Tripp Lite 250W Isolation Transformer Hospital Medical with Surge 120V 2 Outlet HG TAA GSA (IS250HG)
(No reviews yet)
Write a Review
- SKU:
- 18140310
- MPN:
- is250hg
- Availability:
- Usually ships the same or next business day. In stock at our CA warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 12/24/2025 06:15:57 PM PST
- Stock Update:
- 12/24/2025 06:15:57 PM PST
Description
This item is brand-new, factory sealed.
Isolator series ul60601-1 listed medical grade isolation transformers offer line isolation continuous noise filtering and enhanced common mode surge suppression. An internal low-impedance isolation transformer component offers 100% isolation from the input ac line. Full ul60601-1 medical-grade listing with hospital-grade plug and outlet receptacles makes isolator medical-grade transformers ideal for protection of sensitive electronic equipment in patient-care areas. Faraday shield reduces the cumulative leakage current of the isolator and connected equipment to levels less than 100 microamps. Secondary neutral-to-ground bonding virtually eliminates common mode noise providing an isolated neutral-ground reference for sensitive equipment and an inexpensive alternative to dedicated circuits and site electrical upgrades. Removes emi/rfi noise utility switching transients and harmonics generated by other on-site loads and utility or related surge conditions. Additional surge suppression components placed at the line input and output combined with full line isolation offer continuous filtering of a full range of power line noise in all modes. Active transformer filtering provides continuous common-mode noise rejection with no wearable parts. Unique ability to reduce surges in the worst of power environments to harmless levels. Reduces 6000v ieee587 cat a&b ring wave and combination wave test surges to only 0.5v common mode. Model is250hg includes 2 nema5-15r hospital-grade output receptacles a 6-ft. Power cord hospital-grade input plug circuit breaker overload protection and lighted power switch. Rugged all-metal unit housing; ships ready for placement in any industrial medical office or network environment. 2-year warranty.Package Contents:
- IS250HG
- IS250HG Isolation Transformer
- Instruction manual with warranty information
Features
Package Contents:
Yes
Taiwan
- IS250HG
- IS250HG Isolation Transformer
- Instruction manual with warranty information
Certifications & Standards:
- cUL
- UL 2601-1
- UL (UL Series AGIS250YWN)
TAA Compliant:
Yes
Additional Information:
- Transformer Type: Medical grade, low impedance transformer-based line isolation transformer
- Removes EMI/RFI noise, utility switching transients, load-generated harmonics and ground loops
- Reduces 6000V IEEE587 Cat A&B ring wave and combination wave test surges to only 0.5V common mode
- Suppression Joule Rating: 680 (510 input/170 output)
- Leakage Current: As low as 100 microamps
- Noise Suppression Rating: 35 to 65 DB
- Total Harmonic Distortion: Less than 1%
- Over Current Protection: 2A circuit breaker
- Cooling Method: Convection
- Efficiency: 96%
- Let-through Voltage (Ring Wave):
- L-N: 20 V
- L-G: 20 V
- N-G: 0.5 V
- Let-through Voltage (Combination Wave):
- L-N: 250 V
- L-G: 250 V
- N-G: 0.5 V
Country of Origin:
Taiwan
Specs
| Power Description | |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Maximum Line Current | 2.10 A |
| Physical Characteristics | |
| Form Factor | Tower |
| Height | 4.5" |
| Width | 4.8" |
| Depth | 7.8" |
| Warranty | |
| Limited Warranty | 2 Year |
| General Information | |
| Brand Name | Tripp Lite series |
| Manufacturer Website Address | http://www.eaton.com |
| Marketing Information | Isolator Series UL60601-1 Listed Medical Grade Isolation Transformers offer line isolation, continuous noise filtering and enhanced common mode surge suppression. An internal low-impedance isolation transformer component offers 100% isolation from the input AC line. Full UL60601-1 medical-grade listing with hospital-grade plug and outlet receptacles makes Isolator medical-grade transformers ideal for protection of sensitive electronic equipment in patient-care areas. Faraday shield reduces the cumulative leakage current of the Isolator and connected equipment to levels less than 100 microamps. Secondary neutral-to-ground bonding virtually eliminates common mode noise, providing an isolated neutral-ground reference for sensitive equipment, and an inexpensive alternative to dedicated circuits and site electrical upgrades. Removes EMI/RFI noise, utility switching transients and harmonics generated by other on-site loads and utility or lightning related surge conditions. Additional surge suppression components placed at the line input and output combined with full line isolation offer continuous filtering of a full range of power line noise in all modes. Active transformer filtering provides continuous common-mode noise rejection with no wearable parts. Unique ability to reduce surges in the worst of power environments to harmless levels. Reduces 6000V IEE More from the Manufacturer |
| Product Type | Isolation Transformer |
| Product Name | Isolator IS250HG Isolation Transformer |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | IS250HG |
| Product Model | IS250HG |
| Technical Information | |
| Power Rating | 250 VA |
| Output Receptacle Detail | 2 x NEMA 5-15R |
| Output Receptacle Type | NEMA 5-15R |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
