Tripp Lite SmartPro SMX2200XLRT2U 2200VA Tower/Rack-mountable UPS - 2200VA/1600W - 6 Minute Full Load - 8 x IEC 320-C13
- SKU:
- 18141984
- MPN:
- smx2200xlrt2u
- Availability:
- Out of stock
- Stock Update:
- 07/03/2025 11:50:07 AM PST
- Stock Update:
- 07/03/2025 11:50:07 AM PST
Description
This item is brand-new, factory sealed.
Tripp Lite's SMX2200XLRT2U intelligent, line-interactive rack/tower uninterruptible power supply prevents data loss, downtime and equipment damage due to power outages, voltage fluctuations and transient surges. Requires only two rack spaces (2U) in a standard rack enclosure. Large internal batteries offer 17 min. half-load runtime and 6 min. at full load. Runtime is expandable with optional BP48V24-2U or BP48V60RT-3U external battery packs. Maintains regulated 230V nominal output without using battery power during brownouts and overvoltages from 158-290V. 2200VA/1600W power handling capability and full-time sine wave output offers guaranteed compatibility with networking, telecom and other sensitive electronic applications. 8 C13 outlets including 3 load banks (1 outlet each) that are individually switchable via software interface to reboot select equipment on demand or shed less significant loads to extend battery runtime for more critical equipment. Supports simultaneous remote monitoring of UPS and site power conditions via built-in USB and DB9 monitoring ports. HID-compliant USB interface enables full integration with built-in power management and auto shutdown features of Windows and Mac OS X. Includes PowerAlert UPS monitoring and unattended shutdown software with complete cabling. Built-in accessory slot supports SNMP with optional SNMPWEBCARD
Package Contents:
- SmartPro SMX2200XLRT2U 2200VA Tower/Rack-mountable UPS
- SMX2200XLRT2U UPS System
- PowerAlert Software CD and cabling
- EPO cabling
- 3 IEC320 C13-to-C14 jumper cables
- Owner's manual with warranty information
Features
- SmartPro SMX2200XLRT2U 2200VA Tower/Rack-mountable UPS
- USB, Serial & EPO cabling
- 4 post rackmount installation kit
- Set of 3 C13/C14 power cables
- Instruction manual
Certifications & Standards:
- CE/IEC 62040
- FCC Class A (Emissions)
- GOST
- SASO
- TUV w/GS mark
Additional Information:
- Customized load management receptacles: 3 load banks (1 outlet per bank) that support load shedding and remote reboot on demand of locked network devices. Controllable via PowerAlert software to automatically switch off optional loads, like monitors, to increase available runtime for servers and other critical devices
- Switches: 2 front panel-mounted push-button switches for system enable, self-test and alarm cancel functions. Rear: set of input voltage dip switches to set unit to actual input voltage. Battery charge level dip switch to adjust UPS system's battery charge rate
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Country of Origin:
China
Specs
| Power Description | |
| Load Capacity (Watt) | 1920 W |
| Surge Energy Rating | 350 J |
| Input Voltage | 230 V AC |
| Circuit Breaker | Yes |
| Output Voltage |
|
| Load Capacity (VA) | 2200 VA |
| Input Current | 10.70 A |
| Waveform Type | Pure Sine Wave |
| Output Frequency | 60 Hz |
| Physical Characteristics | |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 68.75 lb |
| Height | 3.5" |
| Width | 17.5" |
| Depth | 19.5" |
| Rack Height | 2U |
| Warranty | |
| Limited Warranty | 2 Year |
| Controls/Indicators | |
| Status Indicators | Front panel LCD information and configuration screen offers detailed UPS and site power status and operating data, plus configuration of voltage, operating mode, alarm function and a variety of additional options |
| Interfaces/Ports | |
| USB | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
| Battery Information | |
| Backup/Run Time (Full Load) | 5 Minute |
| DC System Voltage | 48 V DC |
| Replaceable Battery | Yes |
| Battery Chemistry | Lead Acid |
| Hot Swappable | Yes |
| Backup/Run Time (Half Load) | 11.90 Minute |
| Typical Battery Recharge Time | 4.50 Hour |
| Battery Characteristics | Valve-regulated |
| General Information | |
| Brand Name | Tripp Lite series |
| Manufacturer Website Address | http://www.eaton.com |
| Marketing Information | Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for critical server, network and telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS) with built-in Auto-Voltage Regulation (AVR) actively corrects brownouts and overvoltages back to usable levels while maintaining a full battery charge in case of power failure. Tripp Lite's unique configuration excels in exceptionally poor-power environments with two separate levels of voltage boost to correct both slight undervoltages and severe brownout conditions. Interactive LCD interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Super-fast switchover from line to battery power occurs within milliseconds to maintain operation of connected equipment without interruption or reboot. 98% line-mode efficiency offers reduced heat emissions and operating costs. Network management interfaces support communications via USB, RS-232 and optional network management card option. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Network communications ports enable detailed monitoring of equipment load levels, self-test data and utility power conditions. PowerAlert UPS monitoring software is available via free download. Switched output load banks enable scheduled and real-time remote reboot and load shedding of select outlets. Emergency Power Off (EPO) interface. LCD display panel easily rotates for viewing in rackmount or tower configurations. Audible alarm with push-button momentary alarm-cancel and silent-mode configuration options. Programmable self-test. Field-replaceable, hot-swappable battery modules. |
| Product Type | Line-interactive UPS |
| Product Name | SmartPro SMX2200XLRT2U 2200VA Tower/Rack-mountable UPS |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SMX2200XLRT2U |
| Product Model | SMX2200XLRT2U |
| Product Line | SmartPro |
| Technical Information | |
| Receptacle Type | IEC 60320 C13 |
| Receptacle Detail | 8 x IEC 60320 C13 |
| Energy Saving | Greater than 95% efficiency - GREEN UPS; Individually controllable load banks |
| Phase | Single Phase |
| Plug/Connector Type | IEC 60320 C20 |
| EMI/RFI Noise Filter | Yes |
| Protection Type |
|
| Application/Usage |
|
| Emergency Power OFF | Yes |
| Transfer Time | 6 ms |
| AVR | Yes |
| Management | |
| Network Management | SNMP Manageable |
| Alarm |
|
| Environmental Conditions | |
| Thermal Dissipation | 47.18 W |
| Sound Emission (A-Weighted) | 45 dB(A) |
| Maximum Operating Temperature | 104°F (40°C) |
| Storage Temperature | 5°F (-15°C) - 122°F (50°C) |
