Vertiv Geist Switched Rack PDU with Next Generation IMD - 0U| 20A| 120V| [24] NEMA 5-20R Receptacles| L5-20P Plug| 1.9kW Power Capacity| VP5N20A4

(No reviews yet) Write a Review
SKU:
21158769
MPN:
vp5n20a4
Availability:
Usually ships the same or next business day. In stock at our CA, TX warehouses.
Shipping:
Calculated at Checkout
Stock Update:
12/22/2025 06:12:15 PM PST
  • Main
  • Alternate-Image3
  • Alternate-Image2
  • Alternate-Image1
$1,235.43
Stock Update:
12/22/2025 06:12:15 PM PST

Description



This item is brand-new, factory sealed.

The Vertiv Geist Switched RPDU VP5N20A4 is a 20A, 120V, 0U, vertical rack power distribution unit with input power monitoring and outlet level switching. It has (24) NEMA 5-20R receptacles and an L5-20P plug providing 1.9kW of power capacity. This device allows you to remotely turn off receptacles to avoid accidental overloads and power cycle equipment to reboot unresponsive critical IT equipment. It is integrated with the Vertiv Geist Next-Generation IMD which displays power data via its 128x128 high-visibility LCD. It has an internal sensor that intelligently adjusts the orientation based on horizontal or vertical installation. This includes a redundant power-sharing port that connects two IMDs in the rack and provides backup power in case of power loss. Enhanced security with a secure boot is added to the device to help ensure data and operations are protected. The units are UL-listed, TAA-compliant, RoHS certified, and individually tested for functionality and reliability.

Features

Certifications & Standards:
  • UL
  • c-UL Listed 62368
  • c-UL Listed 60950

    •

    TAA Compliant:
    Yes



    Environmentally Friendly:
    Yes



    Environmental Compliance:
    Restriction of Hazardous Substances (RoHS)



    Country of Origin:
    United States



    Specs

    Power Description
    Power Rating (Watt)1900 W
    Input Voltage Range100 V AC - 120 V AC
    Input Voltage120 V AC
    Output Voltage Range100 V AC - 120 V AC
    Input Current20 A
    Physical Characteristics
    Form FactorRack
    Weight (Approximate)18 lb
    Cord Length10 ft
    Product ColorBlack
    Mount TypeRack-mountable
    Height66.3"
    Color FamilyBlack
    Mounting OrientationVertical
    Width2"
    Rack Height0U
    Depth2.6"
    Warranty
    Additional Warranty Information5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years
    Limited Warranty5 Year
    Interfaces/Ports
    Modem (RJ-11)No
    Modem (RJ-22)No
    Modem (RJ-12)Yes
    Network (RJ-45)Yes
    USBYes
    Serial PortYes
    General Information
    Brand NameVertiv Geist
    Manufacturer Website Addresshttp://www.vertiv.com/
    Marketing InformationThe Vertiv Geist Switched RPDU VP5N20A4 is a 20A, 120V, 0U, vertical rack power distribution unit with input power monitoring and outlet level switching. It has (24) NEMA 5-20R receptacles and an L5-20P plug providing 1.9kW of power capacity. This device allows you to remotely turn off receptacles to avoid accidental overloads and power cycle equipment to reboot unresponsive critical IT equipment. It is integrated with the Vertiv Geist Next-Generation IMD which displays power data via its 128x128 high-visibility LCD. It has an internal sensor that intelligently adjusts the orientation based on horizontal or vertical installation. This includes a redundant power-sharing port that connects two IMDs in the rack and provides backup power in case of power loss. Enhanced security with a secure boot is added to the device to help ensure data and operations are protected. The units are UL-listed, TAA-compliant, RoHS certified, and individually tested for functionality and reliability.
    More from the Manufacturer
    Product TypePDU
    Product NameGU VP5N20A4 PDU
    ManufacturerVertiv
    Manufacturer Part NumberVP5N20A4
    Product SeriesN
    Product LineGeist Upgradeable
    Technical Information
    Plug/Connector Detail1 x NEMA L5-20P
    Receptacle TypeNEMA 5-20R
    Receptacle Detail24 x NEMA 5-20R
    Plug/Connector TypeNEMA L5-20P
    PDU TypeSwitched Outlet Monitored
    Features
    • LCD Display
    • Touch Screen Display
    Management
    Remote Outlet SwitchingYes
    Management<li>DHCP </li><li>HTTP </li><li>HTTPS </li><li>IPv4 </li><li>IPv6 </li><li>LDAP </li><li>NTP </li><li>RADIUS </li><li>RSTP </li><li>SSH </li><li>SMTP </li><li>SNMP (v1/v2c/v3) </li><li>Syslog </li><li>TACACS+</li>
