StarTech 1-Port 2.5GbE PoE+ Injector AF212CPOEINJECTOR
- SKU:
- 20799906
- MPN:
- af212c-poe-injector
- Availability:
- Usually ships the same or next business day. In stock at our GA, IL, PA warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 03/29/2026 04:08:48 AM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 | and pay only $60.31 each 60.31 |
| Buy 3 | and pay only $56.28 each 56.28 |
| Buy 4 or above | and pay only $55.07 each 55.07 |
- Stock Update:
- 03/29/2026 04:08:48 AM PST
Description
This item is brand-new, factory sealed.
StarTech.com 1-Port 2.5GbE PoE+ Injector, 10M/100M/1G/2.5G Ethernet, PoE/PoE+ (802.3af/802.3at), Multi-Gigabit, Midspan, 30W- 2.5GbE POE INJECTOR: Multi-gigabit single port midspan PoE+ injector supports up to 2.5Gbps with auto-negotiation; TAA-compliant Power Sourcing Equipment supports up to 30W PoE/PoE+; Features level-4 ESD protection for reliable performance and durability
- NETWORK FLEXABILITY: Auto-negotiation between 2.5Gbps & 10/100/1000Mbps Ethernet; Deliver data/power to PoE devices up to 328ft/100m w/Cat5/5e/6/6a cabling; Unmanaged inline injector w/built-in LAN transformer for electrical isolation; 2K surge protection
- HASSLE-FREE INSTALLATION: Integrated anchor points for surface mounting; Streamline deployment without additional software/settings; Connect the PoE injector to the network (e.g., switch or router) & the remote PD via standard Cat5/e or Cat6/6a cabling
- APPLICATIONS: Enable data & power over a single RJ45 connection in high end enterprise access points such as high resolution IP cameras; Maintain existing network infrastructure while adding PoE functionality to support remote devices
- TECH SPECS: x2 RJ45 ports (data/data+power); 54VDC 0.6A output; 30W max output; Compliant with IEEE 802.3af and 802.3at; 10M/100M/1G/2.5G with auto negotiation; WoL/PXE/9K jumbo frames; Wall mountable; Dimensions 4x2.3x1.3-inch (100x58.4x33.4mm)
- Brand: ?StarTech.com
- Item model number: ?AF212C-POE-INJECTOR
- Item Weight: ?12.8 ounces
- Product Dimensions: ?3.6 x 2.3 x 1.3 inches
- Item Dimensions LxWxH: ?3.6 x 2.3 x 1.3 inches
- Color: ?Black
- Manufacturer: ?StarTech.com
The Power over Ethernet (PoE) Injector's unmanaged design speeds deployment and provides seamless integration into a network infrastructure, delivering 2.5GbE speeds using a single Cat5 (or better) cable for network data and power transmission up to 328ft (100m). PoE and PoE+ compatibility and speeds of 10Mbps, 100Mbps, 1Gbps, and 2.5Gbps ensure effortless connectivity to Powered Devices (PD) such as IP cameras, access control devices, POSs, wireless access points, and digital signage. This multi-gigabit versatile midspan PoE Injector adheres to IEEE 802.3af and 802.3at delivering up to 54V DC and 0.6A (30 Watts), eliminating the need for a separate power source. Level-4 ESD protection (15kV air and 8kV contact) and LAN transformer enhance device safety and maintain signal quality with reduced EMI. Integrated anchor points allow for surface and wall mounting. This TAA-compliant PoE adapter is backed for 2-years, including free lifetime 24/5 multi-lingual technical assistance.
Package Contents:
- AF212C-POE-INJECTOR
- 1 x 6ft (1.8m) NA Power Cord
- 1 x Quick-Start Guide
Features
- AF212C-POE-INJECTOR
- 1 x 6ft (1.8m) NA Power Cord
- 1 x Quick-Start Guide
Certifications & Standards:
- IEEE 802.3af
- IEEE 802.3at
- IEEE 802.3ab
- IEEE 802.3u
- IEEE 802.3i
- IEEE 802.3bz
- IEC 61000-4-2
TAA Compliant:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Specs
| Power Description | |
| Maximum Output Voltage | 54 V DC |
| Maximum Output Current | 600 mA |
| Maximum Output Power | 30 W |
| Input Voltage |
|
| Maximum Input Current | 800 mA |
| Physical Characteristics | |
| Form Factor | Wall/Surface Mountable |
| Weight (Approximate) | 3.50 oz |
| Length | 3.9" |
| Product Color | Black |
| Mount Type | Wall/Surface Mountable |
| Height | 1.3" |
| Color Family | Black |
| Width | 2.3" |
| Warranty | |
| Limited Warranty | 2 Year |
| Interfaces/Ports | |
| Output Ports | 1 x RJ-45 |
| Input Ports | 1 x PoE+ |
| General Information | |
| Brand Name | StarTech.com |
| Manufacturer Website Address | http://www.startech.com |
| Marketing Information | This 1-port 2.5GbE PoE+ Injector serves as a Power Sourcing Equipment (PSE) device and enables Ethernet speeds of 10Mbps, 100Mbps, 1Gbps, and 2.5Gbps. This TAA-compliant midspan inline injector can transmit network data and power up to 328ft (100m) for remote Powered Devices (PD). Versatile PoE Injector Multi-Gigabit single port PoE injector supports the IEEE 802.3af and 802.3at PSE standards, and delivers up to 30W output (54V DC, 0.6A). This enables seamless data and power transmission over Cat5/5e/6/6a to remote Powered Devices (PD) such as IP cameras, access control devices, remote kiosks (POSs), wireless access points (APs), PoE lighting, and digital signage. A built-in LAN Transformer reduces EMI to maintain strong, reliable signal strength across different environments. Streamlined Cable Management All Ethernet cables can be routed from one side of the unit for efficient and organized cable management. The compact design (4x2.3x1.3-inch-100x58.4x33.4 mm) ensures straightforward integration into existing network infrastructure, saving space and time during installation. Integrated anchor points allow for surface and wall mounting. |
| Product Type | PoE+ Injector |
| Product Name | AF212C-POE-INJECTOR |
| Manufacturer | StarTech.com |
| Manufacturer Part Number | AF212C-POE-INJECTOR |
| Packaged Quantity | 1 |
| Technical Information | |
| Protection Type |
|
