Gigabyte MU70-SU0 Server Motherboard - Intel C621A Chipset - Socket LGA-4189 - Intel Optane Memory Ready - ATX (257807)
(No reviews yet)
Write a Review
- SKU:
- 18470235
- MPN:
- 257807
- Availability:
- Usually ships the same or next business day. In stock at our CA warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 02/19/2026 05:10:47 AM PST
- Stock Update:
- 02/19/2026 05:10:47 AM PST
Description
This item is brand-new, factory sealed.
MU72-SU0 (rev. 1.x)Intel C621A Express Chipset
3rd Gen. Intel Xeon Scalable Processors
Intel Xeon W-3300 Processor Family
8-Channel RDIMM/LRDIMM DDR4 per processor, 8 x DIMMs
Supports Intel Optane Persistent Memory 200 series
Intel C621A Express Chipset
Dual 1Gb/s LAN ports (Intel I210-AT)
1 x Dedicated management port
3 x SlimSAS (for 12 x SATA 6Gb/s) ports
Ultra-Fast M.2 and with PCIe Gen3 x4 interface
Up to 7 PCIe Gen4 expansion slots
Where Compute Reigns
3rd Gen Intel Xeon Scalable Processors Ice Lake
GIGABYTE servers and Intel Xeon Scalable Processors deliver incredible 1P/2P performance from edge to data center with incredible gains in I/O throughput and workload demands that need high performing CPUs with large, yet optimized, memory configurations.
Enhanced I/0: Support for PCIe 4.0 allows for double the throughput of PCIe 3.0 for fast and large data transfers. Also, 64 lanes per socket with up to 128 lanes in a 2P configuration for fast data transmission from CPU to GPU, accelerator or storage.
CPU Performance Boost: Now up to 40 cores per socket with greatly improved IPC on Intels 10nm architecture while operating CPUs at 105-270W. Also, an additional UPI lane is added for up to 11.2GT/s for a low latency interconnect between CPUs.
Next Gen Memory: Support for DDR4-3200MHz (1DPC or 2DPC) DIMM. 8 channel memory has been added with up to 16 DIMMs per socket delivering up to 4TB of system memory via usage of 256GB DDR4 DIMM. Additionally, 2/4/6/8-way interleaves for optimal configuration.
Arrival of Intel Optane PMem 200 Series: Optimized for improvements in latency while increasing system memory up to 6TB per socket as a mix of PMem and DDR. The 200 Series also has support for memory mode to expand capacity and app direct mode to act as fast flash storage.Form Factor
ATX
304.8W x 254D (mm)CPU
3rd Generation Intel Xeon Scalable Processors
Intel Xeon Platinum Processor, Intel Xeon Gold Processor, Intel Xeon Silver Processor
10nm technology, CPU TDP up to 270W
Intel Xeon W-3300 Processor Family
CPU TDP up to 270WSocket
1 x LGA 4189
Socket P+Chipset
Intel C621A Express ChipsetMemory
8 x DIMM slots
DDR4 memory supported only
8-channel memory architecture per processor
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
1.2V modules: 3200/2933/2666 MHzLAN
2 x 1Gb/s LAN ports ( Intel I210-AT)
1 x 10/100/1000 management LANVideo
Integrated in Aspeed AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200 at 60Hz 32bpp, DDR4 SDRAMAudio
N/ASAS
N/ASATA
3 x SlimSAS for 12 x SATA III 6Gb/s portsRAID
Intel SATA RAID 0/1/10/5Expansion Slots
Slot_7: 1 x PCIe x16 (Gen4 x16 bus) slot
Slot_6: 1 x PCIe x16 (Gen4 x16 or x8 bus) slot, shared with Slot_5
Slot_5: 1 x PCIe x16 (Gen4 x0 or x8 bus) slot
Slot_4: 1 x PCIe x16 (Gen4 x16 or x8 bus) slot, shared with Slot_3
Slot_3: 1 x PCIe x16 (Gen4 x0 or x8 bus) slot
Slot_2: 1 x PCIe x16 (Gen4 x16 or x8 bus) slot, shared with Slot_1
Slot_1: 1 x PCIe x16 (Gen4 x0 or x8 bus) slot
1 x M.2 slot:
- M-key
- PCIe Gen3 x4 per slot
- Supports NGFF-2280 cardsInternal I/O
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 6-pin ATX 12V power connector ( for PCIe slot)
3 x SlimSAS connectors
1 x M.2 slot
1 x CPU fan header
6 x System fan headers
1 x USB 3.0 header
1 x TPM header
1 x VROC connector
1 x Front panel header
1 x BuzzerRear I/O
4 x USB 3.0
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LEDTPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010OS Supported
Windows Server 2016
Windows Server 2019
Red Hat Enterprise Linux 8.2 ( x64) or later
Red Hat Enterprise Linux 8.3 ( x64) or later
SUSE Linux Enterprise Server 12 SP5 ( x64) or later
SUSE Linux Enterprise Server 15 SP2 ( x64) or later
Ubuntu 20.04 LTS (x64) or later
Ubuntu 20.04.1 LTS (x64) or later
VMware ESXi 6.7 Update3 P03
VMware ESXi 7.0 Update2
Citrix Hypervisor 8.2.0Board Management
Aspeed AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Dashboard
JAVA Based Serial Over LAN
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup and Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP SettingsPSU Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connectors
