VIVOTEK FD9387FRV2 FD9387-FR-V2 5MP Outdoor Dome Facial Recognition IP Camera

This item is brand-new, factory sealed.

FD9387-FR-V2
5MP Facial Recognition Network Camera
Event Integration with VSS and 3rd parties
Cyber Protection via Trend Micro IoT Security
WDR Pro for Unparalleled Visibility
Supreme Night Visibility for Low Light Scene
Weather-proof IP66/IP67, Vandal-proof IK10
Benefits
10,000 Faces on the edge
With 99% facial recognition accuracy, the FD9387-FR-V2 is a powerful tool for accurate facial detection and person of interest control across multiple locations. The camera itself can hold up to 10,000 facial profiles.
Serverless facial recognition infrastructure up to 5 cameras
FD9387-FR-V2 can operate fully without middleware or FTP server, this reduces the operational overhead and allows you to focus on your core business functions.
With a single FD9387-FR-V2, you can store up to 10,000 facial profiles in a serverless architecture. You only need to manage and maintain the database in one camera, and it will automatically synchronize with other facial recognition cameras.System Information
CPU
Multimedia SoC (System-on-Chip)
Flash
1 GB
RAM
DDR4 2 GBCamera Specifications
Image Sensor
1/2.8" Progressive CMOS
Max. Resolution
2560x1920 (5MP)
Lens Type
Motorized, Vari-focal, Remote Focus
Focal Length
F equal 2.7- 13.5 mm
Aperture
F1.4(W) - F2.8(T)
Iris Type
P-iris
Field of View
95^o - 30^o (Horizontal)
70^o - 23^o (Vertical)
128^o - 38^o (Diagonal)
Shutter Time
1/5 sec. to 1/32,000 sec.
WDR Technology
WDR Pro
Day/Night
Yes
Removable IR-cut filter
Yes
Illuminators
Built-in IR illuminators, effective up to 50 meters with Smart IR III, IR LED x4
(50IRE)
Minimum Illumination
0.075 lux at F1.4 (Color)
<0.01 lux at F1.4 (B/W)
0 lux with IR illumination on
Pan Range
+/-175^o
Tilt Range
80^o
Rotation Range
+/-175^o
Pan/Tilt/Zoom Functionalities
ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
Storage
Seamless Recording to MicroSD/SDHC/SDKC card (1TB capacity supported) and recording
to network-attached storage (NAS)
Built-in Installation Aids
Remote focus, remote zoomVideo
Compression
H.265, H.264, MJPEG
Maximum Frame Rate
30 fps at 2560x1920 (WDR Pro on)
30 fps at 1600x1200 (WDR Pro on)
Maximum Streams
3 video streams (Up to 8 configurable profiles)
S/N Ratio
61 dB
Dynamic Range
120 dB
Video Streaming
Adjustable resolution, quality and constant bit rate control, Smart Stream II
Image Settings
General settings
video title and time stamp overlay, video orientation (flip, mirror,
rotation), day /night settings
Illuminators
illuminators, anti-overexposure, Smart IR II
Image settings
white balance, image adjustment (brightness, contrast, saturation,
sharpness, gamma curve), defog, 3DNR, EIS, scene mode (auto, deblur)
Exposure
BLC,
HLC, exposure control (exposure lev el, iris adjustment, exposure time, gain control, iris
mode), AE speed adjustment, WDR
Focus
zoom, focus
Privacy mask
Scheduled profile
settingsAudio
Audio Capability
Two-way audio (Full duplex)
Compression
G.711, G.726
Interface
External microphone Input
External line outputNetwork
Users
Live viewing for up to 10 clients
Security
Access list, digest authentication, HTTPS , IEEE 802.1x, password protection, secure boot,
signed firmware, Trend Micro IoT Security (brute force attack event, cyberattack event,
quarantine event), user access log, user account management
Protocols
802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP/SFTP, HTTP/HTTPS, ICMP,
IGMPv 3, IPv 4, IPv 6, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL,
TCP/IP, TLS 1.2, UDP, UPnP
Interface
10 Base-T/100 Base-TX Ethernet
It is highly recommended to use standard CAT5e and CAT6 cables which are compliant with the 3P/ETL standard.
ONVIF
Profile G, S, T supported, specification available at www.onvif.orgAI Analytics
Compute Capability
SoC with built-in hardware deep learning accelerator
Vision Object Analytics
AI-powered Short Range Facial Recognition
Application
Realtime facial recognition, DO trigger base on different POI.
Application available with license
Black and white list alarm, Person stay time info, Person search and tracking
AI-powered Image Enhancement
Smart IR IIISolution Integration
VADP Package
Stratocast, Trend Micro IoT Security (3-year free trial)Alarm and Event
Event Trigger
Audio detection, camera tampering detection, cybersecurity events (brute force attack event, cyberattack event, quarantine event), digital input, manual trigger, motion detection, periodical trigger, recording notification, SD card life expectancy, shock detection, system boot
Event Action
Event notification via audio clip, camera link, digital output, email, HTTP, FTP/SFTP, NAS server, SD card
File upload via email, HTTP, FTP/SFTP, NAS server, SD cardGeneral
Connectors
RJ-45 cable connector f or 10/100 Mbps PoE network connection
Audio line input
Audio line output
DC 12V power input/AC 24V power input
Digital input x2
Digital output x1
LED Indicator
Sy stem power and status indicator
Power Input
AC 24V/DC 12V, IEEE 802.3at PoE Class 4 (Power Redundancy )
Power Consumption
DC12V: Max 23/18W (IR ON/OFF) Max Current:1.92A
PoE Max: 22.5W/18W (IR ON/OFF) 42.557.0V Max Current: 0.53A-0.4A
AC24V Max: 21W/16W (IR ON/OFF) Max Current: 1.4A
Certifications
EMC
CE (EN 55032 Class A, EN 55035), FCC (FCC Part 15 Subpart B Class A), UKCA (BS
EN 55032:2015+A11: 2020, BS EN 55035:2017+A11:2020, BS EN IEC 62368-
1:2020+A11:2020), RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A),
ICES-003 Issue 7
Saf ety
UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22,
IEC/EN 62471)
Env ironment
IK10 (IEC 62262), IP66/67 (IEC 60529), IA: BIS (IS 13252),
BSMI (EMC: CNS 13438, Saf ety : CNS 14336-1)
Operating Temperature
Starting Temperature:
-30^oC - 60^oC (14^oF - 140^oF)
Working Temperature:
-30^oC - 60^oC (-22^oF - 140^oF) (IR of f )
-30^oC - 50^oC (-22^oF - 122^oF) (IR on)
Humidity
98% RH (non-condensing)System Requirements
Operating System
Microsoft Windows 10/8/7
Mac 10.12 (Chrome only)
Web Browser
Chrome 58.0 or above
Internet Explorer 11
Other Players
VLC: 1.1.11 or aboveIncluded Accessories
Packing Contents
Quick installation guide, product labels, alignment sticker, L-shaped wrench, screw pack, waterproof accessory pack, sunshield, conduit bracket, I/O cableItem Dimension (L"xW"xH")
8 x 8 x 6

Weight
3 lbs

Warranty Information
3-Year
