Black Box MediaCento IPX HD Extender Transmitter - HDMI-Over-IP - 1 Input Device - 328.08 ft Rang (VXHDMIHDIPTX)
- SKU:
- 18168757
- MPN:
- vx-hdmi-hdip-tx
- Availability:
- Usually ships the same or next business day. In stock at our IL, NJ warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 12/26/2025 01:44:02 PM PST
- Stock Update:
- 12/26/2025 01:44:02 PM PST
Description
This item is brand-new, factory sealed.
MediaCento IPX HD is great for:
- Digital signage applications using the iCOMPEL Digital Signage system.
- Basic HDMI video and audio extension direct point to point, or point to multipoint over a gigabit Ethernet network.
- Streaming video to classrooms in schools.
- Corporate video sharing and training.
- Sharing video in command and control room setups.
HDMI HD video over IP
This IP-based video distribution solution uses existing standards-based Ethernet technology and TCP/IP protocols to extend HD HDMI video signals on your Gigabit Ethernet network. In a multicast configuration, one transmitter can drive multiple receivers with no extra network load.
HD means better video
The MediaCento IPX HD supports High Defenition video for great pictures up to 1080p.
Plug-and-play setup
Whether you choose to utilize existing LAN infrastructure, or setup a dedicated video network, setup is easy. For a unicast setup, simply connect your source, your display, a network switch, and you're ready go!
PoE support for remote powering
The MediaCento IPX HD is PoE powered eliminating the need for additional power supplies. Using a PoE network switch completely eliminates the need for external power supplies making installation easier.
Create 8x8 video walls
For video streaming and multicasting video over a network to a video wall, see our LPB2900 Series Gigabit PoE+ Managed Switches (LPB2910A, LPB2926A, LPB2952A).
Signals that go for miles
The MediaCento IPX HD Unicast system transmits up to 328 feet (100 m) point to point, but goes even further with a network switch added to the mix.
Optimal PC-to-screen performance
MediaCento features EDID copy function and is HDCP 2.2-compliant.
Digital signage and video wall applications:
- Hospitality
- Bars/restaurants
- Retail
- Venues/events
- Corporate multi-room solutions
Package Contents:
- MediaCento IPX HD Extender Transmitter - HDMI-Over-IP
- 1 x 5-VDC, 3-A Power Supply
- 1 x Quick Start Guide
Features
- MediaCento IPX HD Extender Transmitter - HDMI-Over-IP
- 1 x 5-VDC, 3-A Power Supply
- 1 x Quick Start Guide
TAA Compliant:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Restriction of Hazardous Substances (RoHS) 2
Country of Origin:
Taiwan
Specs
| Physical Characteristics | |
| Transmitter Weight (Approximate) | 1.04 lb |
| Transmitter Depth | 3.86" |
| Transmitter Height | 1.26" |
| Transmitter Width | 7.09" |
| Warranty | |
| Limited Warranty | 3 Year |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Number of HDMI Inputs | 1 |
| HDMI In | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Video | |
| Maximum Video Resolution | 1920 x 1080 |
| Graphics Modes | Full HD |
| General Information | |
| Brand Name | Black Box |
| Manufacturer Website Address | http://www.blackbox.com |
| Marketing Information | Scalable HD Video Distribution Over Your Existing IP Network The MediaCento IPX HD is a robust and flexible solution for distributing High Definition (1080p) HDMI video and audio over your existing, standards-based Gigabit Ethernet network using TCP/IP protocols. Its primary benefit is enabling scalable video extension in applications like digital signage, corporate training, classroom streaming, and control room video sharing. It supports both basic point-to-point and large-scale point-to-multipoint configurations, utilizing a multicast setup where one transmitter can drive many receivers without placing extra burden on the network. Simplified Setup Setup is significantly simplified by its plug-and-play nature and its PoE power support, which eliminates the need for separate external power supplies. The system ensures excellent picture quality with 1080p HD resolution, an EDID copy function for optimal PC-to-screen performance, and is HDCP 2.2 compliant. It also allows for the creation of video walls up to 8x8 displays and extends signals far beyond the standard 328 feet (100 m) point-to-point distance when network switches are introduced. |
| Product Type | Video Extender Transmitter |
| Product Name | MediaCento IPX HD Extender Transmitter - HDMI-over-IP |
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | VX-HDMI-HDIP-TX |
| Product Line | MediaCento |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Technical Information | |
| Maximum Operating Distance | 328.08 ft |
| Number of Input Devices Supported | 1 |
| Connectivity Technology | Wired |
