StarTech Industrial Gigabit PoE Injector - High Speed 90W 802.3bt PoE++ 48V-56VDC Ultra Power Over Ethernet/UPoE Injector -40C to +75C (248816)
- SKU:
- 18213592
- MPN:
- 248816
- Availability:
- Usually ships the same or next business day. In stock at our CA, IN, MS, NJ, TX warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 02/02/2026 03:44:55 AM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 4 or above | and pay only $248.57 each 248.57 |
- Stock Update:
- 02/02/2026 03:44:55 AM PST
Description
This item is brand-new, factory sealed.
Industrial Gigabit PoE Injector - High Speed/High Power 90W - 802.3bt PoE++ 48V-56VDC DIN Rail UPoE/Ultra Power Over Ethernet Injector Adapter -40C to +75C Rugged (POEINJ1G90W)- WIDE STANDARD COMPATIBILITY: High speed Industrial Gigabit PoE Injector compatible w/ IEEE 802.3bt (PoE++) & previous 90W proprietary POE standards including PoH (HDBase-T), Cisco uPoE, Bosch & AXIS
- 90W POWER BUDGET: Provides up to 90W of auto-negotiated power output for Type 3 and Type 4 PoE/Ultra/UPoE applications like tilt and pan cameras and high power IEEE 802.11ax wireless access points
- TECH SPECS: 1 Gbps | 48V-56VDC Power Input | IEEE 802.3af | IEEE 802.3at | IEEE 802.3bt 90W max | PoH (HDBase-T) | uPoE | 10/100/1000 Mbps Auto Negotiation | DIN/Wall Mountable | Redundant Power Input
- ROBUST DESIGN: Industrial Power over Ethernet Injector w/MTBF of 500,000+hrs @ 50C | Vibration, shock & free fall rated | Rugged IP-30 aluminum housing | Hardened operating temp of -40C to 75C
- STARTECH.COM ADVANTAGE: IT professionals' choice for over 30 years | This PoE Injector is backed for 2-years by StarTech.com, including free 24/5 North America based multi-lingual tech support
- Brand: StarTech
- Item Weight: 13.4 ounces
- Product Dimensions: 7.5 x 9 x 3 inches
- Item Dimensions LxWxH: 7.5 x 9 x 3 inches
- Voltage: 48 Volts
- Manufacturer: STARTECH.COM
This Gigabit Power over Ethernet (PoE+) injector supplies power and data connectivity to a Gigabit PoE-compliant device using a standard Ethernet cable.
Flexible Configurations for a Variety of ApplicationsCompatible with IEEE 802.3bt and most previous 90W proprietary PoE (Ethernet) standards, including PoH (HDBaseT), Cisco uPoE, Bosch, and AXIS. One product can cover multiple use requirements to improve standardization and deployment and dual power terminal block inputs provide redundancy for critical applications.
90 Watt Power BudgetAs many typical PoE-enabled switches max out at 30W a high 90W power budget is perfect for demanding Type 3 and Type 4 PoE applications like tilt and pan cameras and high power IEEE 802.11ax wireless access points.
Designed for Harsh EnvironmentsIndustrial features include -40 C to 75 C operating temperature, IP-30 rated housing, vibration, shock, and free-fall standard testing.
- Vibration: EN 60068-2-6
- Shock: EN 60068-2-27
- Free-fall: EN 60068-2-32
500,000+ hours MTBF rating using Telcordia/Bellcore at 50C for long-term reliability.
The POEINJ1G90W is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Package Contents:
- POEINJ1G90W PoE Injector
- Mounting Hardware Kit
- Quick-Start Guide
- Terminal Block
Features
Yes
WEEE Statement:
https://media.startech.com/cms/pdfs/poeinj1g90w_weee.pdf
EU RoHS Declaration URL:
https://media.startech.com/cms/pdfs/poeinj1g90w_rohs.pdf
Package Contents:
- POEINJ1G90W PoE Injector
- Mounting Hardware Kit
- Quick-Start Guide
- Terminal Block
Certifications & Standards:
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.3at
- IEEE 802.3af
- IEEE 802.3bt
- IEC 61000-4-2
- IEC 61000-4-4
- IEC 61000-4-5
- EN60950-1
- IP-30
- EN 60068-2-6
- EN 60068-2-27
- EN 60068-2-32
Environmental Certification:
EU RoHS
Environmentally Friendly:
Yes
REACH Declaration URL:
https://media.startech.com/cms/pdfs/poeinj1g90w_rohs.pdf
REACH free of SVHC:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS) 2
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin:
Taiwan
Specs
| Power Description | |
| Input Voltage | 56 V DC |
| Physical Characteristics | |
| Form Factor | DIN Rail/Wall Mountable |
| Weight (Approximate) | 6.14 oz |
| Length | 3.2" |
| Product Color | Black |
| Height | 4.1" |
| Color Family | Black |
| Width | 1.3" |
| Warranty | |
| Limited Warranty | 2 Year |
| Interfaces/Ports | |
| Output Ports | 1 x PoE+ |
| Input Ports | 1 x Gigabit Ethernet |
| General Information | |
| Brand Name | StarTech.com |
| Manufacturer Website Address | http://www.startech.com |
| Marketing Information | Gigabit Power over Ethernet (PoE+) injector supplies power and data connectivity to a Gigabit PoE-compliant device using a standard Ethernet cable. Flexible Configurations for a Variety of Applications Compatible with IEEE 802.3bt and most previous 90W proprietary PoE (Ethernet) standards, including Cisco uPoE, Bosch, and AXIS. One product can cover multiple use requirements to improve standardization and deployment and dual power terminal block inputs provide redundancy for critical applications. 90 Watt Power Budget As many typical PoE-enabled switches max out at 30W a high 90W power budget is perfect for demanding Type 3 and Type 4 PoE applications like tilt and pan cameras and high power IEEE 802.11ax wireless access points. Designed for Harsh Environments Industrial features include -40 C to 75 C operating temperature, IP-30 rated housing, vibration, shock, and free-fall standard testing. Vibration: EN 60068-2-6 Shock: EN 60068-2-27 Free-fall: EN 60068-2-32 500,000+ hours MTBF rating using Telcordia/Bellcore at 50C for long-term reliability. More from the Manufacturer More from the Manufacturer |
| Product Type | PoE Injector |
| Product Name | POEINJ1G90W PoE Injector |
| Manufacturer | StarTech.com |
| Manufacturer Part Number | POEINJ1G90W |
| Product Model | POEINJ1G90W |
| Packaged Quantity | 1 Each |
| Technical Information | |
| Protection Type | Surge Protection |
