Black Box Industrial Gigabit Ethernet Switch - Extreme Temperature, 5-Port (lig401a)
(No reviews yet)
Write a Review
- SKU:
- 18157256
- MPN:
- lig401a
- Availability:
- Usually ships the same or next business day. In stock at our IL, NJ warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 12/16/2025 03:44:12 AM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 - 5 | and pay only $199.56 each 199.56 |
| Buy 6 or above | and pay only $194.55 each 194.55 |
- Stock Update:
- 12/16/2025 03:44:12 AM PST
Description
This item is brand-new, factory sealed.
Reliable and scalable.
The very reliable LIG401A Industrial Ethernet Switch, (4) 10/100/1000-Mbps, (1) GE SFP, is designed for the far edges of your network. Use it in harsh, indoor environments with temperature extremes of -40° to +75°C, such as loading docks or monitoring stations. This rugged switch comes in an IP31-rated enclosure that can be DIN-rail or wall mounted.
The Gigabit Ethernet SFP port gives you networking flexibility and scalability. You can extend your network over multimode or single-mode fiber at distances up to 80 kilometers, depending on the SFP you choose. Black Box SFPs are recommended.
For redundancy, the switch has two DC power inputs. If one power source fails, the switch automatically falls over to the second power source. In addition, an alarm will alert you in case of a power failure.
For easy, plug-and-play setup, the 10/100/1000-Mbps Ethernet ports are autosensing with Auto MDI/MDI-X.
A multitude of applications.
This switch can be used in a wide variety of applications, such as: >
Package Contents:
- Industrial Gigabit Ethernet Switch - Extreme Temperature, 5-Port
- DIN Rail Mount Kit
Features
Package Contents:
Yes
Industrial
Taiwan
- INDUSTRIAL UNMANAGED GIGABIT ETHERNET SWITCH
- 2 x WALLMOUNT PLATES
- 1 x DIN RAIL CLIP
- 1 x DC POWER TERMINAL BLOCK
- 4 x RJ-45 PORT DUST COVERS
- 1 x SFP PORT DUST COVER
Additional Information:
This industrial switch does not include a power supply. Use it with the MDR-40-12, MDR-40-24, SDR-120-48, or the SDR-240-48.
Environmentally Friendly:
Yes
Application/Usage:
Industrial
Environmental Compliance:
Waste Electrical and Electronic Equipment Directive (WEEE)
Restriction of Hazardous Substances (RoHS)
Country of Origin:
Taiwan
Specs
| Management & Protocols | |
| Manageable | No |
| Power Description | |
| Power Source | DC |
| Input Voltage |
|
| PoE (RJ-45) Port | No |
| Physical Characteristics | |
| Form Factor |
|
| Weight (Approximate) | 11.20 oz |
| Height | 4.4" |
| Width | 1.1" |
| Depth | 3.5" |
| Warranty | |
| Limited Warranty | 1 Year |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details |
|
| Total Number of Network Ports | 4 |
| I/O Expansions | |
| Total Number of Expansion Slots | 1.0 |
| Number of SFP Slots | 1 |
| Expansion Slot Type | SFP |
| General Information | |
| Brand Name | Black Box |
| Manufacturer Website Address | http://www.blackbox.com |
| Marketing Information | OVERVIEW INDUSTRIAL MANAGED AND UNMANAGED GIGABIT ETHERNET SWITCHES DATA SHEET INTRODUCTION The Industrial Managed and Unmanaged Gigabit Ethernet Switches include unmanaged switches that provide four (4) copper RJ-45 or RJ-45 PoE ports and one (1) multi-rate SFP slot and managed switches that provide six (6) or eight (8) copper RJ-45 or RJ-45 PoE ports and two (2) or four (4) multi-rate SFP slots. Power over Ethernet The LIE401A, LIE1014A, LIE1080A and LIE1082A switches support Power over Ethernet compliant to the IEEE 802.3af and IEEE 802.3at standard on all copper ports. These switches can be used to power standard PoE PD devices with up to 30 watts per port along with the Ethernet data on standard Ethernet Cabling. Multi-rate SFP slots The benefit of having multi-rate SFP slots is to be able to use 100-Mbps and 1-Gbps SFP Modules for either multi- or single-mode in a mix and match as needed. If requirements change, just replace the SFP module and protect your switch investment. Power The switches are powered from 12- to 58-VDC. The PoE models need 48 VDC for 802.3af and a minimum of 53 VDC for 802.3at. Extended temperature range All models are tested and released for operating temperatures from -40° up to +75° Celsius. Management The switches offer powerful features including Layer 2 routing and management with all advanced filter and multicast algorithms needed today to easily prioritize, partition, and organize a reliable high-speed network. |
| Product Type | Ethernet Switch |
| Product Name | Industrial Gigabit Ethernet Switch - Extreme Temperature, 5-Port |
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | LIG401A |
| Media & Performance | |
| Ethernet Technology | Gigabit Ethernet |
| Media Type Supported |
|
| Network Technology |
|
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards |
|
