cyberpower systems

CyberPower OL1000RTXL2UN Smart App Online UPS Systems (OL1000RTXL2UN)

(No reviews yet) Write a Review
SKU:
18168667
MPN:
ol1000rtxl2un
Availability:
Usually ships the same or next business day. In stock at our CA, GA, IL, PA warehouses.
Shipping:
Calculated at Checkout
Stock Update:
12/07/2025 09:22:53 AM PST
  • Main
  • Right
  • Rear
  • Left
  • Front
  • Alternate-Image5
  • Alternate-Image4
  • Alternate-Image3
  • Alternate-Image2
  • Alternate-Image1
  • Alternate-Image6
  • Life-Style
  • Top
  • Bottom
  • Alternate-Image9
  • Alternate-Image8
  • Alternate-Image7
  • Alternate-Image11
  • Alternate-Image10
$1,188.95
Buy more, get it as low as $
Stock Update:
12/07/2025 09:22:53 AM PST

Description



This item is brand-new, factory sealed.

CyberPower OL1000RTXL2UN Smart App Online UPS System, 1000VA/900W, 8 Outlets, 2U Rack/Tower + Pre-Installed SNMP Card
  • 1000VA/900W double conversion online battery backup Uninterruptible power supply (ups) system - designed to safeguard mission-critical servers, storage appliances, network devices and telecom installations with isolated power protection. A factory installed Rmcard205 allows remote management and configuration
  • 8 outlets: 8 NEMA 5-15R battery backup and surge protected outlets - input: 120VAC 15a, plug Type NEMA 5-15P 10 ft. cord
  • EBM OPTION: Optional Extended Battery Modules, BP36V60ART2U can be added for expanded runtimes. EXTENDABLE MULTIFUNCTION LCD PANEL: Displays UPS statuses and customizable operating settings up to 10 away
  • Fast charge technology: allows ups batteries to return to 100% capacity more rapidly by utilizing a built-in charger Inside each extended battery Module (EBM). restores a complete charge within 5 hours regardless of the number of EBMs
  • 3-Year including the batteries, $400, 000 connected equipment and free power panel business edition management software (download)
  • Product Dimensions: 16.9 x 17 x 3.5 inches
  • Item Weight: 53.5 pounds
Style:1000VA Net

Prevent business interruptions and safeguard mission-critical enterprise network equipment. The CyberPower OL1000RTXL2UN is a rack/tower UPS with double conversion topology. It provides sine wave output to critical applications and equipment that require seamless power correction. The Extended Battery Module (EBM) expands runtime, and Fast Charge Technology restores full backup power faster. This model comes with an extendable LCD control panel, Smart Battery Management charging technology, and energy-saving GreenPower UPS ECO Mode. The OL1000RTXL2UN offers generator compatibility and delivers clean AC power with zero transfer time. A factory installed RM card allows remote management and configuration of the UPS via a standard web browser, command line interface (CLI), or network management system (NMS). Its sine wave output keeps sensitive equipment working by preventing unnecessary shutdowns that can occur with simulated sine wave output. With a $400,000 lifetime connected equipment guarantee and a three-year warranty, you can trust CyberPowers commitment to high quality. .



Package Contents:
  • Smart App Online OL1000RTXL2UN 1000VA Rack/Tower UPSUser Manual
  • Registration Card
  • 2 x Rackmount Rails
  • 2 x Rackmount Ears
  • 2 x Hanging Brackets
  • Phone Line
  • Usb Communication Cable
  • Serial Interface Cable (RS-232)
  • 8 x M5x7l Black Flat Head Screws
  • 12 x M5x12l Black Pan Head Screws
  • 6 x M5x6l Silver Pan Head Screws
  • 8 x Plastic Washers
  • 12 x Screw Hole Dust Covers
  • 12 x Rubber Pads
  • And A Software Download Card

Features

Package Contents:
  • Smart App Online OL1000RTXL2UN 1000VA Rack/Tower UPSUser Manual
  • Registration Card
  • 2 x Rackmount Rails
  • 2 x Rackmount Ears
  • 2 x Hanging Brackets
  • Phone Line
  • Usb Communication Cable
  • Serial Interface Cable (RS-232)
  • 8 x M5x7l Black Flat Head Screws
  • 12 x M5x12l Black Pan Head Screws
  • 6 x M5x6l Silver Pan Head Screws
  • 8 x Plastic Washers
  • 12 x Screw Hole Dust Covers
  • 12 x Rubber Pads
  • And A Software Download Card



Certifications & Standards:
UL 1778



Additional Information:
  • Replacement Battery Cartridge Quantity: 1
  • Smart Battery Management (SBM) Mode: Yes
  • Circuit Breaker: 15A
  • Cold Start: Yes
  • Input Power Factor: 0.99
  • Input Voltage Range: 60 VAC - 69 VAC for 0-60% Load
  • Crest Factor: 3:1
  • ECO Mode Voltage Regulation: ±10%, ±15% (Configurable)
  • Harmonic Distortion: < 3% at Linear Load
  • On Battery Frequency: 50/60 Hz ± 0.25Hz (auto-sensing or configurable)
  • Output Power Factor: 0.9
  • Overload Protection: Line Mode: 105% ~ 125% Load - 1 min
  • Short Circuit Protection: UPS Output Cut Off Immediately or Input Fuse / Circuit Breaker Protection
  • Phone / Network Protection RJ11/RJ45: 1-In / 1-Out (Combo)
  • Dry Contacts: Yes
  • Expansion Slot: Yes - RMCARD205 pre-installed
  • LCD: Multifunction LCD
  • Management Cable: USB Cable
  • Removable LCD Control Panel Option: Yes - Requires DB26 cable (not included)
  • Rotatable LCD Control Panel Option: Yes
  • Serial Port: 1 Serial
  • Upgradeable firmware: Yes
  • Material of Construction: Metal
  • Mounting Hardware: Yes
  • ECO Mode Thermal Dissipation: 108 BTU/hr
  • Operating Relative Humidity: 0 - 90 % (non-condensing)
  • Operating Temperature: 32 - 104 °F (0 - 40 °C)



