cyberpower systems
CyberPower OR2200LCDRTXL2U Smart App LCD UPS Systems (OR2200LCDRTXL2U)
(No reviews yet)
Write a Review
- SKU:
- 18135890
- MPN:
- or2200lcdrtxl2u
- Availability:
- Usually ships the same or next business day. In stock at our CA, GA, IL, PA warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 01/15/2026 09:09:09 AM PST
- Stock Update:
- 01/15/2026 09:09:09 AM PST
Description
This item is brand-new, factory sealed.
CyberPower Smart App Intelligent LCD OR2200LCDRTXL2U 2190 VA Tower/Rack-mountable UPS safeguards inter-networking hardware, telecom equipment, workstations and home entertainment systems that do not have active PFC power supplies. Its full automatic voltage regulation (AVR) boost/buck topology delivers a consistent and clean AC power, protecting connected equipment and preventing costly business interruptions.
Package Contents:
- Smart App Intelligent LCD OR2200LCDRTXL2U 2190 VA Tower/Rack-mountable UPS
- PowerPanel Business Edition CD-ROM
Features
Package Contents:
Energy Saving : GreenPower UPS™ Bypass Technology UPS Topology : Line Interactive Battery Quantity : 4 Battery Size : 12 V / 9 Ah Battery Type : Sealed Lead-Acid Battery Extended Battery Module : BP48VP2U02 Hot Swappable : Yes Replacement Battery Cartridge : RB1290X4B Replacement Battery Cartridge Quantity : 1 Runtime at Full Load : 6 min Runtime at Half Load : 15 min Typical Recharge Time : 8 Hours User Replaceable Battery : Yes Physical Dimensions - (WxHxD) (cm) : 43.18 x 8.89 x 47.75 (cm) Physical Dimensions - (WxHxD) (in) : 17 x 3.5 x 18.8 (in) Physical Dimensions - (WxHxD) (mm) : 432 x 89 x 478 (mm) Weight (kg) : 40.82 Weight (lb) : 90 Shipping Dimensions - (WxHxD) (cm) : 55.25 x 26.67 x 60.96 (cm) Shipping - Dimensions (WxHxD, in) : 21.75 x 10.5 x 24.0 (in) Shipping - Dimensions (WxHxD, mm) : 552.45 x 266.7 x 609.6 (mm) Shipping - Weight (kg) : 40.82 Shipping - Weight (lb) : 90 Circuit Breaker : 20 A Cord Length : 10 ft (3.0 m) Input Frequency Range : 47 Hz - 63 Hz Input Plug Type : NEMA 5-20P Nominal Input Voltage : 120 VAC Plug Style : Straight Automatic Voltage Regulation : Single Boost On AC WaveForm : Sine Wave On Battery Frequency : 60 Hz ± 1% On Battery Voltage : 120 VAC ± 5% On Battery Waveform : Simulated Sine Wave Outlets - Battery & Surge Protected : 8 Outlets - Total : 8 Outlet Type COMPUTED : 8 - NEMA 5-20R Output Power Factor : 0.8 Overload Protection : Internal Circuitry Limiting Typical Transfer Time : 4 ms USB Charge Port : No VA : 2100 VA Watts : 1650 W Coax Protection RG6 COMPUTED : 1 in EMI/RFI Filtration COMPUTED : Yes Network Protection RJ45 : 1-in / 1-Out (10/100/1000) Surge Suppression (Joules) : 2060 J Coax Protection RG6 COMPUTED : 1 in EMI/RFI Filtration COMPUTED : Yes Network Protection RJ45 : 1-in / 1-Out (10/100/1000) Surge Suppression (Joules) : 2060 J Audible Alarms : Battery Mode HID Compliant USB Port : Yes LCD : Multifunction LCD LED Indicators : Power On Management Cable : USB Cable Serial Port : 1 Serial SNMP / HTTP Remote Monitoring : Yes - with optional RMCARD205 Software (Free Download) : PowerPanel® Business Color : Black Form Factor : Rack / Tower Material of Construction : Metal Rack Height : 2U Operating Relative Humidity : 0 - 90 % (non-condensing) Operating Temperature : 32 - 104 °F (0 - 40 °C) Storage Temperature : 5 - 113 °F (-15 - 45 °C) Environmental : RoHS Compliant Safety : UL1778 CEG Amount : $300000 Connected Equipment Guarantee : Lifetime Extended Warranty Option : WEXT5YR-U4B Product Warranty : 3 Year Limited Warranty
