SIIG WiFi 6 Dual Band Ethernet PCIe Card - AX3000 LBWR0111S1

This item is brand-new, factory sealed.

Quickly adds WiFi 6 and Bluetooth 5 wireless connectivity through an available PCI Express slot to server or desktop systems

Wi-Fi 6 provides Gigabit wireless speed and dramatically improves wireless coverage at home and work environments

Supports the new WPA3 security feature, enabling next-generation authentication and military-grade encryption

Supports speeds up to 2.4G Mbps on 5 GHz or 574 Mbps on 2.4 GHz dual band data rate

MIMO technology effectively improves signal gain when multiple users are sending and receiving at the same time

Delivers 80MHz to 160MHz, double throughput, ultra-low latency, and uninterrupted connectivity

Works with all current Wi-Fi routers and backward compatible with 802.11a/b/g/n/ac Wi-Fi standards

Bluetooth 5 provide 4 times the coverge range over Bluetooth 4.2 and enhances data broadcasting, enabling seamless services such as location-based services plus simpler pairing of Bluetooth devices. Note: Bluetooth operation requires connecting the included USB cable between the adapter card and your motherboard's 4pin USB header

Supports all PCIe standards, PCIe x1 bus connector installs into any size PCI Express slot

Fits both standard and low profile system chassis with the included full height and spare low profile brackets
Chipset:
Intel AX200
Complies with PCI Express 2.1 specification
Bus connector:
x1 PCI Express
Connector Type:
2 x 5dBi un-fixed and USB 4-Pin header (Bluetooth 5 operation)
Industry Standards:
IEEE802.11.ax, IEEE802.11.ac, IEEE802.11.n, IEEE802.11.b, IEEE802.11.g, IEEE802.11.a
Bluetooth:
Bluetooth 5.0
Security Methods:
WPA and WPA2 Personal and Enterprise, WPA3
Authentication Protocols:
802.1X EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0-MSCHAPv2(EAP-SIM, EAP-AKA, EAP-AKA)
Encryption:
64-bit and 128-bit WEP, TKIP, 128-bit AES-CCMP, 256-bit AES-GCMP
Data Rates:
5G up to 2.4G (802.11ax 160MHz) / 2.4G up to 574M
Product:
Color:
Black
Connectors:
2 x 5dBi un-fixed and USB 4-Pin header
Environmental conditions:
Operating temperature:
32 to 140 degrees F
Storage temperature:
-14 to 158 degrees F
Relative humidity:
5% to 90% RH (non-condensing)
Certifications/Standards:
FCC, CE, RoHS Item Dimension (L"x W"x H")
3 x 5 x 1
Weight
1.00 LB
Warranty Information
1 Year


Package Contents:

• WiFi 6 Dual Band Ethernet PCIe Card - AC3000
• Full Height and Spare Low Profile Brackets
• USB 4-pin Cable
• 2 x Antenna
• Driver CD
• Quick Start Guide
