TP-LINK TL-SF1048 - 48 Port 10/100Mbps Fast Ethernet Switch - Limited Lifetime Warranty
(No reviews yet)
Write a Review
- SKU:
- 18134505
- MPN:
- tl-sf1048
- Availability:
- Out of stock
- Stock Update:
- 04/30/2025 05:55:06 PM PST
- Stock Update:
- 04/30/2025 05:55:06 PM PST
Description
This item is brand-new, factory sealed.
The TL-SF1048 Ethernet Switch provides 48 10/100M Auto-Negotiation RJ45 ports. All RJ45 ports support the Auto-MDI/MDIX function. Every port can works as uplink port or common port. TL-SF1048 Ethernet Switch provides a cost-effective, high performance, non-disruptive, smooth evolution into 100M solution. The Switch delivers superior performance with improving workgroup, network bandwidth, increasing network node, providing greater flexibility, installation convenience.FeaturesSupports IEEE 802.3x flow control for Full Duplex mode and backpressure for half-duplex modeSupports MAC address auto-learning and auto-agingLED indicators for monitoring power, link, activity, 100MbpsStandard 19-inch rack-mountable steel caseInternal universal power supplySpecificationsStandards and Protocols : IEEE802.3, 802.3u, 802.3x, CSMA/CD, TCP/IPBasic Function : Wire-speed Performance MAC Address Auto-Learning and Auto-agingIEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex ModeBackbound Bandwidth : 9.6GbpsMAC Address Table : 8kForwarding Rate : 10BASE-T: 14880pps/port 100BASE-TX: 148800pps/portTransmission Method : Store-and-ForwardPorts : 48 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX)Network Media : 10Base-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100U STP (maximum 100m)100Base-Tx: UTP category 5, 5e cable (maximum 100m)EIA/TIA-568 100U STP (maximum 100m)LED Indicators : Power, Link/ActSafety and Emission : FCC, CEEnvironment : Operating Temperature: 0C-40C (32F-104F)Storage Temperature: -40C-70C (-40F-158F)Operating Humidity: 10%-90% non-condensing Storage Humidity: 5%-90% non-condensingPower : 100-240VAC, 50/60HzDimensions / WeightFeatures
Additional Information:
Yes
Transmission Method:
- Store-and-Forward
Environmentally Friendly:
Yes
Specs
| Management & Protocols | |
| Manageable | No |
| Power Description | |
| Power Source | Power Supply |
| Frequency |
|
| Power Consumption | 9.90 W |
| Physical Characteristics | |
| Form Factor |
|
| Height | 1.7" |
| Width | 17.3" |
| Depth | 10.2" |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 48 x Fast Ethernet Network |
| Total Number of Network Ports | 48 |
| Number of Network (RJ-45) Ports | 48 |
| General Information | |
| Brand Name | TP-Link |
| Manufacturer Website Address | http://www.tp-link.com/us |
| Marketing Information | The TL-SF1048 Ethernet Switch provides 48 10/100M Auto-Negotiation RJ45 ports. All RJ45 ports support the Auto-MDI/MDIX function. Every port can works as uplink port or common port. TL-SF1048 Ethernet Switch provides a cost-effective, high performance, non-disruptive, smooth evolution into 100M solution. |
| Product Type | Ethernet Switch |
| Product Name | TL-SF1048 48-Port Rackmount Switch |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | TL-SF1048 |
| Product Model | TL-SF1048 |
| Media & Performance | |
| Ethernet Technology | Fast Ethernet |
| Media Type Supported | Twisted Pair |
| Network Technology | 10/100Base-TX |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards |
|
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
