports DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC)
- Maximum capacity of system memory: 256GB
- Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
Phase: 18+2+1 Power Phase, 80A SPS for VCore+SOC
GPU functionality: Integrated AMD RDNATM graphics (Actual support may vary by CPU).
- 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
- 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 30Hz*
* Only the CPU's embedded graphics can be displayed through USB4 ports.
If you want to display to a Type-C monitor, please use AM5 RyzenTM 9000, 8000 and 7000 processors with embedded graphics.
* USB4 controller(for USB4_TC1 and USB4_TC2) will run at Gen4x2 with 8000(Phoenix 2) series processors.
Graphics Output: 2 USB4 Type-C, 1 HDMI.
[PCIE] 2 PCIe 5.0 x16 (x8/x8), 1 PCIe 3.0 x16
[PCIE X1] -
OC: Yes
[SLI] -
Cross Fire:
Sound Function: Realtek ALC4082 7.1 CH HD Audio Codec Nahimic Audio
USB 2.0: 8 USB 2.0 (2 Rear, 6 Front)
?USB3.2 Gen1 (USB3.0) 5Gb/s?10 USB 3.2 Gen1 (6 Rear, 4 Front)
?USB3.2 Gen2/Thunderbolt3 10Gb/s?2 USB 3.2 Gen2 (Rear)
USB 3.2 Gen2 x 2 Type-C 20Gb/s 1 USB 3.2 Gen2 x 2 Type-C (Front)
?Thunderbolt 4 (USB4.0)?2 USB4 Type-C (Rear)
[SATA3] 4
?M.2 Slots?1 Ultra M.2 (PCIe Gen3x4), 1 Hyper M.2 (PCIe Gen4x4)
[M.2 Slot Heatsink] 2 Blazing M.2 (PCIe Gen5x4)
?M.2 Wi-Fi?-
Wireless LAN: 802.11be Wi-Fi 7+Bluetooth
LAN: 10Gbps LAN, 5Gbps LAN.
?LED?-
