Tripp Lite 16-Port IP Rack Console Cat5 KVM Switch 19" LCD 1+1 User 1URM (B070-016-19-IP)
(No reviews yet)
Write a Review
- SKU:
- 18543358
- MPN:
- b070-016-19-ip
- Availability:
- Usually ships the same or next business day. In stock at our CA, IL, PA warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 02/22/2026 08:08:49 AM PST
- Stock Update:
- 02/22/2026 08:08:49 AM PST
Description
This item is brand-new, factory sealed.
Tripp Lites B070-016-19-IP, NetCommander Rackmount Console IP KVM switch, is a cost effective and highly flexible system for controlling up to 256 computers from either a single 19" display console, or, from a remote location. The number of connected computers can be increased by cascading additional Tripp Lite B072-008-1 or B072-016-1 KVM switches. Switching between attached servers can be accomplished via the On Screen Display (OSD) or Hotkey commands.Utilizing Tripp Lite B078-101-Series server interface units, KVM cabling is kept to a minimum via Cat5/5e/6 patch cables. Servers can be located up to 100 ft. from the switch.Password feature provides additional security to prevent unauthorized access to attached computers. All rackmount hardware is included, and is designed for easy, one person installation. Fits into any rack from 27" to 42" deep. 2-post rackmounting available using Tripp Lites B019-000. Compatible with all major operating systems. (Mac not compatible over IP) 1 year limited warranty.ConsoleYesPort Control
Hotkeys, OSDMax CPU
256PC/Server
VGA, USB or PS/2Cat5 KVM Switch
YesIP Remote Access
YES, BUILT ININPUT
Nominal input voltage description
Internal Switching 100-240 VAC 50/60HzPHYSICAL
Color
BlackStyle
1U RackmountLCD Monitor (in.)
19ENVIRONMENTAL
Relative Humidity
80% Non-condensing Relative HumidityCONNECTIONS
Ports
16FEATURES/SPECIFICATIONS
Autoscan (Y,N)
YAutoscan Duration
VariableWARRANTY
Features
Package Contents:
UL 60950-1 (USA), CAN/CSA (Canada), FCC Part 15 Class A, CE, IEC 60950-1
Yes
Yes
Taiwan
- NetCommander B070-016-19-IP 19" Rackmount LCD with KVM Switch
- Power Cord
- Serial Firmware Upgrade Cable
- KVM/Console Jumper Cable
- CD (Includes: Owner's Manual)
Certifications & Standards:
UL 60950-1 (USA), CAN/CSA (Canada), FCC Part 15 Class A, CE, IEC 60950-1
TAA Compliant:
Yes
Environmentally Friendly:
Yes
Country of Origin:
Taiwan
Specs
| Power Description | |
| Input Voltage | 240 V AC |
| Physical Characteristics | |
| Product Material | Steel |
| Weight (Approximate) | 37.50 lb |
| Product Color | Black |
| Height | 1.7" |
| Color Family | Black |
| Width | 19" |
| Rack Height | 1U |
| Depth | 26.8" |
| Warranty | |
| Limited Warranty | 1 Year |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of PS/2 Ports | 2 |
| PS/2 Port | Yes |
| Display & Graphics | |
| Screen Resolution | 1366 x 768 |
| Screen Size | 19" |
| Screen Mode | WXGA |
| General Information | |
| Brand Name | Tripp Lite series |
| Manufacturer Website Address | http://www.eaton.com |
| Marketing Information | Tripp Lite's B070-016-19-IP KVM Switch gives you a rack-mountable full keyboard, LCD and touchpad in a single console that occupies only 1U of rack space. Easy to install and use, it's the optimal solution for controlling up to 16 computers/servers locally, from across the room, down the street or halfway around the globe on a LAN, WAN or Internet.The B070-016-19-IP uses inexpensive, user-supplied Cat5e/6/6a cabling with Server Interface Units so you can control computers/servers located up to 100 ft. away from the switch. This switch features two 10/100 Mbps LAN ports, so if one fails, the other takes over, keeping remote access uninterrupted. Users can switch easily between the 16 ports using an on-screen display (OSD). Multi-level password protection prohibits unauthorized users from accessing the connected computers, and a local user and a remote user can be logged on simultaneously. The built-in 19" LCD screen supports video resolutions up to 1366 x 768.Two serial ports allow control of serial-manageable devices such as IP PDUs, firewalls and routers; you can assign individual ports to an IP PDU port to power on/off the server connected to that port. The B070-016-19-IP stores neatly in a rack drawer and pulls out when needed. This KVM console is compatible with both Windows and Linux operating systems, and provides remote access using a Windows computer. Heavy-duty steel housing stands up to frequent use. Complies with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases. Free NetCommander-AXS Management Software is available for access and control of all of your Tripp Lite NetCommander IP KVM switches (B070 and B072 series). From a single interface, you can access server ports on any of your KVM switches, power cycle or power on/off outlets of IP PDU's, and manage KVM settings. This software can be found on the model support page of the B070-016-19-IP, or via searching NetCommander-AXS on www.tripplite.com More from the Manufacturer |
| Product Type | LCD Rack Console |
| Product Name | 16-Port, 1+1 User NetCommander Cat5 IP Console KVM Switch |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | B070-016-19-IP |
| Product Model | B070-016-19-IP |
| Product Line | NetCommander |
| Technical Information | |
| KVM Switch | Yes |
| Number of Computers Supported | 16 |
| KVM Technology | Digital |
| Daisy Chain | Yes |
| Device Type | LCD Rack Console |
| Input Devices | |
| Pointing Device Type | TouchPad |
| Keyboard | Yes |
