Black Box Freedom II KM Switch - 8-Port - 8 Computer(s) - 1 Local User(s) - 2 x Network (KV0008AR2)
- SKU:
- 18160624
- MPN:
- kv0008a-r2
- Availability:
- Usually ships the same or next business day. In stock at our CA, IL, NJ warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 12/25/2025 03:43:34 AM PST
- Stock Update:
- 12/25/2025 03:43:34 AM PST
Description
This item is brand-new, factory sealed.
Glide-and-Switch
Glide-and-switch technology enables you to easily access information and control operations across eight computer systems and monitors by simply moving your mouse from screen to screen
The Freedom II works like an extended desktop switch. With it, you can perform functions that ordinarily would require eight separate keyboard/mouse sets. Use it to create a unified desktop system with eight computers with similar or different operating systems. You'll free up valuable desktop space, save money on equipment and simplify your work.
The Freedom II is ideal for command and control applications such as in:
- Broadcasting
- Public safety
- Industrial
- Defense
- Transportation
Not only can you switch between computer by just moving your mouse, you can also simultaneously access a mix of USB peripherals.
The Freedom II integrates with the Black Box Agility IP-based KVM system. It can interface with up to four Agility receivers that are connected over a LAN to remote servers or PCs. You can then switch the Agility targets using one keyboard and mouse.
You may also want the Freedom II LED system, a 10-port accessory that supports up to 10 LEDs. When connected to the Freed, the LEDs show where the keyboard/mouse controls are located. Each LED designates a monitor connection.
No software is needed for single-head support, so setup is simplified. Additionally the Freedom II works with all know software and operating systems. Multi-head support with Glide-and-Switch is only supported on Windows OS.
Package Contents:
- Freedom II KM Switch - 8-Port
- Power Adapter and Power Cord
- Flash Upgrade Adapter
- 4 x Self-Adhesive Feet
Features
- Freedom II KM Switch - 8-Port
- Power Adapter and Power Cord
- Flash Upgrade Adapter
- 4 x Self-Adhesive Feet
TAA Compliant:
Yes
Environmentally Friendly:
Yes
Compatibility:
Operating Systems Compatible:
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin:
United Kingdom
Specs
| Power Description | |
| Input Voltage Range | 120V AC to 230V AC |
| Input Voltage |
|
| Physical Characteristics | |
| Height | 0.2" |
| Width | 17.1" |
| Depth | 6.2" |
| Warranty | |
| Limited Warranty | 2 Year |
| Interfaces/Ports | |
| Number of USB Ports | 13 |
| Network (RJ-45) | Yes |
| USB | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Number of PS/2 Ports | 2 |
| PS/2 Port | Yes |
| General Information | |
| Brand Name | Black Box |
| Manufacturer Website Address | http://www.blackbox.com |
| Marketing Information | The Freedom II KM Switch with Glide & Switch enables a single user to easily access information and control operations across the computer systems and monitors, saving time, money, and space. The Freedom II works like an extended desktop switch on a single computer. Once you configure your screen layout for the attached PCs with up to eight external displays, switching ports is as simple as moving your mouse cursor over the screens' X and Y borders. Freedom is ideal in command and control applications, such as those in finance on a trading room floor. Not only can users switch between several computers just by moving the mouse, but they can also simultaneously access a mix of USB peripherals, including high-speed USB 2.0 devices. Additionally, the Freedom II KVM Switch integrates with the Black Box Agility IP-based KVM system. This Freedom II KM Switch can interface with Agility receivers, and then switch the Agility targets using just one keyboard and mouse. The Freedom II KM Switch is ideal for command and control applications such as in: Broadcasting Public safety Industrial Defense Transportation |
| Product Type | KM Switchbox |
| Product Name | Freedom II KM Switch - 8-Port |
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | KV0008A-R2 |
| Product Model | KV0008A-R2 |
| Product Line | Freedom II |
| Technical Information | |
| Number of Computers Supported | 8 |
| Number of Local Users Supported | 1 |
