Muxlab
MuxLab HDMI over IP PoE Seamless Transceiver, 4K30 (500860)
- SKU:
- 21243891
- MPN:
- 500860
- Availability:
- Usually ships the same or next business day. In stock at our TX warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 04/02/2026 11:26:53 AM PST
- Stock Update:
- 04/02/2026 11:26:53 AM PST
Description
This item is brand-new, factory sealed.
The HDMI over IP PoE Seamless Transceiver, 4K/30 allows HDMI source equipment to be extended locally up to 330ft (100m) at up to 4K @ 30Hz resolution via Cat5e/6 cable and is compatible with the MuxLab 500861 Transceivers to support point-to-point, point-to-multipoint and multipoint-to-multipoint configurations, Video Wall and Multiview capabilities in a low bandwidth expandable and cost effective manner, without the need to install dedicated cabling systems. The exceptionally low bandwidth requirements of this device combination allows for streaming audio/video content over a local network, over WiFi, and over the Internet for distributed installations spread throughout the globe. The Transceiver accepts a 4K video @ 30Hz and streams the content to an H.264/H.265 Receiver to be displayed on a 4K monitor. The device supports PoE (PD) and may be powered by a PoE (PSE) Ethernet Switch.
Applications:
- Audio/Video Streaming over LAN, Wifi and Internet
- Commercial and residential AV systems
- Classroom projector systems
- Digital signage
- Boardroom systems
- Medical information systems
Features
Monitor
Commercial
Residential
A/V Equipment
Classroom
Projector
Boardroom
Digital Signage System
Specs
| Power Description | |
| Power over Ethernet (PoE) | Yes |
| Interfaces/Ports | |
| Number of USB Ports | 2 |
| Network (RJ-45) | Yes |
| HDMI Out | Yes |
| Number of HDMI Inputs | 1 |
| HDMI In | Yes |
| USB | Yes |
| Number of HDMI Outputs | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Video | |
| Maximum Video Resolution | 3840 x 2160 |
| Graphics Modes | 4K |
| General Information | |
| Brand Name | MuxLab |
| Manufacturer Website Address | http://www.muxlab.com |
| Marketing Information | The HDMI over IP PoE Seamless Transceiver, 4K/30 allows HDMI source equipment to be extended locally up to 330ft (100m) at up to 4K @ 30Hz resolution via Cat5e/6 cable and is compatible with the MuxLab 500861 Transceivers to support point-to-point, point-to-multipoint and multipoint-to-multipoint configurations, Video Wall and Multiview capabilities in a low bandwidth expandable and cost effective manner, without the need to install dedicated cabling systems. The exceptionally low bandwidth requirements of this device combination allows for streaming audio/video content over a local network, over WiFi, and over the Internet for distributed installations spread throughout the globe. The Transceiver accepts a 4K video @ 30Hz and streams the content to an H.264/H.265 Receiver to be displayed on a 4K monitor. The device supports PoE (PD) and may be powered by a PoE (PSE) Ethernet Switch. Applications : Audio/Video Streaming over LAN, Wifi and Internet Commercial and residential AV systems Classroom projector systems Digital signage Boardroom systems Medical information systems |
| Product Type | Video Extender Transceiver |
| Product Name | HDMI over IP PoE Seamless Transceiver, 4K30 |
| Manufacturer | MuxLab, Inc |
| Manufacturer Part Number | 500860 |
| Media & Performance | |
| Twisted Pair Cable Standard |
|
| Technical Information | |
| Maximum Operating Distance | 328.08 ft |
| Connectivity Technology | Wired |
