aten
Aten CS1182DPH4C 2-port Single Display Universal Secure Kvm Pp4.0 [hdmi / Displayport] With Cac S
- SKU:
- 21663020
- MPN:
- cs1182dph4c
- Availability:
- Usually ships the same or next business day. In stock at our IL warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 09/02/2026 12:50:20 AM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 or above | and pay only $622.11 each 622.11 |
- Stock Update:
- 09/02/2026 12:50:20 AM PST
Description
This item is brand-new, factory sealed.
Aten - CS1182DPH4C - ATEN CS1182DPH4C KVM Switchbox - 2 Computer(s) - 5K - 5120 x 2880 - 50 Hz, 60 Hz - 7 x USB - 3 x- ATEN PSD PP v4
- 0 Universal Secure KVM Switch CS1182DPH4C is specifically designed to meet the stringent security requirement of secure defense and intelligence installations
- 0 Universal Secure KVM Switch CS1182DPH4C is compliant with PSD PP v4
- 0 (Protection Profile for Peripheral Sharing Device, Version 4
- Brand Name: ATEN
- UPC: 672792016615
- Warranty Description: No Warranty
- Unit Count: 1 Count
- Manufacturer: Aten
- Number of Items: 1
- Included Components: USB
- Model: CS1182DPH4C
- Part Number: CS1182DPH4C
- Color: Multicolor
ATEN PSD PP v4.0 Universal Secure KVM Switch CS1182DPH4C is specifically designed to meet the stringent security requirement of secure defense and intelligence installations. ATEN PSD PP v4.0 Universal Secure KVM Switch CS1182DPH4C is compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) standard certified by the National Information Assurance Partnership (NIAP). ATEN PSD PP v4.0 Universal Secure KVM Switch CS1182DPH4C provides isolation between computer sources and peripherals while sharing a single keyboard, mouse, monitor, speaker set, and Common Access Card (CAC) reader between connected computers of various security classifications. Compliance with PSD PP v4.0 ensures peripheral sharing capabilities provide maximum user data security when switching port focus, preventing unauthorized data flows or leakage between connected sources. Key protections include isolation and unidirectional data flow, restricted peripheral connectivity and filtering, user data protection, configurable device filtration and management, strict audio filtration, and always-on tamper-proof design, keeping sensitive assets isolated and providing advanced security and a user friendly design for instantly secure deployment. To fulfill different customer demands, ATEN PSD PP v4.0 Universal Secure KVM Switches offer a wide range of options, including 2-port and 4-port, CAC and Non-CAC models, and support for DisplayPort or HDMI interfaces through a single combo connector. ATEN PSD PP v4.0 Universal Secure KVM Switches also provide customers with the flexibility to connect single or dual displays, providing superior video quality up to 5K (5120 x 2880 @ 60Hz). 5K resolution provides greater screen real estate and sharper detail, allowing users to view multiple classified sessions, monitoring dashboards, or data-intensive applications side by side with uncompromised clarity. This enhanced visual precision helps minimize task-switching and potential errors,
Package Contents:
- CS1182DPH4C KVM Switchbox
- 1x Power adapter
- 1x Foot pad set
- 1x Port name labels
- 1x HDMI cable lock set
- 1x User instructions
Features
- CS1182DPH4C KVM Switchbox
- 1x Power adapter
- 1x Foot pad set
- 1x Port name labels
- 1x HDMI cable lock set
- 1x User instructions
Certifications & Standards:
PSD PP v4.0
TAA Compliant:
Yes
Compatibility:
KVM Cables:
- 2L-7D02UDPX4
- 2L-7D02UH21X4
- 2L-7D02UHX4
- 2L-7D03UDPX4
- 2L-7D03UHX4
Country of Origin:
Taiwan
Specs
| Power Description | |
| Input Voltage Range | 100-240V |
| Frequency |
|
| Input Current | 1.20 A |
| Physical Characteristics | |
| Weight (Approximate) | 2.67 lb |
| Length | 9.65" |
| Height | 1.7" |
| Width | 5.7" |
| Warranty | |
| Limited Warranty | 24 Month |
| Interfaces/Ports | |
| Number of USB Ports | 7 |
| Number of HDMI Ports | 3 |
| Number of DisplayPorts | 3 |
| USB | Yes |
| DisplayPort | Yes |
| HDMI | Yes |
| Video | |
| Maximum Video Resolution | 5120 x 2880 |
| Graphic Mode | 5K |
| General Information | |
| Brand Name | ATEN |
| Manufacturer Website Address | http://www.aten.com/us/en/ |
| Marketing Information | ATEN PSD PP v4.0 Universal Secure KVM Switch CS1182DPH4C is specifically designed to meet the stringent security requirement of secure defense and intelligence installations. ATEN PSD PP v4.0 Universal Secure KVM Switch CS1182DPH4C is compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) standard certified by the National Information Assurance Partnership (NIAP). ATEN PSD PP v4.0 Universal Secure KVM Switch CS1182DPH4C provides isolation between computer sources and peripherals while sharing a single keyboard, mouse, monitor, speaker set, and Common Access Card (CAC) reader between connected computers of various security classifications. Compliance with PSD PP v4.0 ensures peripheral sharing capabilities provide maximum user data security when switching port focus, preventing unauthorized data flows or leakage between connected sources. Key protections include isolation and unidirectional data flow, restricted peripheral connectivity and filtering, user data protection, configurable device filtration and management, strict audio filtration, and always-on tamper-proof design, keeping sensitive assets isolated and providing advanced security and a user friendly design for instantly secure deployment. To fulfill different customer demands, ATEN PSD PP v4.0 Universal Secure KVM Switches offer a wide range of options, including 2-port and 4-port, CAC and Non-CAC models, and support for DisplayPort or HDMI interfaces through a single combo connector. ATEN PSD PP v4.0 Universal Secure KVM Switches also provide customers with the flexibility to connect single or dual displays, providing superior video quality up to 5K (5120 x 2880 @ 60Hz). 5K resolution provides greater screen real estate and sharper detail, allowing users to view multiple classified sessions, monitoring dashboards, or data-intensive applications side by side with uncompromised clarity. This enhanced visual precision helps minimize task-switching and potential errors, improving both operational accuracy and overall productivity in mission-critical or security-conscious workplaces. To enhance security, ATEN PSD PP v4.0 Universal Secure KVM Switch CS1182DPH4C only offers manual switching methods including front panel pushbuttons and Remote Port Selector (RPS). With multi-layered security, ATEN PSD PP v4.0 Universal Secure KVM Switch CS1182DPH4C ensures high-level desktop security and data safekeeping for applications such as government and military agencies, healthcare providers, banking & finance institutions, and other organizations that often handle sensitive or confidential data on separate networks. |
| Product Type | KVM Switchbox |
| Product Name | CS1182DPH4C KVM Switchbox |
| Manufacturer | ATEN Technology, Inc |
| Manufacturer Part Number | CS1182DPH4C |
| Product Model | CS1182DPH4C |
| Packaged Quantity | 1 |
| Technical Information | |
| Number of Computers Supported | 2 |
| Device Type | Secure KVM |
| Features |
|
| Connectivity Technology | Wired |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Operating Temperature | 32°F (0°C) |
