Silverstone SST-HA2050-PT Hela 2050 Platinum - Power Supply - 2050 Watt
(No reviews yet)
Write a Review
- SKU:
- 20483652
- MPN:
- sst-ha2050-pt
- Availability:
- Out of stock
- Stock Update:
- 01/14/2026 01:37:19 PM PST
- Stock Update:
- 01/14/2026 01:37:19 PM PST
Description
This item is brand-new, factory sealed.
Product No.SST-HA2050-PT Max. DC Output: 2050W Power density: 882W per liter Combined +3.3V & +5V: 120W Combined +12V: 2040W Input Voltage: 2050W: 200~240 Vrms | 1650W: 103 ~ 264 Vrms Input Frequency Range: 47Hz ~ 63Hz PFC: Active PFC (PF>0.95 at full load) Efficiency: =89% & <91% overall efficiency MTBF: 100,000 hours Operating temperature: 0C ~ 50C Protection: Over Current Protection Over Power Protection Over Voltage Protection Short Circuit Protection Over Temperature Protection Connectors: 1 x 24 / 20-Pin motherboard connector 2 x 8 / 4-Pin EPS / ATX 12V connectors 1 x 12-Pin GPU connector 18 x 8 / 6-Pin PCIe connectors 12 x SATA connectors 3 x 4-Pin Peripheral connectors 1 x 4-Pin Floppy connector Cooling System: 135mm dual ball bearing fan Form factor: ATX (PS2) Noise Level: 0 dBA minimum Dimension: 150 mm (W) x 86 mm (H) x 180 mm (D) 5.91" (W) x 3.39" (H) x 7.09" (D) Weight: 4.34 kg Certification: Cybenetics Platinum Other: Switch on rear side to activate / de-activate semi-fanless mode GPU Support list Compatible with ATX12V v2.52Compact and high density design with a depth of 180mm for easy integration Intel ATX12V 2.52 support Built-in MCU semi-fanless mode to achieve optimized cooling performance 2050W 24/7 continuous power output with 50 operating temperature Super flexible black flat cables 100% modular cables 12-Pin GPU connector support
Features
Certifications & Standards:
China
- TUV
- CE
- FCC
- UKCA
- EAC
- CCC
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
China Restriction of Hazardous Substances (China RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin:
China
Specs
| Power Description | |
| Input Frequency | 63Hz |
| Number of +12V Rails | 1 |
| Output Power | 2050 W |
| Input Voltage | 230 V AC |
| Output Voltage Detail |
|
| Output Voltage |
|
| Physical Characteristics | |
| Form Factor | ATX PS/2 |
| Weight (Approximate) | 9.57 lb |
| Product Color | Black |
| Height | 3.4" |
| Color Family | Black |
| Width | 5.9" |
| Depth | 7.1" |
| Warranty | |
| Limited Warranty | 5 Year |
| Interfaces/Ports | |
| Number of (6+2 pin) PCI Express Power Connectors | 12 |
| Number of (4+4 pin) CPU Power Connectors | 2 |
| Number of SATA Power Connectors | 12 |
| PCI Express Connector | Yes |
| General Information | |
| Brand Name | SilverStone |
| Manufacturer Website Address | http://www.silverstonetek.com |
| Marketing Information | Designed for Cybenetics Platinum level of efficiency to reduce wasted heat and save on electricity 180mm depth sets new standard for high wattage PSUs with modular cables Complies with Intel ATX12V V2.52 power supply design guide to support the latest Intel / AMD CPUs with stable and plentiful power to your system Fully modular design with universal EPS / PCIe connector interface. Flat cables have much greater fl Japanese electrolytic capacitors / ±3% regulation and low ripple & noise performance for high stability A built-in intelligent fan controller (microcontroller unit, MCU) enables the HELA 2050 Platinum to operate quietly during idle or low powered computing activities while ramping up for maximum cooling during stress and max loads 12-Pin GPU connector support Advanced protections for safety and security Over current protection Over power protection Over voltage protection Short circuit protection Over temperature protection |
| Product Type | Power Supply |
| Product Name | SST-AX2050MCPT-A 2050W Power Supply |
| Manufacturer | SilverStone Technology, Inc |
| Manufacturer Part Number | SST-HA2050-PT |
| Product Model | SST-AX2050MCPT-A |
| Technical Information | |
| Fan Diameter | 135 mm |
| Specification Compliance | ATX12V v2.52 |
| Efficiency | 89% |
| Number of Fans | 1 |
| Fan Bearing Type | Dual Ball Fan Bearing |
| Protection Type |
|
| Features | Compact |
| Modular | Yes |
| Power Factor Correction (PFC) | Active |
| Reliability | |
| MTBF | 100000 Hour |
| Environmental Conditions | |
| Maximum Operating Temperature | 122°F (50°C) |
| Minimum Operating Temperature | 32°F (0°C) |
