Kingston
Kingston Server Premier 32GB DDR4 SDRAM Memory Module (KSM32RS4/32HCR) KSM32RS4/32HCR
(No reviews yet)
Write a Review
- SKU:
- 18915170
- MPN:
- 261554
- Availability:
- Usually ships the same or next business day. In stock at our CA warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 03/24/2026 04:10:20 PM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 - 19 | and pay only $357.40 each 357.4 |
| Buy 20 or above | and pay only $351.69 each 351.69 |
- Stock Update:
- 03/24/2026 04:10:20 PM PST
Description
This item is brand-new, factory sealed.
KSM32RS4/32HCR32GB 1Rx4 4G x 72-Bit PC4-3200
CL22 Registered w/Parity 288-Pin DIMM
DESCRIPTION
Kingston's KSM32RS4/32HCR is a 4G x 72-bit (32GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM) registered w/ parity, 1Rx4, ECC, memory module, based on eighteen 4G x 4-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers. The electrical and mechanical specifications are as follows:
FEATURES
Power Supply: VDD = 1.2V
VDDQ = 1.2V
VPP = 2.5V
VDDSPD = 2.41V to 2.75V
Functionality and operations comply with the DDR4 SDRAM datasheet
16 internal banks
Bank Grouping is applied, and CAS to CAS latency (tCCD_L, tCCD_S) for
the banks in the same or different bank group accesses are available
Data transfer rates: PC4-3200, PC4-2933, PC4-2666, PC4-2400, PC4-2133, PC4-1866, PC4-1600
Bi-Directional Differential Data Strobe
8 bit pre-fetch
Burst Length (BL) switch on-the-fly BL8 or BC4(Burst Chop)
Supports ECC error correction and detection
On-Die Termination (ODT)
Temperature sensor with integrated SPD
This product is in compliance with the RoHS directive.
Per DRAM Addressability is supported
Internal Vref DQ level generation is available
Write CRC is supported at all speed grades
CA parity (Command/Address Parity) mode is supportedCL(IDD)
22cyclesRow Cycle Time (tRCmin)
45.75ns(min.)Refresh to Active/Refresh Command Time (tRFCmin)
350ns(min.)Row Active Time (tRASmin)
32ns(min.)Maximum Operating PowerUL Rating
94 V - 0Operating Temperature
0o C to +85o CStorage Temperature
-55o C to +100o CItem Dimension (L"xW"xH")
7 x 3 x 1
Weight
1 lb
Warranty Information
Lifetime
Features
Compatibility:
Taiwan
- Apple - Mac Pro Tower/Rack (2019) Rack Server
Acer Altos BrainSphere Servers:
- P530 F4
- P550 F4
- R185 F5
- R360 F5
- R365 F5
- R369 F4
- R380 F5
- R385 F4
- R385 F5
- R389 F4
- R685 F5
- T350 F4
AIC Products:
- Auriga Server Board
- FB128-AG Server
- LYNX Server Board
- SB101-UR Server
- SB102-UR Server
- SPICA Server Board
- URSA Server Board
- VELA Server Board
- Virgo Server Board
ASRock Products:
- Server 1U-Open19-m3.large.x86
- Server 1U-Open19-m3.medium.x86
- Server 1U12XL-EPYC/2T (EPYCD8-2T)
- Server 1U12XL-EPYC/2T2E (EPYCD8-2T)
- Server 1U1G-WC422/2T
- Server 1U4G-ROME
- Server 1U4LW-ROME/2T
- Server 2U24E-ROME
- Server 2U24E/ROME2
- Server 2U2E-F/ROME2
- Server 2U4G-EPYC (EPYCD8)
- Server 2U4G-EPYC-2T (EPYCD8-2T)
- Server 2U4G-ROME/2T
- Server 3U4X-ROME/2T
- Server 4U10G-ROME2/2T
- Server 4U8G-ROME2/2T
- Server 7U8X-ROME/2T
- Server Board EP2C621D16-4LP
- Server Board EP2C621D16FM
- Server Board EP2C621D16GM
- Server Board EP2C621D16HM-AB
- Server Board EP2C621D16HM2-M3
- Server Board EP2C622D16-2T
- Server Board EP2C622D16FM
- Server Board EP2C622D16NM
- Server Board EPC621D6U-2T
- Server Board EPC621D6U-2T16R
- Server Board EPYCD8
- Server Board EPYCD8-2T
- Server Board ROM2D16-2T
- Server Board ROM2D16HM3
- Server Board ROME2D32LM3
- Server Board ROME2D32TM3
- Server Board ROMED16QM3
- Server Board ROMED8-2T
- Server Board SP2C621D16N
- Server Board SP2C621D32GM-2T
- Server Board SP2C621D32LM3
- Server Board SP2C621D32TM3
- Server Board SPC621D16QM32
- Server Board SPC621D8
- Server Board SPC621D8-2L2T
- Server Board SPC621D8HM3
- Server Board SPC621D8U-2T
ASUS Products:
- E900 G4 Workstation
- ESC Server ESC8000 G4
- ESC Server ESC8000 G4/10G
- ESC4000 DHD G4 Server
- ESC4000 G4 Server
- ESC4000 G4S Server
- ESC4000 G4X Server
- ESC4000-E10 Server
- ESC4000-E10S Server
- ESC4000A-E10 Server
- ESC4000A-E11 Server
- ESC8000A-E11 Server
- KRPA-U16 Motherboard
- Pro E800 G4 Workstation
- Pro WS C422 ACE Motherboard
- Pro WS C621-64L SAGE/10G Motherboard
- Pro WS WRX80E-SAGE SE WIFI
- RS500-E9-PS4 Server
- RS500-E9-RS4 Server
- RS500-E9-RS4-U Server
- RS500A-E10-PS4 Server
- RS500A-E10-RS12U Server
- RS500A-E10-RS4 Server
- RS500A-E11-RS12U Server
- RS500A-E11-RS4U Server
- RS520-E9-RS12-E Server
- RS520-E9-RS12UV2 Server
- RS520-E9-RS8 Server
- RS520-E9-RS8 V2 Server
- RS520A-E11-RS12U Server
- RS520A-E11-RS24U Server
- RS540-E9-RS36-E Server
- RS620SA-E10-RS12 Server
- RS700-E10-RS12U Server
- RS700-E10-RS4U Server
- RS700-E9-RS12 Server
- RS700-E9-RS4 Server
- RS700A-E11-RS12U Server
- RS700A-E11-RS4U Server
Country of Origin:
Taiwan
Specs
| Physical Characteristics | |
| Form Factor | DIMM |
| Length | 5.3" |
| Number of Pins | 288-pin |
| Width | 1.2" |
| Warranty | |
| Limited Warranty | Lifetime |
| General Information | |
| Brand Name | Kingston |
| Manufacturer Website Address | http://www.kingston.com |
| Product Type | RAM Module |
| Product Name | Server Premier 32GB DDR4 SDRAM Memory Module |
| Manufacturer | Kingston Technology Company |
| Manufacturer Part Number | KSM32RS4/32HCR |
| Product Line | Server Premier |
| Technical Information | |
| Memory Technology | DDR4 SDRAM |
| Memory Size | 32 GB |
| CAS Latency | CL22 |
| Memory Rank | Single-rank |
| Memory Speed | 3200 MHz |
| Device Supported |
|
| Memory Voltage | 1.20 V |
| Memory Standard | DDR4-3200/PC4-25600 |
| Error Checking | ECC |
| Signal Processing | Registered |
