Qnap

QNAP TS-453BT3 SAN/NAS/DAS Storage System (ts-453bt3-8g-us)

(No reviews yet) Write a Review
SKU:
18061736
MPN:
ts-453bt3-8g-us
Availability:
Out of stock
Stock Update:
01/02/2026 08:58:19 PM PST
  • Right
  • Rear
  • Left
  • Front
  • Alternate-Image3
  • Alternate-Image2
  • Alternate-Image1
  • Main

Out of stock

Stock Update:
01/02/2026 08:58:19 PM PST

Description

This item is brand-new, factory sealed.

Specifications

  • Mfr Part Number: TS-453BT3-8G-US
  • Hardware:
    • CPU: Intel Celeron J3455 quad-core 1.5 GHz processor (burst up to 2.3 GHz)
    • CPU Architecture 64-bit x86
    • Graphic Processors Intel HD Graphics 500
    • System Memory 8 GB SO-DIMM DDR3L (2 x 4 GB)
    • Maximum Memory 8 GB (2 x 4 GB)
    • Memory Slot 2 x SO-DIMM DDR3L
    • Flash Memory 4GB (Dual boot OS protection)
    • Drive Bay 4 x 3.5-inch SATA 6Gb/s, 3Gb/s
    • Drive Compatibility
      • 3.5-inch SATA hard disk drives
      • 2.5-inch SATA hard disk drives
      • 2.5-inch SATA solid state drives
    • M.2 SSD Slot  2 x M.2 2280 SATA 6Gb/s SSD slots (pre-installed QM2 PCIe card)
    • Gigabit Ethernet Port (RJ45) 2
    • 10 Gigabit Ethernet Port 1 x 10GBASE-T (10G/5G/2.5G/1G/100M)
    • Thunderbolt Port 2 (Thunderbolt 3)
    • PCIe Slot 1 x PCIe Gen 2 (x2), pre-installed with a QM2 expansion card (QM2-2S10G1TB) that includes a 10GbE 10GBASE-T port and two M.2 SATA SSD slots.
    • USB 3.0 port 5
    • USB 3.1 Gen 2 (10Gbps) Port Optional via a PCIe adapter (need to replace the pre-installed QM2 card)
    • IR Sensor (RM-IR004, RM-IR002, & MCE)
    • HDMI Output 2, HDMI 1.4b (up to 3840 x 2160 @ 30Hz)
    • Audio Input 2 x 3.5mm dynamic microphone input jacks
    • Audio Output 1 x built-in speaker, 1 x 3.5mm line out jack (for amplifier or headphone amplifier)
    • Form Factor Tower
    • LED Indicators Power/Status, LAN, USB, HDD1-4
    • LCD Display/ Button Monochrome OLED display with capacitive sensing Enter and Select buttons
    • Buttons Power, USB copy, Reset, Capacitive touch buttons (select, enter)
  • Networking:
    • TCP/IP: Dual stack (IPv4 and IPv6)
    • Jumbo frame
    • DHCP server and client
    • USB Wi-Fi Adapter
    • Virtual Switch
      • Combining containers in the same virtual switch
      • Network Address Translation (NAT)
      • Spanning Tree Protocol (STP)
    • USB QuickAccess
    • WirelessAP Station
  • Security:
    • Network access protection with auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
    • CIFS host access control for shared folders
    • FIPS 140-2 validated AES 256-bit volume-based data encryption
    • AES 256-bit external drive encryption
    • Importable SSL certificates.
    • Instant alerts via email, SMS, beep, and push service
    • 2-step verification
    • Data encryption functions may be unavailable in accordance with the legislative restrictions of some countries.
  • Storage Management:
    • Storage space utilization monitoring
    • Flexible volumes and LUNs with thin provisioning and space reclaiming
    • Disk volume types: single, RAID 0, 1, 5, 6, 10, hot spare and global hot spare
    • Storage pools
    • Qtier Technology (automated storage tiering)
    • Supports snapshots
    • Snapshots
    • Note: This feature requires 4 GB of system memory.
      • Volume and LUN snapshots
      • Snapshot Manager
      • Snapshot cloning
      • Snapshot Vault
      • Snapshot Replica Unify Snapshot Directory
      • Support for previous Windows versions (SMB)
      • Snapshot Agent for Microsoft Windows and VMware vSphere
    • Online volume expansion
    • Online storage pool expansion
    • Online RAID capacity expansion and online RAID level migration
    • SMART data migration
    • Storage expansion through QNAP expansion units
    • JBOD enclosure roaming
    • SSD read-only or read-write cache
      • Note: The cache size depends on the total memory.
    • Bad block scan and hard drive S.M.A.R.T.
    • Bad block recovery and RAID recovery
    • Bitmap support
  • File System:
    • Internal hard drive (EXT4)
    • External hard drive (EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT) Note: You can purchase exFAT driver licenses on the License Center.
  • Form Factor: Tower
  • Fan: System: 1 x 120mm
  • Power Consumption: 38.101W (Typical Operation)
  • Power Supply Unit: 120W adapter, 100-240V
  • Dimensions: 6.61 x 6.69 x 8.9 inch
  • Weight: 5.53 lbs

Features

Package Contents:
  • TS-453BT3 SAN/NAS/DAS Storage System
  • 2 x Ethernet Cables
  • AC Adapter
  • 1 x Power Cord
  • 12 x Flat Head Screws (for 2.5" HDD)
  • Quick Installation Guide (QIG)
  • Infrared (IR) Remote Control



