Brainboxes 1 SFP & 4 Port Gigabit Ethernet Switch SW584
- SKU:
- 20539810
- MPN:
- sw-584
- Availability:
- Usually ships the same or next business day. In stock at our IL warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 03/28/2026 06:42:36 PM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 or above | and pay only $128.05 each 128.05 |
- Stock Update:
- 03/28/2026 06:42:36 PM PST
Description
This item is brand-new, factory sealed.
SFP & Industrial Gigabit Ethernet switch.
Fast, low-cost, future-proof way to deploy long network segments. Connect to a wide variety of fibre optic and copper cable types for high-speed data connection over extended distances.
Galvanically Isolated Ethernet Ports. Automatic detection of data transmission speed: 10/100/1000 Mbps. Industrial temperature range of -40°C to +80°C (-40°F to 176°F) and dual input redundant power supply with wide voltage range means it can be powered from USB or on the 24V factory floor. Power terminal is removable with numbered pins for easy wiring. Power consumption is optimised based on the status of the link device. No software required. Ideal for factory floor, in vehicle and marine applications.
Package Contents:
- 1 SFP & 4 Port Gigabit Ethernet Switch
- Quick Start Guide
Features
- 1 SFP & 4 Port Gigabit Ethernet Switch
- Quick Start Guide
Environmentally Friendly:
Yes
Application/Usage:
Network
Industrial
Factory
Vehicle
Marine
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin:
Great Britain
Specs
| Power Description | |
| Plug/Connector Type | Terminal Block |
| Power Source |
|
| Input Voltage |
|
| Power Consumption | 3.60 W |
| Physical Characteristics | |
| Form Factor |
|
| Weight (Approximate) | 3.84 oz |
| Height | 0.9" |
| Width | 3.9" |
| Depth | 3.7" |
| Warranty | |
| Limited Warranty | Lifetime |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details |
|
| Total Number of Network Ports | 4 |
| Modular | Yes |
| I/O Expansions | |
| Total Number of Expansion Slots | 1 |
| Number of SFP Slots | 1 |
| Expansion Slot Type | SFP (mini-GBIC) |
| General Information | |
| Brand Name | Brainboxes |
| Manufacturer Website Address | http://www.brainboxes.com |
| Marketing Information | SFP & Industrial Gigabit Ethernet switch. Fast, low-cost, future-proof way to deploy long network segments. Connect to a wide variety of fibre optic and copper cable types for high-speed data connection over extended distances. Galvanically Isolated Ethernet Ports. Automatic detection of data transmission speed: 10/100/1000 Mbps. Industrial temperature range of -40°C to +80°C (-40°F to 176°F) and dual input redundant power supply with wide voltage range means it can be powered from USB or on the 24V factory floor. Power terminal is removable with numbered pins for easy wiring. Power consumption is optimised based on the status of the link device. No software required. Ideal for factory floor, in vehicle and marine applications. |
| Product Type | Ethernet Switch |
| Product Name | 1 SFP & 4 Port Gigabit Ethernet Switch |
| Manufacturer | Brainboxes Limited |
| Manufacturer Part Number | SW-584 |
| Product Model | SW-584 |
| Media & Performance | |
| Ethernet Technology | Gigabit Ethernet |
| Maximum Data Transfer Rate | 125 MB/s |
| Media Type Supported |
|
| Network Technology |
|
| Network & Communication | |
| Layer Supported | 2 |
| Technical Information | |
| Features | IP20 |
Warranty Information
