Ubiquiti airMAX GigaBeam Long-Range 60/5 GHz Radio (gbe-lr-us)
(No reviews yet)
Write a Review
- SKU:
- 19179450
- MPN:
- gbe-lr-us
- Availability:
- Out of stock
- Stock Update:
- 04/18/2023 12:04:10 PM PST
- Stock Update:
- 04/18/2023 12:04:10 PM PST
Description
This item is brand-new, factory sealed.
airMAX AC 60 GHz/5 GHz Radio with 1+ Gbps Throughput and Up to 2 km Range
Featuring a high-gain dish antenna, the GigaBeam LR is a 60 GHz radio designed for low-interference and high-throughput connectivity in long-range deployments. It includes a 5 GHz radio for failover. For the 60 GHz link, the GigaBeam LR supports full bandwidth use of 2.16 GHz. The dedicated management radio allows easy setup via Wi-Fi.
Features:
- 60 GHz radio with 5 GHz radio backup
- Low-interference 60 GHz spectrum
- Up to 1+ Gbps with low latency
- Long-range performance
- 2.4 GHz management radio
- Full bandwidth support: 2.16 GHz
Package Contents:
- airMAX GigaBeam Long-Range 60/5 GHz Radio
- Pole Mount
Features
Package Contents:
Wi-Fi
- airMAX GigaBeam Long-Range 60/5 GHz Radio
- Pole Mount
Additional Information:
- Enclosure: Aluminum, UV-stabilized Polycarbonate
- Antenna Gain:
- 5 Ghz: 11 dBi
- 60 Ghz: 38 dBi
- Max. Power Consumption: 11W
- Power Method: Passive PoE, Pins 4, 5+ and 7, 8-
- Power Supply: 24VDC, 0.5A Gigabit PoE Adapter (Included)
- Voltage Range: +22 to +26VDC
- LEDs: Power/Ethernet/5G/60G
- Wind Loading:
- 56 N @ 200 km/h
- <(12.6 lbf @ 125 mph)
- Wind Survivability:
- 200 km/h
- (125 mph)
- ESD/EMP Protection: ± 24kV Contact/Air
- Operating Temperature: -40 to 60° C (-40 to 140° F)
- Operating Humidity: 5 to 95% Noncondensing
- Certifications: FCC, IC, CE
- Max. Conducted TX Power
- 5/60 GHz Combined: 25 dBm
- Channel Bandwidth
- 60 Ghz: 2160 Mhz
- 5 Ghz: 20/40/80 Mhz
- US/CA
- U-NII-1: 5150 - 5250
- U-NII-2A: 5250 - 5350
- U-NII-2C: 5470 - 5725
- U-NII-3: 5725 - 5850, 57,000 - 66,000
- Worldwide:
- 5180 - 5875
- 57,000 - 66,000
- Worldwide: 2412 - 2472
- US/CA: 2412 - 2462
Features:
Wi-Fi
Specs
| Physical Characteristics | |
| Weight (Approximate) | 3.09 lb |
| Height | 11.9" |
| Width | 16.3" |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| General Information | |
| Brand Name | Ubiquiti |
| Manufacturer Website Address | http://www.ui.com |
| Marketing Information | airMAX AC 60 GHz/5 GHz Radio with 1+ Gbps Throughput and Up to 2 km Range Featuring a high-gain dish antenna, the GigaBeam LR is a 60 GHz radio designed for low-interference and high-throughput connectivity in long-range deployments. It includes a 5 GHz radio for failover. For the 60 GHz link, the GigaBeam LR supports full bandwidth use of 2.16 GHz. The dedicated management radio allows easy setup via Wi-Fi. Features: 60 GHz radio with 5 GHz radio backup Low-interference 60 GHz spectrum Up to 1+ Gbps with low latency Long-range performance 2.4 GHz management radio Full bandwidth support: 2.16 GHz |
| Product Type | Radio Modem |
| Product Name | airMAX GigaBeam Long-Range 60/5 GHz Radio |
| Manufacturer | Ubiquiti Inc. |
| Manufacturer Part Number | GBE-LR-US |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
