Vantec 264234 Ac Ugt-m2670 M.2 Pcie Gen3x2 B+m Key To 5 Ports Sata Iii Expansion Card

This item is brand-new, factory sealed.

M.2 PCIe Gen3x2 B+M Key To 5 Ports SATA III Expansion Card
UGT-M2670
This M.2 PCIe Gen3x2 B+M Key to 5 ports SATA III Expansion Card is designed to use the M.2 NVMe slot on the motherboard to connect 5 SATA devices.
Provide 5 SATA ports via M.2 PCIeSupports PCIe Gen3x2 transfer speedSupports SATA III 6Gbps transfer speed (Backward compatible with SATA II/I)Supports SATA plug and play functionProvides LED indicators for each SATA port
Highlight
This M.2 PCIe Gen3x2 B+M Key to 5 ports SATA III Expansion Card is designed to use the M.2 NVMe slot on the motherboard to connect 5 SATA devices. It uses PCIe v3.0 with 2 lanes (B+M Key) to link to the 5 SATA devices. This will allow for even greater number of SATA III devices to be connected. It is Plug and Play, no additional software or drivers are required when using Windows 10/11. It is design to support SATA SSD or HDD for fast data transfer and clear LEDs indicators for each SATA port for disk activity. The Core chipset JMB585 manage the 5 SATA port with port multiplier and multiple commands for simultaneous sending/receiving data both in AHCI and legacy IDE mode. It also support TRIM to SSD and is able perform at a theoretical speed of 6Gbps.
Provide 5 SATA ports via M.2 PCIe
Supports PCIe Gen3x2 transfer speed
Supports SATA III 6Gbps transfer speed (Backward compatible with SATA II/I)
Supports SATA plug and play function
Provides LED indicators for each SATA portModel:
UGT-M2670M.2 interface:
M.2 NVMe (PCI Express 3.0x2)Device Connectors:
Five SATA III (6Gbps) portsPower Supply:
M.2 interface powered, no external power neededOS Support:
Windows 11, 10 (32bit or 64bit) Linux OS with Latest KernelEnvironmental:
Operating Temperature:
0 ^oC to +45^oC
Operating Humidity:
10% to 85 % RH (no condensation)
Storage Temperature:
-10^oC to +70^oC
Storage Humidity:
5% to 90% RH (no condensation)System Requirements:
M.2 NVMe interface on motherboard
Newer OS (Windows 11/10)
Preferred, but not required, motherboard with newer core chipset
NOTE: Will work on motherboard with M.2 NVME, will not work with M.2 SATAWhats Included:
1 x M.2 PCIe Gen3x2 B+M Key to 5 ports SATA III Expansion Card, 1 x Quick Install GuideItem Dimension (L"xW"xH")
6 x 3 x 1

Weight
1 lb

Warranty Information
1-Year
