Broadcom BCM95720A2003AC Dual-Port Gigabit Ethernet Adapter
(No reviews yet)
Write a Review
- SKU:
- 18039059
- MPN:
- 254613
- Availability:
- Usually ships the same or next business day. In stock at our NJ warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 05/18/2026 11:47:38 PM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 | and pay only $90.53 each 90.53 |
| Buy 3 - 4 | and pay only $88.47 each 88.47 |
| Buy 5 - 12 | and pay only $86.86 each 86.86 |
| Buy 13 or above | and pay only $84.91 each 84.91 |
- Stock Update:
- 05/18/2026 11:47:38 PM PST
Description
This item is brand-new, factory sealed.
Designed for today's enterprise and data center environments, Broadcom's NetXtreme 1G Ethernet Adapters are the ideal solution for multicore servers, delivering full line-rate throughput across all ports.The BCM5720 PCIe NIC is a 13th-generation 10/100/1000BASE-T and 10/100/1000BASE-X Ethernet LAN controller solution for high-performance server and networking applications. The host interface supports a separate PCI Express function for each LAN interface. The BCM5720 includes I/O Virtualization (IOV) features such as 17 receive and 16 transmit queues, and 17 MSI-X vectors with flexible vector-to-queue association. These IOV features enable the BCM5720 to support the VMWare NetQueue and Microsoft VMQ technologies.
The BCM5720 includes a comprehensive set of hardware features that the system may use to implement IEEE 1588 or IEEE 802.1AS-based time synchronization. These hardware features include a high-precision clock, timestamp registers for receive/transmit packets, and programmable trigger inputs and watchdog outputs. Adapter Type
PCIe NIC ASIC
BCM5720 Connectors
1GBASE-T OS Support
CentOS, Debian, Microsoft Windows, Oracle Linux, Oracle Solaris, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, SUSE Linux Enterprise Server, Ubuntu, VMware, VMware ESX, VMware vSphere, Windows Hyper-V, Windows Server Host Connector
PCIe 2.0 x1 Link-Speeds
1GbE/100Mb/1Mb Multi-Host
No NPAR
No Ports
2 RoCEv2
No TruFlowTM
No TruManageTM
YesItem Dimension (L inchxW inchxH inch)
6 x 3 x 1
Weight
1.00 lb
Warranty Information
NA
Features
Environmentally Friendly:
Yes
Server
Restriction of Hazardous Substances (RoHS)
Yes
Device Supported:
Server
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Specs
| Physical Characteristics | |
| Form Factor | Plug-in Card |
| Width | 2.7" |
| Depth | 4.3" |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Host Interface | PCI Express 2.0 x1 |
| Number of Network (RJ-45) Ports | 2 |
| General Information | |
| Brand Name | Broadcom |
| Manufacturer Website Address | https://www.broadcom.com |
| Marketing Information | Leveraging long-standing industry leadership in Ethernet, Broadcom now offers the NetXtreme BCM5720-2P Ethernet Server Adapter, providing the highest levels of performance, efficiency, and scalability for the enterprise data center. Designed for today's enterprise and data center environments, the Broadcom BCM5720-2P Ethernet Server adapter is the ideal solution for multicore servers, delivering full line-rate throughput across all ports. The adapter utilizes Broadcom's field-proven dual-port BCM5720-2P integrated controller device to deliver lower power consumption and Energy Efficient Ethernet (EEE), reducing IT operation costs. The BCM5720-2P is compatible with x86 and x64 servers utilizing the PCIe v1.x and v2.x interfaces. Increasing application workloads are placing greater demands on enterprise networks, and the BCM5720-2P-based dual-port 1GbE Server Adapter is the solution of choice for such environments, providing a reliable, highperformance, energy-efficient 1GbE connectivity solution. |
| Product Type | Gigabit Ethernet Card |
| Product Name | NetXtreme BCM5720-2P Dual-Port Ethernet Server Adapter |
| Manufacturer | Broadcom Corporation |
| Manufacturer Part Number | BCM5720-2P |
| Product Model | BCM5720-2P |
| Product Line | NetXtreme |
| Packaged Quantity | 1 |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Network & Communication | |
| Network Technology | 10/100/1000Base-T |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
