Startech Usb Hdmi Over Cat 5e / Cat 6 Kvm Console Extender W/ 1080p Uncompressed Video - 330ft [100m] - 1 Computer[s] - 1 Local User[s] - 330 Ft Range - 2 X Network [rj-45] - 4 X Usb (sv565utphdu)
- SKU:
- 18149634
- MPN:
- sv565utphdu
- Availability:
- Usually ships the same or next business day. In stock at our IL, SC, TX warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 02/11/2026 03:31:23 AM PST
- Stock Update:
- 02/11/2026 03:31:23 AM PST
Description
This item is brand-new, factory sealed.
The SV565UTPHDU USB HDMI® KVM Extender lets you control a PC from up to 330ft (100m) away over a single Cat 5e or Cat 6 cable connection, with uncompressed 1080p HDMI video and access to up to 3 connected USB devices.
A flexible solution for powering large high-definition displays remotely, this HDMI USB extender supports uncompressed 1080p or 1920x1200 video resolutions at maximum distance. Additional features such as 3D and 4K support, HDCP, CEC and Lip Sync pass-through enable you to display your content exactly as you need it on the remote display.
This versatile KVM console extender can be connected to a single system, or cascaded to an existing KVM switch for remote operation of multiple systems, and features 3 USB 2.0 ports on the remote end, allowing you to connect a keyboard, mouse, printer or other peripherals. Since the extender uses Cat 5e (or better) network cable, you have the option to use existing infrastructure wiring, which helps avoid the hassle and expense of running bulky video cables.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Package Contents:
- Local Extender Unit
- Remote Extender Unit
- HDMI Cable
- USB Cable
- Universal Power Adapters (NA/EU/UK)
- Instruction Manual
Features
- 1 x Local Transmitter Unit
- 1 x Remote Receiver Unit
- 4 x Mounting Brackets
- 1 x HDMI Cable
- 1 x USB Cable
- 2 x Universal Power Adapters (NA, EU ,UK)
- 1 x Quick-start guide
Certifications & Standards:
- CE
- FCC
- UL
Environmentally Friendly:
Yes
Country of Origin:
Canada
Specs
| Power Description | |
| Input Voltage Range | 100V AC to 240V AC |
| Input Voltage |
|
| Power Consumption | 15 W |
| Physical Characteristics | |
| Transmitter Weight (Approximate) | 1.87 lb |
| Receiver Width | 4.40" |
| Receiver Height | 1.20" |
| Product Color | Black |
| Receiver Depth | 6.90" |
| Transmitter Depth | 6.90" |
| Receiver Weight (Approximate) | 1.87 lb |
| Color Family | Black |
| Transmitter Height | 1.20" |
| Transmitter Width | 4.40" |
| Warranty | |
| Limited Warranty | 2 Year |
| Interfaces/Ports | |
| Number of USB Ports | 6 |
| Network (RJ-45) | Yes |
| Number of HDMI Ports | 2 |
| USB | Yes |
| HDMI | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Video | |
| Maximum Video Resolution | 1920 x 1200 |
| Graphic Mode | WUXGA |
| General Information | |
| Brand Name | StarTech.com |
| Manufacturer Website Address | http://www.startech.com |
| Marketing Information | The SV565UTPHDU USB HDMI® KVM Extender lets you control a PC from up to 330ft (100m) away over a single Cat 5e or Cat 6 cable connection, with uncompressed 1080p HDMI video and access to up to 3 connected USB devices. A flexible solution for powering large high-definition displays remotely, this HDMI USB extender supports uncompressed 1080p or 1920x1200 video resolutions at maximum distance. Additional features such as 3Dsupport, HDCP, CEC and Lip Sync pass-through enable you to display your content exactly as you need it on the remote display. This versatile KVM console extender can be connected to a single system, or cascaded to an existing KVM switch for remote operation of multiple systems, and features 3 USB 2.0 ports on the remote end, allowing you to connect a keyboard, mouse, printer or other peripherals. Since the extender uses Cat 5e (or better) network cable, you have the option to use existing infrastructure wiring, which helps avoid the hassle and expense of running bulky video cables. Backed by a StarTech.com 2-year warranty and free lifetime technical support. More from the Manufacturer More from the Manufacturer |
| Product Type | KVM Console/Extender |
| Product Name | KVM Console/Extender |
| Manufacturer | StarTech.com |
| Manufacturer Part Number | SV565UTPHDU |
| Packaged Quantity | 1 Kit |
| Technical Information | |
| Number of Computers Supported | 1 |
| Maximum Operating Distance | 330 ft |
| Connectivity Technology | Wired |
| Number of Local Users Supported | 1 |
