CyberPower CP685AVRG AVR UPS Systems (CP685AVRG)
(No reviews yet)
Write a Review
- SKU:
- 18055503
- MPN:
- cp685avrg
- Availability:
- Out of stock
- Stock Update:
- 01/23/2026 07:54:05 PM PST
- Stock Update:
- 01/23/2026 07:54:05 PM PST
Description
This item is brand-new, factory sealed.
The CyberPower CP685AVRG uninterruptible power supply (UPS) system provides battery backup and surge protection for -induced surges and other power events that can damage electronic equipment. This UPS, with line-interactive topology, uses simulated sine wave output to deliver enough battery backup to power connected electronics through a utility power failure. The unit has enough runtime to perform a graceful shutdown to protect against the loss of data and damage to valuable desktop computers, workstations, networking devices, and home entertainment systems.The CP685AVRG uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power. AVR is essential in areas where power fluctuations occur frequently, and it helps to extend the unit's battery life. CyberPower designed the CP685AVRG to minimize noise for a quieter work environment and run efficiently to reduce power consumption.
- Experience higher efficiency with lower energy cost
- 685 VA load capacity - work without any interruption during power outages
- Prevent critical data loss by staying powered during a blackout with up to 390 W load capacity
- Up to 2 minute runtime on full load to preserve critical data from power shortage interruptions
Package Contents:
- CP685AVRG AVR UPS Series
- User's Manual
- USB Device Cable
- PowerPanel Personal Software CD or Free Download Card
Features
Package Contents:
Energy Saving : GreenPower UPS™ Bypass Technology Energy Star Certified : Yes UPS Topology : Line Interactive Battery Quantity : 1 Battery Size : 12 V / 7 Ah Battery Type : Sealed Lead-Acid Battery Hot Swappable : No Replacement Battery Cartridge : RB1270B (for serial numbers that with "CXA") Replacement Battery Cartridge Quantity : 1 Runtime at Full Load : 2 min Runtime at Half Load : 11 min Typical Recharge Time : 8 Hours User Replaceable Battery : Yes Physical Dimensions - (WxHxD) (cm) : 27.94 x 17.27 x 8.89 (cm) Physical Dimensions - (WxHxD) (in) : 11 x 6.8 x 3.5 (in) Physical Dimensions - (WxHxD) (mm) : 279 x 173 x 89 (mm) Weight (kg) : 5.27 Weight (lb) : 11.62 Shipping Dimensions - (WxHxD) (cm) : 25.4 x 13.97 x 36.83 (cm) Shipping - Dimensions (WxHxD, in) : 10.0 x 5.5 x 14.5 (in) Shipping - Dimensions (WxHxD, mm) : 254.0 x 139.7 x 368.3 (mm) Shipping - Weight (kg) : 5.67 Shipping - Weight (lb) : 12.5 Circuit Breaker : 15 A Cord Length : 6 ft (1.8 m) Input Frequency Range : 57 Hz - 63 Hz Input Plug Type : NEMA 5-15P Input Voltage Range : 90 VAC - 140 VAC Nominal Input Voltage : 120 VAC Automatic Voltage Regulation : Single Boost On AC WaveForm : Sine Wave On Battery Frequency : 60 Hz ± 1% On Battery Voltage : 120 VAC ± 5% On Battery Waveform : Simulated Sine Wave Outlets - Battery & Surge Protected : 4 Outlets - Surge-Only Protected : 4 Outlets - Total : 8 Outlets - Widely Spaced : 4 Outlet Type COMPUTED : 8 - NEMA 5-15R Output Power Factor : 0.6 Overload Protection : Internal Circuitry Limiting Typical Transfer Time : 4 ms USB Charge Port : No VA : 685 VA Watts : 390 W Coax Protection RG6 COMPUTED : None EMI/RFI Filtration COMPUTED : Yes Surge Suppression (Joules) : 1030 J Coax Protection RG6 COMPUTED : None EMI/RFI Filtration COMPUTED : Yes Surge Suppression (Joules) : 1030 J Audible Alarms : Battery Mode HID Compliant USB Port : Yes LED Indicators : Power On Management Cable : USB Cable Serial Port : 1 Serial Software (Free Download) : PowerPanel® Personal Color : Black Form Factor : Compact Keyhole Mounting Slots : Yes Material of Construction : Plastic Operating Relative Humidity : 0 - 90 % (non-condensing) Operating Temperature : 32 - 95 °F (0 - 35 °C) Storage Temperature : 5 - 113 °F (-15 - 45 °C) Environmental : RoHS Compliant Safety : UL1778 CEG Amount : $125000 Connected Equipment Guarantee : Lifetime Extended Warranty Option : WEXT5YR-U1B Product Warranty : 3 Year Limited Warranty
Yes
Yes
Restriction of Hazardous Substances (RoHS)
China
- CP685AVRG AVR UPS Series
- User's Manual
- USB Device Cable
- PowerPanel Personal Software CD or Free Download Card
Additional Information:
Environmentally Friendly:
Yes
Energy Star:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Country of Origin:
China
Specs
| Power Description | |
| Load Capacity (Watt) | 390 W |
| Input Voltage Range | 90 V AC - 140 V AC |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Load Capacity (VA) | 685 VA |
| Waveform Type | Simulated Sine Wave |
| Physical Characteristics | |
| Form Factor | Compact |
| Weight (Approximate) | 12 lb |
| Height | 6.8" |
| Width | 11" |
| Depth | 3.5" |
| Warranty | |
| Limited Warranty | 3 Year |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Battery Information | |
| Backup/Run Time (Full Load) | 2 Minute |
| Typical Battery Recharge Time | 8 Hour |
| General Information | |
| Brand Name | CyberPower |
| Manufacturer Website Address | https://www.cyberpowersystems.com/ |
| Marketing Information | The CyberPower CP685AVRG uninterruptible power supply (UPS) system provides battery backup and surge protection for lightning-induced surges and other power events that can damage electronic equipment. This UPS, with line-interactive topology, uses simulated sine wave output to deliver battery backup to power connected electronics during a utility power failure. The unit has enough runtime to perform a graceful shutdown to protect against the loss of data and damage to valuable desktop computers, workstations, networking devices, and home entertainment systems. The CP685AVRG uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power. AVR is essential in areas where power fluctuations occur frequently, and it helps to extend the unit's battery life. CyberPower designed the CP685AVRG to minimize noise for a quieter work environment and run efficiently to reduce power consumption. With a $125,000 lifetime connected equipment guarantee and a three-year warranty, you can trust CyberPower's commitment to the quality of this battery backup with surge protection. More from the Manufacturer |
| Product Type | Line-interactive UPS |
| Product Name | CP685AVRG AVR UPS Systems |
| Manufacturer | CyberPower Systems, Inc |
| Manufacturer Part Number | CP685AVRG |
| Product Model | CP685AVRG |
| Product Series | AVR UPS |
| Packaged Quantity | 1 / Each |
| Technical Information | |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 8 x NEMA 5-15R |
| Plug/Connector Type | NEMA 5-15P |
| Application/Usage |
|
| Transfer Time | 4 ms |
