cyberpower systems
Cyberpower Basic Pdu30bt8f8r 16-outlets Pdu - 16 X Nema 5-20r - 1u Rack-mountable, Zero U Vertical Rackmount
(No reviews yet)
Write a Review
- SKU:
- 18135935
- MPN:
- pdu30bt8f8r
- Availability:
- Usually ships the same or next business day. In stock at our CA, NJ warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 03/17/2026 03:41:13 AM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 4 or above | and pay only $239.48 each 239.48 |
- Stock Update:
- 03/17/2026 03:41:13 AM PST
Description
This item is brand-new, factory sealed.
The CyberPower 16-outlet (8 Front/8 Rear) rack mount basic power distribution unit (PDU30BT8F8R) provides 120V 30A output. It distributes power to 16 NEMA 5-20R receptacles from a single NEMA L5-30P twist lock plug, with unfiltered electrical pass-through. Designed for datacenters and other electrically demanding applications, this unit has a rugged, industrial-grade metal housing and a 12-foot AC power cord. It can be mounted either horizontally or vertically, includes a cord retention tray and is ETL/RoHS certified. A lifetime warranty ensures that this PDU is free of defects in design, assembly, material or workmanship.
Package Contents:
- Basic PDU30BT8F8R 16-Outlets PDU
- Cord Retention Tray
Features
Package Contents:
Physical Dimensions - (WxHxD) (cm) : 44.45 x 4.45 x 5.72 (cm) Physical Dimensions - (WxHxD) (in) : 17.5 x 1.75 x 2.25 (in) Physical Dimensions - (WxHxD) (mm) : 445 x 44 x 57 (mm) Weight (kg) : 2.72 Weight (lb) : 6 Shipping Dimensions - (WxHxD) (cm) : 22.63 x 6.68 x 50.8 (cm) Shipping - Dimensions (WxHxD, in) : 8.91 x 2.63 x 20.0 (in) Shipping - Dimensions (WxHxD, mm) : 226.31 x 66.8 x 508.0 (mm) Shipping - Weight (kg) : 9.47 Shipping - Weight (lb) : 20.88 Cord Length : 12 ft (3.7 m) Derated Input Current : 24 A Input Frequency Range : 50 Hz - 60 Hz Input Plug Type : NEMA L5-30P Maximum Input Current : 30A Nominal Input Voltage : 100 - 125 VAC Phase : Single Phase Plug Style : Straight (Twist Lock) Nominal Output Voltage : 100 - 125 VAC Outlets - Front : 8 Outlets - # of Banks : 1 Outlets - Rear : 8 Outlets - Total : 16 Outlet Type COMPUTED : 16 - NEMA 5-20R Overload Protection : 20A x 2 USB Charge Port : No Adjustable Mounting Brackets : 2 sets (L-Short, L-Long) Color : Black Cord Retention Tray/Cord Organizers : Yes External Site Ground Pin : Yes Form Factors Supported : Horizontal or Vertical Wallmount Material of Construction : Metal Rack Height : 1U Operating Elevation : 0 - 10000 ft (0 - 3048 m) Operating Relative Humidity : 0 - 95 % (non-condensing) Operating Temperature : 32 - 95 °F (0 - 35 °C) Storage Elevation : 0 - 50000 ft (0 - 15239 m) Storage Temperature : 5 - 113 °F (-15 - 45 °C) Environmental : RoHS Compliant Safety : UL62368 Product Warranty : Limited Lifetime Warranty
Yes
No
Restriction of Hazardous Substances (RoHS)
- Basic PDU30BT8F8R 16-Outlets PDU
- Cord Retention Tray
- User Manual
- Screw Kit
- Cord Clip Kit
- Horizontal Mounting Brackets
- Vertical Mounting Brackets
- Product Registration Card
Certifications & Standards:
- UL60950_1 certified by ETL
- CSA C22.2
Additional Information:
Environmentally Friendly:
Yes
Energy Star:
No
Application/Usage:
Network Device
Server
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Specs
| Power Description | |
| Input Frequency | 60 Hz |
| Input Voltage Range | 100 V AC - 125 V AC |
| Input Voltage | 120 V AC |
| Output Voltage |
|
| Output Voltage Range | 100 V AC - 125 V AC |
| Input Current | 30 A |
| Physical Characteristics | |
| Form Factor | Horizontal/Vertical |
| Weight (Approximate) | 6 lb |
| Cord Length | 12 ft |
| Product Color | Black |
| Mount Type |
|
| Height | 1.8" |
| Color Family | Black |
| Mounting Orientation | Horizontal |
| Width | 17.5" |
| Rack Height | 1U |
| Depth | 2.3" |
| Warranty | |
| Limited Warranty | Lifetime |
| General Information | |
| Brand Name | CyberPower |
| Manufacturer Website Address | https://www.cyberpowersystems.com/ |
| Marketing Information | The CyberPower PDU30BT8F8R, a 16-outlet (8 front, 8 rear) rackmount basic power distribution unit (PDU), provides 100-125V 30A output. It distributes power to 16 NEMA 5-20R receptacles from a single NEMA L5-30P twist lock plug with unfiltered electrical pass-through. Designed for datacenters and other electrically demanding applications, the PDU30BT8F8R has rugged, industrial-grade metal housing and a 12-foot AC power cord. It can be mounted either horizontally or vertically, includes a cord retention tray, and is ETL/RoHS certified. A limited lifetime warranty covers defects in materials and workmanship in the product under normal use and conditions. |
| Product Type | PDU |
| Product Name | PDU30BT8F8R Single Phase 100 - 125 VAC 30A Basic |
| Manufacturer | CyberPower Systems, Inc |
| Manufacturer Part Number | PDU30BT8F8R |
| Product Model | PDU30BT8F8R |
| Product Series | Basic PDU |
| Technical Information | |
| Receptacle Type | NEMA 5-20R |
| Receptacle Detail | 16 x NEMA 5-20R |
| Phase | Single Phase |
| Plug/Connector Type | NEMA L5-30P |
| PDU Type | Basic |
| Locking Receptacles | Cord Retention Tray |
| Protection Type | Overload Protection |
| Environmental Conditions | |
| Maximum Storage Temperature | 113°F (45°C) |
| Maximum Operating Temperature | 95°F (35°C) |
| Minimum Storage Temperature | 5°F (-15°C) |
| Minimum Operating Temperature | 32°F (0°C) |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
