Maretron CM-CG1-CF-10.0 Micro Double-ended Cordset, 10m CMCG1CF10.0

(No reviews yet) Write a Review
SKU:
18259522
MPN:
cm-cg1-cf-10-0
Availability:
Usually ships the same or next business day. In stock at our GA, MI, TX, WA warehouses.
Shipping:
Calculated at Checkout
Stock Update:
02/02/2026 12:56:55 PM PST
$69.82
Buy more, get it as low as $

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

Buy 2 and pay only $64.00 each 64
Buy 3 - 6 and pay only $62.95 each 62.95
Buy 7 or above and pay only $61.74 each 61.74
Stock Update:
02/02/2026 12:56:55 PM PST

Description

This item is brand-new, factory sealed.

Mechanical
  • Contact Carrier Mat/Color: Thermoplastic PUR/Blue-Gray
  • Molded Body Mat/Color: Thermoplastic PUR/Blue-Gray
  • Contact Mat/Plating: Brass/Gold
  • Coupling Nut Mat/Plating: Brass/Nickel
  • Connector Outside Diameter: 0.59"
    Electrical
  • Current Rating: 4.0 Amps
  • Voltage Rating: 250 V
    Cable
  • Outer Jacket Mat/Color: PVC/Gray
  • Conductor Insulation Material: HDPE (data pair), SRPVC (power pair)
  • Number of Conductors: 4X22 AWG, 22 AWG Drain Wire
  • Shielding (3-Levels): FOIL (Overall), FOIL (Power Pair), FOIL (Data Pair)
    Environmental
  • Protection Class: IEC IP68, NEMA 1,3,4,6P
  • Temperature Rating: -40 deg C to 80 deg C to (-40 deg F to 176 deg F)
    Approvals
  • (Cable) UL: PLTC 75 deg C Sunlight Resistant E90625,
    AWM 80 deg C 300V
  • (Cable) CSA: CMX-OUTDOOR-CMG LL54185 75 deg C,
    AWM I/II A/B 80C 300V FT4
  • NMEA: NMEA 2000 Approved
    • View AllClose

    Warranty Information

    All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
