Description
This item is brand-new, factory sealed.
NIAP PSD v4.0 Certified Secure KVM Switches | ONE Console Controls Multiple Classification Systems Without Any Data Leakage
Every day, organizations face critical network security challenges. One of the most vulnerable parts of a network is the user console. Simply connecting computer peripherals such as keyboard and mouse to multiple systems introduces potential data leakage and hacking risks.
Black Box Secure KVM Switches provide complete port isolation between networks, ensuring that no data leaks between secure ports and the outside world. Built with true air-gap data-path isolation between systems and networks, these switches also help prevent hardware tampering and EDID/audio detection.
Listed on the NIAP Product Compliant List (PCL), Black Box NIAP PSD v4.0-certified Secure KVM Switches meet the highest Common Criteria Protection Profile/Information Assurance standards defined by NIAP.
Package Contents:
- 1x Secure KVM Switch
- 1x 12 VDC Wallmount Supply (ICP36-120-3000) with US, EU, UK, and AU adapter clips
- 1x Set of 4 rubber feet (already be attached)
- 1x Quick Start Guide
Features
Package Contents:
Yes
United States
- KVM Switch, NIAP 4.0 Certified - 2-Port, Dual-Monitor, FlexPort HDMI/DisplayPort, CAC
- 1 x 12 VDC Wallmount Supply (ICP36-120-3000) with US, EU, UK, and AU adapter clips
- 1 x Set of 4 rubber feet (already be attached)
- 1 x Quick Start Guide
Certifications & Standards:
NIAP 4.0 Certified
TAA Compliant:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin:
United States
Specs
| Power Description | |
| Input Voltage Range | 12V DC |
| Physical Characteristics | |
| Weight (Approximate) | 3.85 lb |
| Height | 2.6" |
| Width | 8.8" |
| Depth | 6.7" |
| Warranty | |
| Limited Warranty | 3 Year |
| Interfaces/Ports | |
| Number of USB Ports | 7 |
| Number of HDMI Ports | 6 |
| Number of DisplayPorts | 6 |
| USB | Yes |
| DisplayPort | Yes |
| HDMI | Yes |
| USB 2.0 | Yes |
| USB Standard | USB 2.0 |
| Video | |
| Maximum Video Resolution | 3840 x 2160 |
| Graphic Mode | 4K |
| General Information | |
| Brand Name | Black Box |
| Manufacturer Website Address | http://www.blackbox.com |
| Marketing Information | Keep your sensitive data safe in defense applications, secure control rooms, corporate communications, server operations, educational administrations, medical facilities, banking networks, insurance data centers, transit management, industrial operations, intelligence communications, and more. This Secure KVM Switch features mechanical, electrical, and optical signal isolation to prevent hacking and data leakage in environments where security is paramount. Use the switch to control KVM (Keyboard, Video, and Mouse) operation on up to two or four computers with one or two HDMI/DisplayPort displays. Certified for NIAP Protection Profile for Peripheral Sharing Device Version 4.0 The Secure KVM Switches are tested and certified under the USA scheme for NIAP Protection Profile 4.0 so you get the best data protection available on the market today. Control the Switch via Front-Panel Buttons Use the clearly marked front-panel buttons for controlling the device, so securely switching between sources is always simple. Isolated Data Channels and Non-Reprogrammable ROM Ensure Maximum Security Data relays work one at a time to shield connections from outside intrusion. Inverted signals control the data relays. Each port uses its own isolated data channel and each unit features non-reprogrammable ROM to better protect the switch's functions. There is no data leakage between ports. Would-be hackers can never gain access to your sensitive data by compromising the switch's ROM. Protects from Internet Data Breaches The switch offers the highest security when accessing classified and public networks over the internet through isolated connections. By isolating connections between networks, no data is leaked between secure ports and the outside world. Secure EDID Learn and Video Emulation The Secure KVM emulates (simulates) the presence of a keyboard and mouse for every attached computer through a USB cable. Both selected and non-selected computers maintain a constant connection with the unit's keyboard-mouse emulation controllers, allowing for ultra-fast switching and restricting the discovery of newly connected peripherals during switching operations. Emulation of keyboard and mouse also prevents the direct connection between the peripherals and the connected computers, shielding systems from potential vulnerabilities. Tamperproof Seals Protect Your Devices Built-in tamperproof seals and a long-life internal anti-tamper battery add even more security for your devices. |
| Product Type | KVM Switchbox |
| Product Name | KVM Switch, NIAP 4.0 Certified - 2-Port, Dual-Monitor, FlexPort HDMI/DisplayPort, CAC |
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | KVS4-2002HVX |
| Product Model | KVS4-2002HVX |
| Product Line | Secure |
| Packaged Quantity | 1 |
| Technical Information | |
| Number of Remote Users Supported | 1 |
| Number of Computers Supported | 4 |
| Device Type | Secure KVM |
| Features |
|
| Connectivity Technology | Wired |
| Number of Local Users Supported | 1 |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Operating Temperature | 32°F (0°C) |