Environmentally Friendly:
Yes



Software Included:
PowerPanel® Business



Energy Star:
Yes



Environmental Compliance:
Restriction of Hazardous Substances (RoHS)



Country of Origin:
Taiwan



Specs

Power Description
Load Capacity (Watt)900 W
Input Frequency
  • 40 Hz
  • 70 Hz
Output Power Factor0.9
Surge Energy Rating1780 J
Input Power Factor0.99
Input Voltage Range
  • 60 V AC - 69 V AC
  • 100 V AC - 125 V AC
Input Voltage
  • 120 V AC
  • 230 V AC
Output Voltage
  • 125 V AC
  • 100 V AC
  • 110 V AC
  • 115 V AC
  • 120 V AC
Load Capacity (VA)1000 VA
Waveform TypeSine Wave
Output Frequency
  • 50 Hz
  • 60 Hz
Physical Characteristics
Form FactorRack/Tower
Weight (Approximate)39.60 lb
Product ColorBlack
Height3.5"
Color FamilyBlack
Width17"
Rack Height2U
Depth16.9"
Warranty
Directly Connected Equipment Guarantee$400000 Lifetime
Limited Warranty3 Year
Controls/Indicators
Status Indicators<p><b>LED Indicators:</b></p> <ul> <li>Power On (White)</li> <li>Line Mode (Green)</li> <li>Battery Mode (Yellow)</li> <li>Bypass Mode (Yellow)</li> <li>Fault (Red)</li> <li>Replace Battery (Red)</li> </ul>
Battery Information
Backup/Run Time (Full Load)8 Minute
Number of Batteries3
Battery Capacity9000 mAh
Replaceable BatteryYes
Battery ChemistryLead Acid
Battery Size12V
Backup/Run Time (Half Load)21 Minute
Typical Battery Recharge Time4 Hour
Battery CharacteristicsSealed
Display & Graphics
DisplayLCD
General Information
Brand NameCyberPower
Manufacturer Website Addresshttps://www.cyberpowersystems.com/
Marketing InformationPrevent business interruptions and safeguard mission-critical enterprise network equipment.
The CyberPower OL1000RTXL2UN is a rack/tower UPS with double conversion topology. It provides sine wave output to critical applications and equipment that require seamless power correction. The Extended Battery Module (EBM) expands runtime, and Fast Charge Technology restores full backup power faster. This model comes with an extendable LCD control panel, Smart Battery Management charging technology, and energy-saving GreenPower UPS™ ECO Mode.
The OL1000RTXL2UN offers generator compatibility and delivers clean AC power with zero transfer time. A factory installed RM card allows remote management and configuration of the UPS via a standard web browser, command line interface (CLI), or network management system (NMS). Its sine wave output keeps sensitive equipment working by preventing unnecessary shutdowns that can occur with simulated sine wave output.
With a $400,000 lifetime connected equipment guarantee and a three-year warranty, you can trust CyberPower's commitment to high quality.
More from the Manufacturer
Product TypeDouble Conversion Online UPS
Product NameOL1000RTXL2UN Smart App Online UPS Systems
ManufacturerCyberPower Systems, Inc
Manufacturer Part NumberOL1000RTXL2UN
Product ModelOL1000RTXL2UN
Product SeriesSmart App Online UPS
Technical Information
Receptacle TypeNEMA 5-15R
Receptacle Detail8 x NEMA 5-15R
EMI/RFI Noise FilterYes
Transfer Time0 ns
Crest Factor3:1
Energy SavingECO Mode Efficiency >94%
Overload ProtectionYes
Plug/Connector TypeNEMA 5-15P
Cord Length10 ft
Circuit Breaker Current Rating15 A
Dataline Protection
  • RJ-11
  • RJ-45
Protection TypeShort Circuit
Application/Usage
  • Mission Critical Equipment
  • Generator
Management
Network Management
  • Dry Contact
  • Relay Card
  • SNMP Manageable
Alarm
  • Battery Mode
  • Low Battery
  • Overload
  • UPS Fault
Interfaces/Ports
Network (RJ-45)Yes
USBYes
EPO PortYes
Serial PortYes
USB (HID Compliant) PortYes
Environmental Conditions
Operating Humidity0% - 90%
Thermal Dissipation80.30 W
Storage Relative Humidity0% - 95%
Maximum Storage Elevation50000 ft
Sound Emission (A-Weighted)55 dB(A)
Maximum Operating Temperature104&deg;F (40&deg;C)
Storage Temperature-4&deg;F (-20&deg;C) - 113&deg;F (45&deg;C)
Maximum Operating Elevation10000 ft
