StarTech HDMI Extender over CAT6/CAT5 EXTENDHDMI4K40C6P1

This item is brand-new, factory sealed.

4K HDMI Extender over CAT6/CAT5 Ethernet Cable, 4K 30Hz or 1080p 60Hz Video Extender, HDMI over Ethernet Cable, HDMI Transmitter and Receiver Kit, IR Remote Control
4K 30Hz 130ft 1080p 230ft IR Extension Power over Cable
Product ID: EXTEND-HDMI-4K40C6P1
HDMI OVER ETHERNET CABLE: This HDMI Extender over CAT6/5e sends 4K 30Hz up to 130ft (40m) or 1080p up to 230ft (70m) 7.1ch Audio 4:4:4 Chroma Subsampling HDCP 1.4 Metal Housing with mounting brackets IR Extension kit incl.
SINGLE POWER ADAPTER: The power adapter connects to the HDMI Extender Kits transmitter and powers the receiver for areas where power outlets may be limited Power is delivered to the receiver over the Ethernet cable using Power over Cable (PoC)
VERSATILE FUNCTIONALITY: The Transmitters HDMI output can be used to connect a local display or cascaded to another HDMI extender The 4K HDMI extender over Ethernet cable is ideal for displaying video over CAT6 for digital signage in malls, stadiums and hospitals
IR EXTENSION: The HDMI CAT6/5e Extender includes a IR Control Extension Kit with 1x IR Blaster and 1x IR Receiver (IR remote not included) IR Blaster/Receiver have adhesive for easy installion Control your IR devices from a remote location (receiver)
EASY INSTALLATION: No IP configuration, software, or drivers required Durable metal housing and built-on mounting brackets make it ideal for many environments Point-to-Point transmitter to receiver connection, using a single CAT6/5e cable
This HDMI Extender over CAT6 lets you transmit a 4K 30Hz HDMI audio video signal up to 130ft (40m), or 230ft (70m) for 1080p resolutions. This converter kit includes both the transmitter and receiver for a complete end-to-end solution.Compatibility
OS IndependentSpecifications
Connector(s)
Local Unit Connectors
1 HDMI
1 - HDMI
1 - RJ-45
1 - 3.5mm Stereo Female 3 pos
Remote Unit Connectors
1 - HDMI
1 - RJ-45
1 - 3.5mm Stereo Female 3 posEnvironmental
Operating Temperature
0^oC to 40^oC (32^oF to 104^oF)
Storage Temperature
-20^oC to 60^oC (-4^oF to 140^oF)
Humidity
20% - 90% RH (non-condensing)Hardware
Cabling
Cat 5e UTP or better
Audio
Yes
Rack-Mountable
No
Daisy-Chain
YesIndicators
LED Indicators
2 - Power LED
2 - Link LEDPerformance
Maximum Data Transfer Rate
10.2 Gbps
Max Distance
70 m / 230 ft
Maximum Digital Resolutions
CAT6 Up to 40m: 4K at 30 Hz
CAT6 Up to 70m: 1080p
CAT5e Up to 35m: 4K at 30 Hz
CAT5e Up to 60m: 1080p
Wide Screen Supported
Yes
Audio Specifications
HDMI - 7.1 Channel AudioPhysical Characteristics
Color
BlackPower
Power Source
AC Adapter Included
Input Voltage
100 - 240 AC
Input Current
0.3 A
Output Voltage
12V DC
Output Current
1 A
Center Tip Polarity
Positive
Plug Type
M
Power Consumption (In Watts)
WWhats in the Box
Included in Package
1 - Local HDMI Transmitter Unit
1 - Remote HDMI Receiver Unit
1 - IR Blaster
1 - IR Receiver
1 - Power Adapter
1 - Quick-Start GuideCompliance and Certifications
RoHS and REACH Certificate of Compliance
CE
Waste Electrical and Electronic Equipment Directive (WEEE)
RCMItem Dimension (L"xW"xH")
5 x 8 x 3

Weight
1.14 lbs

Warranty Information
2 Year Warranty
