Mimo Monitors UM-760-OF 7in Open Frame 1024x600 Usb Mntr Non-touch
- SKU:
- 18956035
- MPN:
- um-760-of
- Availability:
- Out of stock
- Stock Update:
- 05/30/2025 09:33:53 AM PST
- Stock Update:
- 05/30/2025 09:33:53 AM PST
Description
This item is brand-new, factory sealed.
The same 7" small non-touch monitor from the UM-760, but now available in open frame for applications that will be integrated into other equipment or enclosures. Same slick design features as our popular 760 model, this is a great entry-level display-only model.. The screen can display in either landscape or portrait orientations. The UM-760-OF open frame touchscreen monitor is designed to provide the most cost effective solutions for consumer, retail POS, and hospitality markets.
-
Utilizes DisplayLinkTM technology that provides video, touch and power over a single USB connection. No separate power supply to worry about
-
Ultra-light, weighs less than 1 pound
-
Can be applied as a secondary customer-facing display in retail POS environments
-
Mechanical drawings available upon request
Features
Yes
Application/Usage:
Hospitality
Gaming
Point of Sale (POS)
Kiosk System
Retail
Country of Origin:
South Korea
Specs
| Power Description | |
| Maximum Power Consumption | 4 W |
| Physical Characteristics | |
| Height | 5.3" |
| Width | 7" |
| Depth | 1" |
| Warranty | |
| Limited Warranty | 1 Year |
| Interfaces/Ports | |
| USB | Yes |
| Video | |
| Native Contrast Ratio | 700:1 |
| Brightness | 250 Nit |
| Maximum Resolution | 1024 x 600 |
| General Information | |
| Brand Name | Mimo Monitors |
| Manufacturer Website Address | http://www.mimomonitors.com |
| Marketing Information | 7" Open Frame Non-Touch Display, USB The UM-760-OF is a 7" small capacitive open frame touchscreen monitor, enabling easy integration into custom enclosures or other equipment for a range of applications. This small touchscreen display monitor sacrifices nothing in slick design, but now has the added responsiveness of a 5 point multi-touch capacitive touchscreen integrated in a rugged, durable molded metal product cycle-enclosure. No external changes are needed when it comes time to phase in future generation panels. The UM-760-OF open frame touchscreen monitor delivers the most cost-effective solution for applications such as hospitality, retail, trade shows, gaming, light industrial automation, and much more. Video and Power Via Single USB Connection Utilizing the same single cable USB display technology found on our line of displays, the UM-760-OF 7-inchnon-touch monitor delivers video and power over a single USB connection. No more cluttered connections or the inconvenience of connecting AC power to your wall or desk-mounted touch screen monitor. More from the Manufacturer |
| Product Type | Open-frame LCD Touchscreen Monitor |
| Product Name | Open Frame 7" USB LCD Monitor |
| Manufacturer | Mimo Monitors, Inc |
| Manufacturer Part Number | UM-760-OF |
| Product Model | UM-760-OF |
| Technical Information | |
| Vertical Viewing Angle | 145° |
| Viewable Screen Size | 7" |
| Response Time | 15 ms |
| Mount Type | Desk Mountable |
| Screen Mode | WSVGA |
| Horizontal Viewing Angle | 150° |
| Screen Size Class | 7" |
| Aspect Ratio | 16:9 |
| Audio | |
| Speakers | Yes |
| Environmental Conditions | |
| Operating Temperature Range | -4°F (-20°C) to 140°F (60°C) |
| Touchscreen Information | |
| Touchscreen Type | Capacitive |
| Multi-touch Screen | Yes |
| Number of Simultaneous Touchpoints | 5 |
