Description
This item is brand-new, factory sealed.
The CS784H is a 4-port desktop KVM switch designed for those who demand a streamlined workflow and uncompromising visual quality across multiple systems. It enables fast, reliable switching between four HDMI computers with up to 4K DCI resolution, while sharing a single keyboard, monitor, mouse, audio output, and USB peripherals through one KVM console. With multiple switching methods - including pushbuttons, hotkeys, and a remote port selector - the CS784H is the perfect companion for desktop setups in offices, content creation, remote work, design, and more.
Space-Efficient Desktop Setup
The CS784H simplifies control of up to four HDMI computer systems by sharing a single keyboard, monitor, and mouse from one KVM console, delivering a clutter-free and organized desktop workspace.
Superior Visual Clarity
The KVM switch is designed to deliver exceptional visual performance, supporting 1080p@60, 4K@60, and up to 5120?1440@60.
USB Peripheral Sharing
Media and data sharing between computers is fast and effortless via plug-n-play connection (e.g. hard drive, flash drive, printer, etc) to the USB ports on the KVM switch.
Flexible Port Selection
Port switching is quick and flexible via pushbuttons, hotkeys, or the remote port selector - whichever best fits your workflow.
All Essentials Packed. No Extras Needed.
Everything you need is included - 4 HDMI cables, 2 USB 2.0 A to B cables, 1 power adapter, and 1 remote port selector (wired switch button) - for instant setup.
Applications
The CS784H enables centralized control of up to 4 HDMI computers via one keyboard, mouse, and monitor, delivering a tidy and efficient desktop workspace where multitasking is streamlined and cable clutter is minimized.
Package Contents:
Features
Additional Information:
1-99 Seconds (Default: 5 sec.)
Compatibility:
Converters
- UC3008A1
Video Converters
- VC810
- VC985
- VC986
- VC080
- VC180
- VC812
Docks and Switches
- US224
- US234
- US424
Video Splitters
- VS182B
- VS184B
- VS1804T
Video Extenders
- VE811
- VE1812
- VE801
- VE812
Video Switches
- VS481C
KVM Extenders
- CE801
- CE840
- CE820
HDMI Cables
- 2L-7D02H-1
- 2L-7D03H
- 2L-7D05H
- 2L-7D10H
- 2L-7D15H
- 2L-7D20H
KVM Cables
- 2L-7D02UH
Specs
| Power Description | |
| Input Voltage Range | 5VDC |
| Physical Characteristics | |
| Product Material |
|
| Form Factor | Desktop |
| Weight (Approximate) | 1.04 lb |
| Length | 7.96" |
| Height | 1" |
| Width | 3.2" |
| Warranty | |
| Limited Warranty | 3 Year |
| Interfaces/Ports | |
| Number of USB Ports | 8 |
| Number of HDMI Ports | 5 |
| USB | Yes |
| HDMI | Yes |
| USB 2.0 | Yes |
| USB Standard | USB 2.0 |
| Video | |
| Maximum Video Resolution | 5120 x 1440 |
| Graphic Mode |
|
| General Information | |
| Brand Name | ATEN |
| Manufacturer Website Address | http://www.aten.com/us/en/ |
| Marketing Information | The CS784H is a 4-port desktop KVM switch designed for those who demand a streamlined workflow and uncompromising visual quality across multiple systems. It enables fast, reliable switching between four HDMI computers with up to 4K DCI resolution, while sharing a single keyboard, monitor, mouse, audio output, and USB peripherals through one KVM console. With multiple switching methods - including pushbuttons, hotkeys, and a remote port selector - the CS784H is the perfect companion for desktop setups in offices, content creation, remote work, design, and more. Space-Efficient Desktop Setup The CS784H simplifies control of up to four HDMI computer systems by sharing a single keyboard, monitor, and mouse from one KVM console, delivering a clutter-free and organized desktop workspace. Superior Visual Clarity The KVM switch is designed to deliver exceptional visual performance, supporting 1080p@60, 4K@60, and up to 5120?1440@60. USB Peripheral Sharing Media and data sharing between computers is fast and effortless via plug-n-play connection (e.g. hard drive, flash drive, printer, etc) to the USB ports on the KVM switch. Flexible Port Selection Port switching is quick and flexible via pushbuttons, hotkeys, or the remote port selector - whichever best fits your workflow. All Essentials Packed. No Extras Needed. Everything you need is included - 4 HDMI cables, 2 USB 2.0 A to B cables, 1 power adapter, and 1 remote port selector (wired switch button) - for instant setup. Applications The CS784H enables centralized control of up to 4 HDMI computers via one keyboard, mouse, and monitor, delivering a tidy and efficient desktop workspace where multitasking is streamlined and cable clutter is minimized. |
| Product Type | KVM Switchbox |
| Product Name | 4-Port USB 4K HDMI KVMP Switch (Cables Included) |
| Manufacturer | ATEN Technology, Inc |
| Manufacturer Part Number | CS784H |
| Technical Information | |
| Number of Computers Supported | 4 |
| Features |
|
| Connectivity Technology | Wired |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Operating Temperature | 32°F (0°C) |