1 x 6-pin PCIe power connectorsOperating Properties
Operating temperature: 10oC to 40oC
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40oC to 60oC
Non-operating humidity: 20%-95% (non-condensing)Retail Packaging Content
1 x MU72-SU0
1 x I/O shield
1 x Quick start guide
1 x SlimSAS for 4 x SATAIII 6Gb/s cable
Single Box dimensions: 360 x 330 x 80 mm
Carton dimension: 674 x 424 x 385 mm
Quantity: 10 x single box with one carton
Package Contents:
- MU72-SU0 (rev. 1.x) Server Motherboard
- I/O shield: 12AIO-MU72SU-00R
- SlimSAS for 4 x SATAIII 6Gb/s Cable
- Quick Start Guide
Features
Package Contents:
Yes
Taiwan
- MU72-SU0 (rev. 1.x) Server Motherboard
- I/O shield: 12AIO-MU72SU-00R
- SlimSAS for 4 x SATAIII 6Gb/s Cable
- Quick Start Guide
Environmentally Friendly:
Yes
Environmental Compliance:
Waste Electrical and Electronic Equipment Directive (WEEE)
China Restriction of Hazardous Substances (China RoHS)
Country of Origin:
Taiwan
Specs
| Physical Characteristics | |
| Form Factor | ATX |
| Width | 12" |
| Depth | 10" |
| Warranty | |
| Limited Warranty | 3 Year |
| I/O Expansions | |
| Total Number of Expansion Slots | 7 |
| Number of PCI Express x16 Slots | 7 |
| Total Number of PCI Express Slots | 7 |
| Memory | |
| Memory Technology | DDR4 SDRAM |
| Number of Memory Slots | 8 |
| Memory Speed Supported |
|
| Memory Form Factor |
|
| Maximum Memory Supported | 256 GB |
| Intel Optane Memory Ready | Yes |
| General Information | |
| Brand Name | GIGABYTE |
| Manufacturer Website Address | http://www.gigabyte.us |
| Marketing Information | Where Compute Reigns | 3rd Gen Intel® Xeon® Scalable Processors - "Ice Lake" GIGABYTE servers and Intel Xeon Scalable Processors deliver incredible 1P/2P performance from edge to data center with incredible gains in I/O throughput and workload demands that need high performing CPUs with large, yet optimized, memory configurations. Enhanced I/0: Support for PCIe 4.0 allows for double the throughput of PCIe 3.0 for fast and large data transfers. Also, 64 lanes per socket with up to 128 lanes in a 2P configuration for fast data transmission from CPU to GPU, accelerator or storage. CPU Performance Boost: Now up to 40 cores per socket with greatly improved IPC on Intel's 10nm architecture while operating CPUs at 105-270W. Also, an additional UPI lane is added for up to 11.2GT/s for a low latency interconnect between CPUs. Next Gen Memory: Each processor provides eight memory channels to support 8 or 16 DIMM slots with up to DDR4-3200. There are two sub-clustering modes, Sub NUMA (SNC) and Hemisphere (HEMI), available using balanced memory that results in performance improvements. Additionally, support for Intel Optane PMem 200 series provides two modes for greater memory capacity and data persistence to process large amounts of data faster. Next Level Security: New instructions and architecture deliver a high level of cryptographic operations for data privacy and protection. Cryptographic accelerators speed up encryption protocols as well as improvements in software guard extensions and memory encryption are added. AI Acceleration: AI inference and training are enhanced with DL Boost Technology for greater business, operational, and security insights. Applications include HPC, AI, and Media & Graphics. Intel® Xeon® W-3300 Processors The Intel® Xeon® W-3300 processors are optimized for advanced workstation professionals in a single socket solution. These processors are designed for heavily threaded, I/O intensive workloads across Architecture, Engineering, and Construction (AEC), Media and Entertainment (M&E), and Artificial Intelligence/ Machine Learning (AI & ML). |
| Product Type | Server Motherboard |
| Product Name | MU72-SU0 (rev. 1.x) Server Motherboard |
| Manufacturer | GIGABYTE Technology, Inc |
| Manufacturer Part Number | MU72-SU0 |
| Product Model | MU70-SU0 |
| Processor & Chipset | |
| Chipset Manufacturer | Intel |
| Processor Generation Supported | 3rd Gen |
| Processor Supported |
|
| Total Processor Supported | 1 |
| Processor Socket | Socket LGA-4189 |
| Chipset Model | C621A |
| Onboard Interfaces | |
| Total Number of Onboard USB Ports | 2 |
| Number of M.2 Interfaces | 1 |
| Number of Onboard USB 3.0 Ports | 2 |
| Interfaces/Ports | |
| VGA | Yes |
| Total Number of USB Ports | 4 |
| Number of USB 3.0 Ports | 4 |
| Number of Network (RJ-45) Ports | 2 |
| I/O Controller | |
| RAID Supported | Yes |
| Controller Type |
|
| RAID Levels |
|
| Video | |
| Onboard Video | On-board Video Chipset |
| Graphics Controller Model | AST2600 |
| Network & Communication | |
| Gigabit Ethernet | Yes |
