cyberpower systems
Cyberpower Or1000pfcrt2u Pfc Sinewave 1000va Rack-mountable Ups - 1000 Va/700 W - 120 V Ac - 6.60 Minute - Rack-mountable - 6.60 Minute - 8 X Nema 5-15r - Overload (or1000pfcrt2u)
(No reviews yet)
Write a Review
- SKU:
- 18167841
- MPN:
- or1000pfcrt2u
- Availability:
- Usually ships the same or next business day. In stock at our CA, GA, PA warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 12/11/2025 05:09:00 AM PST
- Stock Update:
- 12/11/2025 05:09:00 AM PST
Description
This item is brand-new, factory sealed.
The CyberPower OR1000PFCRT2U PFC Sinewave UPS System with sine wave output and multifunction LCD safeguards networking hardware, networked-based devices, small office servers, workstations and telecom equipment that use conventional and Active Power Factor Correction (PFC) power supplies.The OR1000PFCRT2U uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently.
This UPS is ENERGY STAR® qualified with patented GreenPower UPS™ Bypass circuitry to save on energy costs by reducing energy consumption and heat buildup.
A Three-Year Warranty ensures that this UPS has passed our highest quality standards in design, assembly, material or workmanship and further protection is offered by a $300,000 Connected Equipment Guarantee.
Package Contents:
- OR1000PFCRT2U PFC Sinewave 1000VA Rack-mountable UPS
- USB A-B Cable
- User's Manual
- Software Download Card
- Registration Info Card
Features
Package Contents:
Energy Saving : GreenPower UPS™ Bypass Technology UPS Topology : Line Interactive Battery Quantity : 2 Battery Size : 12 V / 9 Ah Battery Type : Sealed Lead-Acid Battery Battery Voltage : 24 VDC Hot Swappable : Yes Replacement Battery Cartridge : RB1290X2C Replacement Battery Cartridge Quantity : 1 Runtime at Full Load : 6.6 min Runtime at Half Load : 17.9 min Typical Recharge Time : 10 Hours User Replaceable Battery : Yes Physical Dimensions - (WxHxD) (cm) : 43.21 x 8.89 x 38.91 (cm) Physical Dimensions - (WxHxD) (in) : 17.01 x 3.5 x 15.32 (in) Physical Dimensions - (WxHxD) (mm) : 432 x 89 x 389 (mm) Weight (kg) : 16.96 Weight (lb) : 37.4 Shipping Dimensions - (WxHxD) (cm) : 52.07 x 29.21 x 53.98 (cm) Shipping - Dimensions (WxHxD, in) : 20.5 x 11.5 x 21.25 (in) Shipping - Dimensions (WxHxD, mm) : 520.7 x 292.1 x 539.75 (mm) Shipping - Weight (kg) : 20.5 Shipping - Weight (lb) : 45.2 Adjustable Voltage Range : 86 - 142 VAC Circuit Breaker : 15 A Cord Length : 10 ft (3.0 m) Input Frequency Range : 57 Hz - 63 Hz Input Plug Type : NEMA 5-15P Input Voltage Range : 88 VAC - 139 VAC Nominal Input Voltage : 120 VAC Plug Style : Right Angle - 45° Offset Automatic Voltage Regulation : Single Boost On AC WaveForm : Sine Wave On Battery Frequency : 60 Hz ± 1% On Battery Voltage : 120 VAC ± 5% On Battery Waveform : Sine Wave Outlets - Battery & Surge Protected : 8 Outlets - Total : 8 Outlet Type COMPUTED : 8 - NEMA 5-15R Output Power Factor : 0.7 Overload Protection : Internal Circuitry Limiting Typical Transfer Time : 4 ms Under/Over-Voltage Correction : +14% USB Charge Port : No VA : 1000 VA Watts : 700 W EMI/RFI Filtration COMPUTED : Yes Phone / Network Protection RJ11/RJ45 : 1-In / 1-Out (Combo) Surge Suppression (Joules) : 1470 J EMI/RFI Filtration COMPUTED : Yes Phone / Network Protection RJ11/RJ45 : 1-In / 1-Out (Combo) Surge Suppression (Joules) : 1470 J Audible Alarms : Battery Mode Emergency Power Off (EPO) Port : Yes HID Compliant USB Port : Yes LCD : Multifunction LCD LED Indicators : Power On Management Cable : USB Cable Remote Management Card : None Serial Port : 1 Serial Software (Free Download) : PowerPanel® Business Color : Black Form Factor : Rack / Tower Material of Construction : Metal Rack Height : 2U Audible noise at 1.5M from surface of unit : 48.5 dBA On Battery Thermal Dissipation : 447.6 BTU/hr Online Thermal Dissipation : 70.3 BTU/hr Operating Elevation : 0 - 10000 ft (0 - 3048 m) Operating Relative Humidity : 0 - 90 % (non-condensing) Operating Temperature : 32 - 104 °F (0 - 40 °C) Storage Elevation : 0 - 50000 ft (0 - 15239 m) Storage Relative Humidity : 0 - 95% (non-condensing) Storage Temperature : 5 - 113 °F (-15 - 45 °C) Environmental : RoHS Compliant Safety : UL1778 5th Ed. CEG Amount : $300000 Connected Equipment Guarantee : Lifetime Extended Warranty Option : WEXT5YR-U2A Product Warranty : 3 Year Limited Warranty
Yes
PowerPanel Business Edition
No
Restriction of Hazardous Substances (RoHS)
China
- OR1000PFCRT2U PFC Sinewave 1000VA Rack-mountable UPS
- USB A-B Cable
- User's Manual
- Software Download Card
- Registration Info Card
Certifications & Standards:
- cUL
- UL 1778 5th Ed
- FCC Class A
Additional Information:
Environmentally Friendly:
Yes
Software Included:
PowerPanel Business Edition
Energy Star:
No
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Country of Origin:
China
Specs
| Power Description | |
| Load Capacity (Watt) | 700 W |
| Surge Energy Rating | 1470 J |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Load Capacity (VA) | 1000 VA |
| Waveform Type | Sine Wave |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Weight (Approximate) | 37.40 lb |
| Height | 3.5" |
| Width | 17" |
| Depth | 15.3" |
| Warranty | |
| Limited Warranty | 3 Year |
| Controls/Indicators | |
| Status Indicators | <ul> <li>Power On</li> <li>Wiring Fault</li> </ul> |
| Interfaces/Ports | |
| Modem (RJ-11) | Yes |
| Network (RJ-45) | Yes |
| USB | Yes |
| Serial Port | Yes |
| Battery Information | |
| Backup/Run Time (Full Load) | 6.60 Minute |
| Number of Batteries | 2 |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Half Load) | 17.90 Minute |
| Typical Battery Recharge Time | 10 Hour |
| General Information | |
| Brand Name | CyberPower |
| Manufacturer Website Address | https://www.cyberpowersystems.com/ |
| Marketing Information | A a rack/tower UPS with line interactive topology, the CyberPower PFC Sinewave OR1000PFCRT2U provides power protection (using sine wave output) and surge protection for department servers, workgroup servers, network devices and telecom equipment requiring Active PFC power source compatibility. The OR1000PFCRT2U uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The OR1000PFCRT2U comes with a three-year warranty and a $300,000 Connected Equipment Guarantee. More from the Manufacturer |
| Product Type | Line-interactive UPS |
| Product Name | OR1000PFCRT2U PFC Sinewave UPS Systems |
| Manufacturer | CyberPower Systems, Inc |
| Manufacturer Part Number | OR1000PFCRT2U |
| Product Model | OR1000PFCRT2U |
| Product Series | PFC Sinewave UPS |
| Technical Information | |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 8 x NEMA 5-15R |
| Overload Protection | Yes |
| Plug/Connector Type | NEMA 5-15P |
| Dataline Protection |
|
| EMI/RFI Noise Filter | Yes |
| Management | |
| Alarm |
|
