Tripp Lite 18u Wall Mount Rack Enclosure Cabinet Side Mount - Heavy Duty Wallmount - Black (srw18uhd)
(No reviews yet)
Write a Review
- SKU:
- 18152761
- MPN:
- srw18uhd
- Availability:
- Usually ships in 2-3 business days. In stock at our IL, PA, TX warehouses.
- Shipping:
- $263.16 (Fixed Shipping Cost)
- Stock Update:
- 12/13/2025 06:16:15 AM PST
- Stock Update:
- 12/13/2025 06:16:15 AM PST
Description
This item is brand-new, factory sealed.
The SRW18UHD is a wall-mount, rack enclosure that can accommodate full server depth equipment (29"-31") but only protrudes off the wall 24". Since the equipment is mounted in the wall cabinet sideways, the leverage off the wall is less and the weight capacity is increased greatly. Access to mounted equipment is still great due to full access doors on each side of the cabinet (for front and rear equipment access) and one full removable side panel for access along the length of the mounted equipment. Adjustable front and rear mounting rails have square holes (default position) and tapped holes to accommodate 18U of equipment.
Package Contents:
- SmartRack Heavy-Duty Side-Mount Wall-Mount Rack Enclosure Cabinet
- 42 x M6 Cage Nuts
- 42 x M6 Equipment Mounting Screws
- 42 x M6 Washers
- 42 x 12-24 Equipment Mounting Screws
- 1 x Key Set
- Owner's Manual
Features
Package Contents:
EIA-310-E
Yes
Restriction of Hazardous Substances (RoHS)
China
- SmartRack Heavy-Duty Side-Mount Wall-Mount Rack Enclosure Cabinet
- 42 x M6 Cage Nuts
- 42 x M6 Equipment Mounting Screws
- 42 x M6 Washers
- 42 x 12-24 Equipment Mounting Screws
- 1 x Key Set
- Owner's Manual
Certifications & Standards:
EIA-310-E
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Country of Origin:
China
Specs
| Physical Characteristics | |
| Form Factor | Wall Mountable |
| Weight (Approximate) | 119.90 lb |
| Rack Width | 19" |
| Product Color | Black |
| Rack Depth | 32.50" |
| Static/Stationary Weight Capacity | 500 lb |
| Height | 37" |
| Color Family | Black |
| Width | 24.8" |
| Depth | 36.2" |
| Rack Height | 18U |
| Warranty | |
| Limited Warranty | 5 Year |
| General Information | |
| Brand Name | Tripp Lite series |
| Manufacturer Website Address | http://www.eaton.com |
| Marketing Information | The SRW18UHD SmartRack 18U Heavy-Duty Low-Profile Server-Depth Side-Mount Wall-Mount Rack Enclosure Cabinet is designed to house EIA-standard 19-inch rack equipment in network wiring closets, retail locations, classrooms, back offices and other areas with limited floor space where you need equipment to be secure, organized and out of the way. Constructed from heavy-duty steel with a durable black powder-coated finish, the cabinet has a maximum load capacity of 500 pounds.Because the low-profile cabinet mounts sideways, it extends less than 25 inches from the wall while housing equipment up to 32.5 inches deep, including 1U servers, UPS systems, battery packs, network switches and patch panels. The removable front panel and side doors lock securely to help prevent damage, tampering or theft. The top, bottom and sides are vented, which allows air to flow freely and keep equipment cool. Convenient top and bottom ports allow easy cable routing.The SRW18UHD comes fully assembled and ready to mount to the wall. Square and threaded mounting holes and numbered rack spaces make equipment installation easy. The vertical mounting rails adjust in 7/8-inch increments. More from the Manufacturer |
| Product Type | Rack Cabinet |
| Product Name | SmartRack Heavy-Duty Side-Mount Wall-Mount Rack Enclosure Cabinet |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SRW18UHD |
| Product Model | SRW18UHD |
| Product Line | SmartRack |
| Technical Information | |
| Front Rail | Yes |
| Application/Usage | Server |
| Features |
|
| Rear Rail | Yes |
