Ubiquiti UniFi Switch Aggregation (usw-aggregation)
(No reviews yet)
Write a Review
- SKU:
- 19179549
- MPN:
- usw-aggregation
- Availability:
- Usually ships the same or next business day. In stock at our CA, GA, IL, PA warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 03/18/2026 02:08:58 PM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 4 or above | and pay only $283.48 each 283.48 |
- Stock Update:
- 03/18/2026 02:08:58 PM PST
Description
This item is brand-new, factory sealed.
UniFi Aggregation Switch is a managed Layer 2 switch with eight 10G SFP+ ports. Featuring a compact 4.7" depth and fanless design it supports high-bandwidth links to provide link aggregation for higher capacity and increased availability.Features
Certifications & Standards:
Network
Waste Electrical and Electronic Equipment Directive (WEEE)
- CE
- FCC
- IC
- Anatel: 00593-21-08356
Additional Information:
- Switching Capacity: 160 Gbps
- Total Non-Blocking Throughput: 80 Gbps
- Forwarding Rate: 119 Mpps
- Supported VLANs: 1,000
- MAC Address Table Size: 16,000
- Packet Buffer Size: 1.5 MB
- Management: Ethernet, AR
- Heat Dissipation: 102 BTU/hr
- Supported Rack Depth: 400~1200 mm (15.7-47.2")
- LCM Display: 1.3" touchscreen
- ESD Protection: Air: ± 16kV, contact: ± 12kV
- Ambient Operating Temperature: -5 to 40° C (23 to 104° F)
- Ambient Operating Humidity: 10 to 90% noncondensing
- NDAA Compliant: Yes
- LACP Port Aggregation: Yes
- STP & RSTP: Yes
- Advanced IGMP Configuration (Querier, Fast Leave, Router Port): Yes
- MAC-Based ACLs & Device Isolation: Yes
- DHCP Snooping & Guarding: Yes
- Egress Rate Limit: Yes
- Storm Control: Yes
- Multicast & Broadcast Rate Limiting: Yes
- MAC Address Blocking: Yes
- IP-Based ACLs & Network Isolation: Yes
- MAC-Based Port Restriction: Yes
- Port Isolation: Yes
- Jumbo Frames: Yes
- LLDP-MED: Yes
- Voice VLAN: Yes
- Virtual Network Override: Yes
Application/Usage:
Network
Environmental Compliance:
Waste Electrical and Electronic Equipment Directive (WEEE)
Specs
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| Power Source | AC/DC |
| Frequency |
|
| Input Voltage |
|
| Power Consumption | 36 W |
| Physical Characteristics | |
| Product Material | SGCC Steel |
| Form Factor | Rack-mountable |
| Weight (Approximate) | 5.73 lb |
| Height | 1.7" |
| Compatible Rack Unit | 1U |
| Width | 17.4" |
| Depth | 4.7" |
| Interfaces/Ports | |
| Port/Expansion Slot Details | 8 x 10 Gigabit Ethernet Expansion Slot |
| I/O Expansions | |
| Total Number of Expansion Slots | 8 |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 8 |
| General Information | |
| Brand Name | Ubiquiti |
| Manufacturer Website Address | http://www.ui.com |
| Product Type | Ethernet Switch |
| Product Name | USW-AGGREGATION Ethernet Switch |
| Manufacturer | Ubiquiti Inc. |
| Manufacturer Part Number | USW-AGGREGATION |
| Product Model | USW-AGGREGATION |
| Media & Performance | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Maximum Data Transfer Rate | 1.25 GB/s |
| Media Type Supported | Optical Fiber |
| Network Technology | 10GBase-X |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.1x |
| Technical Information | |
| Features |
|