Country of Origin:
Taiwan



Specs

Controllers
RAID SupportedYes
Controller TypeSerial ATA/600
RAID Levels0, 1, 5, 6, 10, Hot Spare
Management & Protocols
Protocols
  • AFP
  • NFS
  • SMB
  • DNS
  • Telnet
  • DLNA
  • IPv6
  • FTPS
  • WEBDAV
  • SSL/TLS
  • CIFS
  • HTTPS
  • FTP
  • SSH
  • DHCP
  • FXP
  • SMTP
  • LDAP
  • iSCSI
  • IPv4
  • UPnP
  • TCP/IP
  • PPTP
  • HTTP
  • DDNS
  • CIFS/SMB
  • RSync
  • SNMP
Physical Characteristics
Form FactorTower
Weight (Approximate)5.53 lb
Height6.6"
Width6.7"
Depth8.9"
Warranty
Limited Warranty2 Year
I/O Expansions
Total Number of Expansion Slots1
Number of Total Expansion Bays4
Number of 2.5"/3.5" Bays4
Memory
Standard Memory8 GB
Memory TechnologyDDR3L SDRAM
General Information
Brand NameQNAP
Manufacturer Website Addresshttp://www.qnap.com
Marketing InformationFeaturing dual Thunderbolt™ 3 ports, coupled with M.2 SSD caching and 10GBASE-T connectivity, the TS-453BT3 provides an ideal environment for professional collaborative media editing and high-speed file sharing. The TS-453BT3 features a sleek new look with an OLED panel and two capacitive touch buttons. With powerful hardware capabilities and feature-rich productivity tools, the TS-453BT3 provides the best NAS solution for media studios or small creative workgroups looking to greatly simplify their workflows.
High-speed Thunderbolt 3 with SMB protocol, allowing Mac and Windows users to collaborate on media editing.
Dual M.2 SATA 6 Gb/s SSD allows for setting up caching or storage pool, improving file access efficiency.
10GbE connectivity accelerates virtualization applications and file sharing across devices.
Qtier™ auto-tiering technology and SSD caching enable 24/7 optimized storage efficiency
4K media playback and real-time transcoding; directly view creative works on an HDTV via HDMI output.
Qfiling automates file organization, greatly improving work efficiency.
Runs faster with Thunderbolt™ 3 and 10GbE connectivity
Powered by an Intel® Celeron® J3455 quad-core 1.5GHz processor (burst up to 2.3 GHz), with up to 8GB DDR3L RAM, dual Gigabit LAN ports, and SATA 6Gb/s drives, the TS-453BT3 delivers up to 683 MB/s read/write speeds and up to 683 MB/s with AES-NI encryption, delivering high performance while also maintaining the security of your data. The Thunderbolt 3 port runs up to 514 MB/s, allowing for quick file access. You can also connect USB Type-C devices through the Thunderbolt 3 ports to transfer large media files across devices, bringing you a more efficient workflow.
Collaboration station for Mac and Windows
TS-453BT3 is the perfect match for users with Thunderbolt 3 Mac and can also be used with Thunderbolt 2 Mac by using a suitable adapter. The increased bandwidth of Thunderbolt 3 enables smooth video editing and faster file sharing for photographers, video editors and graphic designers. Up to 2 Thunderbolt devices can be connected to the TS-453BT3 to process real-time photo and audio editing simultaneously without impacting system performance. As Final Cut Pro® X 10.3 supports file sharing via SMB, Windows users and other devices utilizing Thunderbolt™ 3, 10GbE or GbE connections can join the editing workflow more efficiently.
Direct access to 10GbE network from your Mac
The innovative Thunderbolt-to-Ethernet converter (T2E) allows your Mac® devices to access 10GbE networks via the TS-453BT3, providing flexible, convenient and highly-efficient data transfer without needing to buy extra adapters or converters.
Greater efficiency with SSD caching and 10GbE connectivity
The pre-installed dual-port M.2 SATA SSD/10GBASE-T expansion card* enables caching or Qtier auto-tiering technology to improve NAS performance without occupying disk bays of the NAS.
The 10GBASE-T port ensures that the TS-453BT3 meets 10GbE infrastructure requirements and can efficiently manage data transfers requiring high-bandwidth.
Simple, sleek and trendy look
The TS-453BT3 features a sliding cover design with tool-less 3.5-inch hard drive installation, making it easier for you to set up and maintain. The OLED front panel displays system information (including CPU temperatures, fan speed, and storage capacities of hard drives, volumes and LUN), allowing you to quickly view overall system status. Dust-proof capacitive touch buttons allow you to easily wake up the screen, change network IP settings and host password or even restart and shut down the system.
Product TypeSAN/NAS/DAS Storage System
Product NameTS-453BT3 SAN/NAS/DAS Storage System
ManufacturerQNAP Systems
Manufacturer Part NumberTS-453BT3-8G-US
Product ModelTS-453BT3
Processor & Chipset
Processor CoreQuad-core (4 Core)
Processor ModelJ3455
Processor TypeCeleron
Processor Speed1.50 GHz
Storage
Number of Hard Drives Supported4
Number of Hard Drives InstalledNo
Number of Solid State Drive InstalledNo
Number of Solid State Drive Supported6
Interfaces/Ports
Network (RJ-45)Yes
Host Interface
  • USB 3.0
  • Thunderbolt 2
HDMIYes
Total Number of USB Ports5
Number of USB 3.0 Ports5
Network & Communication
Ethernet Technology10 Gigabit Ethernet
Software
Operating SystemQTS 4.3
