Transition Networks Unmanaged Hardened Gigabit Ethernet PoE+ Switch with Low Voltage Input (sistp1040-382b-lrt)
- SKU:
- 18469810
- MPN:
- sistp1040-382b-lrt
- Availability:
- Out of stock
- Stock Update:
- 10/23/2023 10:48:05 AM PST
- Stock Update:
- 10/23/2023 10:48:05 AM PST
Description
This item is brand-new, factory sealed.
This switch is an unmanaged full Gigabit Ethernet hardened PoE+ switch that complies with IEEE 802.3at and IEEE 802.3af. The switch has (8) 10/100/1000Base-T PoE+ ports with (2) 100/1000 dual speed SFP slots. In many fields such as Vehicle, Factory or Solar systems, there are no standard power input requirements of 52 to 57 volts for PoE devices. The SISTP1040-382B-LRT uses booster technology to allow the user to deploy the PoE switches in the power input range of 12 to 24 volts. It can still deliver up to 30 Watts on each PoE+ port. The two fiber uplink ports can also be used in a daisy chain for maximum network reliability. It has redundant input power connections to ensure safe reliable operation in temperatures between -40°C and +70°C. Transition Networks' hardened switches are certified to operate reliably in harsh environments such as those found on factory floors, outdoor enclosures or other hazardous environments.
Package Contents:
- Unmanaged Hardened Gigabit Ethernet PoE+ Switch with Low Voltage Input
- Din Rail Bracket
Features
TAA Compliant:
Yes
Application/Usage:
Network
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin:
Taiwan
Specs
| Management & Protocols | |
| Manageable | No |
| Power Description | |
| Redundant Power Supply Supported | Yes |
| Power Source |
|
| PoE Budget | 120 W |
| PoE (RJ-45) Port | Yes |
| Physical Characteristics | |
| Form Factor |
|
| Weight (Approximate) | 1.01 lb |
| Height | 1.7" |
| Width | 5.3" |
| Depth | 5.1" |
| Warranty | |
| Limited Warranty | 5 Year |
| Interfaces/Ports | |
| Port/Expansion Slot Details |
|
| Total Number of Network Ports | 8 |
| Modular | Yes |
| I/O Expansions | |
| Total Number of Expansion Slots | 2.0 |
| Number of SFP Slots | 2 |
| Expansion Slot Type | SFP (mini-GBIC) |
| General Information | |
| Brand Name | Transition Networks |
| Manufacturer Website Address | http://www.transition.com |
| Marketing Information | This switch is an unmanaged full Gigabit Ethernet hardened PoE+ switch that complies with IEEE 802.3at and IEEE 802.3af. The switch has (8) 10/100/1000Base-T PoE+ ports with (2) 100/1000 dual speed SFP slots. In many fields such as Vehicle, Factory or Solar systems, there are no standard power input requirements of 52 to 57 volts for PoE devices. The SISTP1040-382B-LRT uses booster technology to allow the user to deploy the PoE switches in the power input range of 12 to 24 volts. It can still deliver up to 30 Watts on each PoE+ port. The two fiber uplink ports can also be used in a daisy chain for maximum network reliability. It has redundant input power connections to ensure safe reliable operation in temperatures between -40°C and +70°C. Lantronix' hardened switches are certified to operate reliably in harsh environments such as those found on factory floors, outdoor enclosures or other hazardous environments. NDAA Compliant, TAA Compliant |
| Product Type | Ethernet Switch |
| Product Name | Unmanaged Hardened Gigabit Ethernet PoE+ Switch with Low Voltage Input |
| Manufacturer | Lantronix, Inc |
| Manufacturer Part Number | SISTP1040-382B-LRT |
| Product Model | SISTP1040-382-LRT |
| Media & Performance | |
| Ethernet Technology | Gigabit Ethernet |
| Media Type Supported |
|
| Network Technology |
|
| Network & Communication | |
| Layer Supported | 2 |
| Technical Information | |
| Features | IP30 |
