CyberPower PDU31003 100 - 120 VAC 30A Monitored PDU (PDU31003)

(No reviews yet) Write a Review
SKU:
18159004
MPN:
pdu31003
Availability:
Usually ships the same or next business day. In stock at our CA warehouse.
Shipping:
Calculated at Checkout
Stock Update:
02/04/2026 04:44:14 PM PST
  • Main
  • Right
  • Left
  • Alternate-Image2
  • Alternate-Image1
$744.39
Buy more, get it as low as $

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

Buy 2 or above and pay only $728.31 each 728.31
Stock Update:
02/04/2026 04:44:14 PM PST

Description



This item is brand-new, factory sealed.

120V (16) 5-20R Out L5-30P 12ft Cord 2U 3YR Wty

Package Contents:
  • PDU31003 16-Outlet PDU
  • 4 x Mounting Brackets: 2 Short & 2 Long
  • 12 x (Flat Head M4 x 8) Bracket Mounting Screws
  • 6 x (M5 x 12) Rack Mounting Screws/Washers
  • 2 x Cord Retention Tray
  • 12 x (M3 x 6) Cord Retention Tray Mounting Screws
  • 24 x Cable Ties
  • RJ45/DB9 Serial Port Connection Cable
  • Users Manual
  • Registration & Software Download Cards

Features

UL Listed:
Yes



Certifications & Standards:
  • UL 60950-1



Additional Information:
  • Physical Dimensions - (WxHxD) (cm) : 43.31 x 8.89 x 11.2 (cm)
  • Physical Dimensions - (WxHxD) (in) : 17.05 x 3.5 x 4.41 (in)
  • Physical Dimensions - (WxHxD) (mm) : 433 x 89 x 112 (mm)
  • Weight (kg) : 3.99
  • Weight (lb) : 8.8
  • Shipping Dimensions - (WxHxD) (cm) : 50.04 x 1.52 x 24.89 (cm)
  • Shipping - Dimensions (WxHxD, in) : 19.7 x 0.6 x 9.8 (in)
  • Shipping - Dimensions (WxHxD, mm) : 500.38 x 15.24 x 248.92 (mm)
  • Shipping - Weight (kg) : 4.88
  • Shipping - Weight (lb) : 10.75
  • Cord Length : 12 ft (3.7 m)
  • Derated Input Current : 24 A
  • Input Frequency Range : 50 Hz - 60 Hz
  • Input Plug Type : NEMA L5-30P
  • Maximum Input Current : 30A
  • Power Cord Length : 12 ft (4 m)
  • Circuit Quantity : 2
  • Nominal Output Voltage : 100 - 120 VAC
  • Number of Outlets : 16
  • Outlets - Total : 16
  • Outlet Type COMPUTED : 16 - NEMA 5-20R
  • Overload Protection : 30A
  • USB Charge Port : No
  • Environmental Sensor : Optional, via RJ45
  • Hardware Connection Port : RJ45
  • LCD : Multifunction LCD
  • Outlet switching : No
  • Protocols : IPv4|TCP/IP|UDP|SNMPv1|HTTP|NTP|DNS|Telnet|DHCP|SMTP|FTP|IPv6|SNMPv3|HTTPs|SSH|SSL|TLS|LDAP(S)|RADIUS|Syslog|CLI|Windows AD
  • Upgradeable firmware : Yes
  • Color : Black
  • Form Factors Supported : Horizontal or Vertical Wallmount
  • Material of Construction : Metal
  • Rack Height : 2U
  • Operating Elevation : 0 - 11483 ft (0 - 3500 m)
  • Operating Relative Humidity : 0 - 95 % (non-condensing)
  • Operating Temperature : 32 - 113 °F (0 - 45 °C)
  • Storage Elevation : 0 - 49213 ft (0 - 14999 m)
  • Storage Temperature : 5 - 131 °F (-15 - 55 °C)
  • Safety : UL 60950-1
  • Extended Warranty Option : WEXT5YR-PDU1A
  • Product Warranty : 3 Year Limited Warranty

    •

    Energy Star:
    No



    Country of Origin:
    China



    Specs

    Power Description
    Input Frequency60 Hz
    Input Voltage Range100 V AC - 120 V AC
    Input Voltage120 V AC
    Circuit BreakerYes
    Output Voltage120 V AC
    Output Voltage Range100 V AC - 120 V AC
    Input Current30 A
    Physical Characteristics
    Weight (Approximate)8.80 lb
    Product ColorBlack
    Depth4.4"
    Product MaterialMetal
    Form FactorRack
    Cord Length12 ft
    Length4.4"
    Mount TypeRack-mountable
    Height3.5"
    Color FamilyBlack
    Mounting OrientationHorizontal/Vertical
    Width17.1"
    Rack Height2U
    Warranty
    Limited Warranty3 Year
    Interfaces/Ports
    Network (RJ-45)Yes
    General Information
    Brand NameCyberPower
    Manufacturer Website Addresshttps://www.cyberpowersystems.com/
    Marketing InformationThe CyberPower PDU31003, a 16-outlet (front), 2U rackmount monitored power distribution unit (PDU), provides 120V 30A output. PDU31003 distributes power to 16 NEMA 5-20R receptacles from a single twist lock NEMA L5-30P plug with unfiltered electrical pass-through. Monitor power status over the network by using the CyberPower management console and the RJ45 Ethernet port for network connection. Monitor power status locally by using the LCD.
    Product TypePDU
    Product NamePDU31003
    ManufacturerCyberPower Systems, Inc
    Manufacturer Part NumberPDU31003
    Product ModelPDU31003
    Product SeriesMonitored PDU
    Technical Information
    Plug/Connector Detail1 x NEMA L5-30P
    Receptacle TypeNEMA 5-20R
    Receptacle Detail16 x NEMA 5-20R
    Plug/Connector TypeNEMA L5-30P
    PDU TypeMonitored
    Protection TypeOverload Protection
    FeaturesLCD Display
    Management
    Remote Outlet SwitchingNo
    Management<ul> <li>IPv4</li> <li>TCP/IP</li> <li>UDP</li> <li>SNMPv1</li> <li>HTTP</li> <li>NTP</li> <li>DNS</li> <li>Telnet</li> <li>DHCP</li> <li>SMTP</li> <li>FTP</li> <li>IPv6</li> <li>SNMPv3</li> <li>HTTPs</li> <li>SSH SSL</li> <li>TLS</li> <li>LDAP(S)</li> <li>RADIUS</li> <li>Syslog</li> <li>CLI</li> <li>Windows AD</li> </ul>
    Environmental Conditions
    Maximum Storage Temperature131&deg;F (55&deg;C)
    Maximum Operating Temperature113&deg;F (45&deg;C)
    Minimum Storage Temperature5&deg;F (-15&deg;C)
    Minimum Operating Temperature32&deg;F (0&deg;C)
