Blue Sea Systems
Blue Sea System 3923917 Blue Sea 7042 187 - Series Thermal Circuit Breaker - 80amp
(No reviews yet)
Write a Review
- SKU:
- 18007509
- MPN:
- 3923917
- Availability:
- Usually ships the same or next business day. In stock at our NJ warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 12/08/2025 06:24:58 PM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 | and pay only $82.09 each 82.09 |
| Buy 3 - 4 | and pay only $80.43 each 80.43 |
| Buy 5 or above | and pay only $79.10 each 79.1 |
- Stock Update:
- 12/08/2025 06:24:58 PM PST
Description
This item is brand-new, factory sealed.
187 - Series Thermal Circuit Breakers - Panel Mount80 Amp Circuit Breaker
PN: 7042
Features:
- Combines switching and circuit protection into a single device
- All components meet SAE J1171 external ignition protection requirements
- Clear, single lever operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Waterproof
- Recessed mounting holes for clean appearance
- Self-trimming case eliminates the need for mounting panels or trim bezels
- Round case permits easy installation with standard sized hole saw
- Large clearance around terminal studs accept heavy gauge wire lugs
- Robust 5/16 terminals provide high torque connections
- Large lever with vertical/horizontal orientation provides indication of trip status
- Ignition protected - safe for installation aboard gasoline powered boats
| Specifications | |
| Circuit Breaker Class: | Type III - Switchable / Manual Reset - Trip Free |
| Type: | Thermally Responsive Bi-Metal Blade |
| Case Material: | Thermoset Polyester |
| Voltage Rating: | 48 Volts DC Maximum |
| Interrupt Rating: | 5,000 Amperes @12 Volts DC |
| 3,000 Amperes @24 Volts DC | |
| 1,500 Amperes @42 Volts DC | |
| Operating Temperature Range: | -25C° to +82C° |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
