Adesso NuScan 2600U - Handheld 2D Barcode Scanner (NUSCAN2600U)
- SKU:
- 18060126
- MPN:
- nuscan2600u
- Availability:
- Usually ships the same or next business day. In stock at our IL, MS, NJ warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 04/26/2024 03:25:23 AM PST
- Stock Update:
- 04/26/2024 03:25:23 AM PST
Description
This item is brand-new, factory sealed.
The Adesso NuScan 2600U is compatible with a wide range of 1D and 2D barcode symbologies. With CMOS imager the NuScan 2600U is able to scan major 2D barcodes such as PDF 417, QR Codes, Data Matrix, and micro QR Code. As your daily peripheral companion, your peripheral must be able to provide you with good hygiene and cleanness. The NuScan 2600U can be cleaned periodically. With all these great features, the NuScan 2600U is truly your ultimate barcode scanner.Features:
2D Scanning Engine
The 2D scanning engine offers decoding capability for 2D barcodes like PDF417, Data Matrix, QR Code, MicroQR as well as common 1D barcodes.
Reliable Data Collection
Its built-in decoder can read the majority of 1D & 2D barcodes and its driver-less operation makes it easy to use with both Windows and Mac operating systems.
Superior Scanning Performance
Equipped with its CMOS sensor the device has a motion tolerance of 5 inches per second, offering fast and accurate scanning results.
Drop Protection
With its drop protection design, the NuScan 2600U less likely to become damaged due to accidental drops.
Long Scanning Range
The 2D CMOS decoding engine is able to scan barcodes up to 12 inches scan depth.
Mechanical:
Cable Length:
6 Ft (1.8meters)
Electrical:
Power Input voltage:
5 +/- 5% VDC
Working Current:
120mA
Light Source:
White LED and 640nm visible Red LED
Performance:
Interface:
USB
Sensor:
640x480 CMOS Sensor
Minimum Resolution Supported (2D):
5 mil
Depth of Field:
0-10 inches ( at 13mil UPC-A, PC 100%)
Scan Rate:
30 frames per second
Scan Angle
Roll: +/-30o, Pitch: +/-60o, Skew: +/-60o
Print Contrast:
>25%
Alert Operation:
Blue LED indicator and beeper
Environmental
Operating Temperature:
-20oC to 50oC (-4oF to 122oF)
Storage Temperature:
-40oC to 70oC (-40oF to 158oF)
Operating Humidity :
20% - 95% (non-condensing)
Storage Humidity :
5% to 95% (non-condensing)
Shock Resistance:
Withstanding 1.5m freefall drops
Regulatory
FCC, CE RoHS
Supported Symbologies
1D: EAN-8, EAN-13, EAN-13 2 add-on, EAN-13 5add-on, ISSN, ISBN, UPC-A, UPC-E, Code 11, Code 32 Code 39, Code 93, Code 128, Codabar, Industrial 2 of 5, Interleaved 2 of 5, Matrix 2 of 5
2D: PDF417, MicroPDF417, MicroQR, Data Matrix, QR, Aztec
System Requirements:
Windows2000 / XP / Vista / 7 / 8 / 10
Mac OS X
Interface: USB
Includes:
Adesso NuScan 2600U Handheld 2D Barcode Scanner
Quick Start Guide
Item Dimension (L"x W"x H")
11 x 8 x 2
Weight
4.00 LB
Package Contents:
- NuScan 2600U - Handheld 2D Barcode Scanner
- Quick Start Guide
Features
Package Contents:
Yes
Taiwan
- NuScan 2600U - Handheld 2D Barcode Scanner
- Quick Start Guide
Environmentally Friendly:
Yes
Application/Usage:
Logistics
Library
Healthcare
Retail
Warehouse
Platform Supported:
PC
Mac
Android
Country of Origin:
Taiwan
Specs
Physical Characteristics | |
Form Factor | Handheld |
Weight (Approximate) | 6.88 oz |
Length | 6.6" |
Height | 4.1" |
Width | 2.9" |
Warranty | |
Limited Warranty | 1 Year |
Interfaces/Ports | |
Host Interface | USB |
General Information | |
Brand Name | Adesso |
Manufacturer Website Address | http://www.adesso.com |
Marketing Information | The Adesso NuScan 2600U is compatible with a wide range of 1D and 2D barcode symbologies. With CMOS imager the NuScan 2600U is able to scan major 2D barcodes such as PDF 417, QR Codes, Data Matrix, and micro QR Code. As your daily peripheral companion, your peripheral must be able to provide you with good hygiene and cleanness. The NuScan 2600U can be cleaned periodically. With all these great features, the NuScan 2600U is truly your ultimate barcode scanner. 2D Scanning Engine The 2D scanning engine offers decoding capability for 2D barcodes like PDF417, Data Matrix, QR Code, MicroQR as well as common 1D barcodes. Reliable Data Collection It's built-in decoder can read the majority of 1D & 2D barcodes and it's driver-less operation makes it easy to use with both Windows® and Mac® operating systems. Superior Scanning Performance Equipped with its CMOS sensor the device has a motion tolerance of 5 inches per second, offering fast and accurate scanning results. Drop Protection With its drop protection design, the NuScan 2600U less likely to become damaged due to accidental drops. Long Scanning Range The 2D CMOS decoding engine is able to scan barcodes up to 12 inches scan depth. More from the Manufacturer |
Product Type | Barcode Scanner |
Product Name | NuScan 2600U - Handheld 2D Barcode Scanner |
Manufacturer | Adesso, Inc |
Manufacturer Part Number | NUSCAN2600U |
Product Model | 2600U |
Product Line | NuScan |
Technical Information | |
Maximum Ambient Light | 70000 lux |
Scanning Distance | 12" |
Barcode Symbology Supported | <p><b>1D:</b> </p> <ul> <li>EAN-8</li> <li>EAN-13</li> <li>EAN-13 2 add-on</li> <li>EAN-13 5add-on</li> <li>ISSN</li> <li>ISBN</li> <li>UPC-A</li> <li>UPC-E</li> <li>Code 11</li> <li>Code 32</li> <li>Code 39</li> <li>Code 93</li> <li>Code 128</li> <li>Codabar</li> <li>Industrial 2 of 5</li> <li>Interleaved 2 of 5</li> <li>Matrix 2 of 5</li> </ul> <p><b>2D:<br /></b></p> <ul> <li>PDF417</li> <li>MicroPDF417</li> <li>MicroQR</li> <li>Data Matrix</li> <li>QR</li> <li>Aztec</li> </ul> |
Drop Specification | The drop-protection design prevents damage due to accidental drops of less than 1.5 meters. |
Light Source | LED |
Scan Rate | 30 scan/s |
Scanning Capability |
|
Scanner Range | Long Range |
Connectivity Technology | Cable |
Minimum Print Contrast | 35% |
