AXIS External IP Relay - 1 Output, 1 Input (01397-001)
(No reviews yet)
Write a Review
- SKU:
- 20762460
- MPN:
- 01397-001
- Availability:
- Usually ships the same or next business day. In stock at our IL warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 03/24/2026 09:24:00 PM PST
- Stock Update:
- 03/24/2026 09:24:00 PM PST
Description
This item is brand-new, factory sealed.
Do you need an intercom to switch on lights or call a lift, but the switched devices are far away and laying cables all the way to the intercom isn't an option? Use an external IP relay, which is controlled using HTTP commands from a 2N IP intercom or access unit. The command is sent to the relay in unsecured form. You can also use the IP relay input. Connect an exit button, for example, to switch the output locally.Features
Additional Information:
2N Products:
Czech Republic
- Supported protocols: TCP/IP, HTTP, XML, Modbus
- Number of relays: 1
- Maximum voltage: 240V AC, 30V DC
- Maximum current: 12A
- Relay modes: ON/OFF or Pulsed (0.1 s up to 1 day)
- Number of inputs: 1
- Type: optically-isolated
- Voltage range: 4-26V DC (950uA @ 4V, 8.5mA @ 26V)
- Input functions: monitor, local relay control
- Country of origin: Czech Republic. Country of origin is subject to change
Compatibility:
2N Products:
- IP Style
- Access Unit 2.0
- IP Verso
- IP Force
- IP Safety
- LTE Verso
- Access Unit M
- IP Audit Kit
Country of Origin:
Czech Republic
Specs
| Power Description | |
| Minimum Operating Voltage | 9 V DC |
| Maximum Operating Voltage | 28 V DC |
| Physical Characteristics | |
| Product Material | Polycarbonate Plastic |
| Weight (Approximate) | 5.01 oz |
| Height | 3.1" |
| Width | 1.4" |
| General Information | |
| Brand Name | AXIS |
| Manufacturer Website Address | http://www.axis.com |
| Marketing Information | Do you need an intercom to switch on lights or call a lift, but the switched devices are far away and laying cables all the way to the intercom isn't an option? Use an external IP relay, which is controlled using HTTP commands from a 2N IP intercom or access unit. The command is sent to the relay in unsecured form. You can also use the IP relay input. Connect an exit button, for example, to switch the output locally. |
| Product Type | Relay |
| Product Name | External IP Relay - 1 Output, 1 Input |
| Manufacturer | Axis Communications |
| Manufacturer Part Number | 01397-001 |
| Product Information | |
| Application/Usage | Intercom System |
| Interface | RJ-45 |
| Environmental Conditions | |
| Maximum Storage Temperature | 185°F (85°C) |
| Relative Humidity | 5% - 95% |
| Maximum Operating Temperature | 134.6°F (57°C) |
| Minimum Storage Temperature | -40°F (-40°C) |
| Minimum Operating Temperature | -40°F (-40°C) |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