Yes
PowerPanel Business Edition Software
No
Restriction of Hazardous Substances (RoHS)
Philippines
- Smart App LCD OR2200LCDRTXL2U 2190 VA Tower/Rack-mountable UPS
- User's manual
- Rackmount brackets
- Stands, Telephone cable
- Emergency Power Off cable
- USB A+B type cable
Certifications & Standards:
- UL1778
- CSA C22.2 No 107.3
- FCC/DoC Class B
Additional Information:
Environmentally Friendly:
Yes
Software Included:
PowerPanel Business Edition Software
Energy Star:
No
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Country of Origin:
Philippines
Specs
| Power Description | |
| Input Frequency | 63 Hz |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Load Capacity (VA) | 2190 VA |
| Waveform Type | Simulated Sine Wave |
| Output Frequency | 60 Hz |
| Physical Characteristics | |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 90 lb |
| Product Color | Black |
| Height | 3.5" |
| Color Family | Black |
| Width | 17" |
| Rack Height | 2U |
| Depth | 18.8" |
| Warranty | |
| Directly Connected Equipment Guarantee | $300000 Lifetime |
| Limited Warranty | 3 Year |
| Controls/Indicators | |
| Status Indicators | <ul> <li>Power On</li> <li>Wiring Fault</li> </ul> |
| Interfaces/Ports | |
| EPO Port | Yes |
| Serial Port | Yes |
| USB (HID Compliant) Port | Yes |
| Battery Information | |
| Backup/Run Time (Full Load) | 6 Minute |
| Number of Batteries | 4 |
| Battery Capacity | 9000 mAh |
| Replaceable Battery | Yes |
| Battery Chemistry | Lead Acid |
| Battery Size | 12V |
| Backup/Run Time (Half Load) | 15 Minute |
| Typical Battery Recharge Time | 8 Hour |
| Battery Characteristics | Maintenance-free |
| General Information | |
| Brand Name | CyberPower |
| Manufacturer Website Address | https://www.cyberpowersystems.com/ |
| Marketing Information | A rack/tower convertible UPS with line interactive topology, the CyberPower Smart LCD OR2200LCDRTXL2U provides battery backup (using simulated sine wave output) and surge protection for department servers, workgroup servers, workstations, network devices, and telecom installations without active PFC power supplies. The OR2200LCDRTXL2U uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. This model accepts the RMCARD205 network management card for remote management and control via a standard web browser or network management system. The OR2200LCDRTXL2U comes with a three-year warranty and a $300,000 Connected Equipment Guarantee. More from the Manufacturer |
| Product Type | Line-interactive UPS |
| Product Name | OR2200LCDRTXL2U Smart App LCD UPS Systems |
| Manufacturer | CyberPower Systems, Inc |
| Manufacturer Part Number | OR2200LCDRTXL2U |
| Product Model | OR2200LCDRTXL2U |
| Product Series | Smart App LCD UPS |
| Technical Information | |
| Receptacle Type | NEMA 5-20R |
| Receptacle Detail | 8 x NEMA 5-20R |
| Energy Saving | GreenPower UPS™ Bypass Technology |
| Overload Protection | Yes |
| Plug/Connector Type | NEMA 5-20P |
| Dataline Protection |
|
| Application/Usage |
|
| Number of Battery & Surge Outlets | 8 |
| Transfer Time | 4 ms |
| AVR | Yes |
| Management | |
| Network Management | SNMP Manageable |
| Alarm |
|
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
