J5 Create JVA11 4K HDMI Video Capture Adapter

This item is brand-new, factory sealed.

4K HDMI Capture Adapter

HDMI to USB-C 3.2 4K Capture Device

Windows / macOS / Chrome OS / Android Compatible

Model: JVA11

Record or stream high resolution video content with a compact 4K capture device. The USB-C cable includes a USB Type-A adapter for increased device compatibility and works with a variety of video capture software. USB 3.2 supports high quality streams and recordings. Its small size makes it easy to transport and put away. This is a great device for video podcasts, field production, and capturing gameplay.

Use With Various Devices

Three HDMI Input Resolutions For Recording

Ablility To Capture 4K@30 FPS, 2K60 FPS, 1080P 120 FPS

Ideal for live streaming, broadcasting, and gaming

It works with OBS, XSplit, CameraFi, QuickTime, and other video streaming software.

Compatible with PlayStation 4/5, Xbox Series X/S, Xbox One X/S, and Switch gaming consoles.

Third-Party Software Support

Capture and Record in 4K Resolution For a Clear Visual Experience

Stream with Ultra-Low Latency and a High-Performance USB-C 3.2 Connection

No Driver Installation Required

Compliance with the UVC/UAC Standard

USB-C Cable Includes a Type-A Adapter for Added Compatibility

Ideal For a Variety Of Uses

Gaming Video Conferencing Live Streaming BroadcastingHardware
audio input
1 - HDMI Female
audio output
N/A
audio switcher
N/A
host connector
1 - USB-C 3.2 Gen 1 Female (Type-A to USB-C)
ports
1 - USB-C 3.2 Gen 1 (Host)
1 - HDMI Input
power source
N/A
video input
1 - HDMI Female
video output
N/A
video switcher
N/APerformance
audio channel
2.1 via HDMI
audio frequency
48 kHz
compressions
USB 3.0: RGB / YUV4:2:2 / YUV4:2:0
USB 2.0: YUV4:2:0
hdmi input resolutions
3840 x 2160 at 30
hdr supported
No
headset
N/A
maximum capture capability
USB 3.0: 3840 x 2160 at 30
USB 2.0: 1280 x 720 at 30
maximum capture refresh rate
4K30 fps, 2K60 fps, 1080p120 fps
max display refresh rate
N/A
microphone
N/APower
input current
1.5A
input voltage
5V
output current
N/A
output voltage
N/A
power consumption
less than or equal 530mA
power delivery
N/APhysical Specifications
cable length
7.87 in. (20 cm)
color
Black
enclosure type
Aluminum
operating humidity
<80% non-condensing
operating temperature
32 to 104^oF (0 to 40^oC)
storage humidity
<85% non-condensing
storage temperature
14 to 149^oF (-10 - 65^oC)Package Contents
1 - JVA11 4K HDMI Capture Adapter
1 - Quick Installation Guide (QIG)Country Of Origin Declaration
Country Of Origin - TaiwanItem Dimension (L"xW"xH")
4 x 6 x 1

Weight
1 lb

Warranty Information
2 Year

Package Contents:

• 4K HDMI Capture Adapter
• 1 x Quick Installation Guide (QIG)
