Datalogic
Datalogic QuickScan QD2430 Handheld Barcode Scanner (qd2430-bk)
(No reviews yet)
Write a Review
- SKU:
- 20015931
- MPN:
- qd2430-bk_37
- Availability:
- Out of stock
- Stock Update:
- 08/13/2024 04:55:32 PM PST
- Stock Update:
- 08/13/2024 04:55:32 PM PST
Description
This item is brand-new, factory sealed.
The popularity of 2D bar codes has spread across all market segments of the data capture industry. Now, with more affordable pricing and virtually no drawbacks with area imaging technology, 2D bar code readers are in high demand with features such as reading from mobile phone displays or in planning ahead for future 2D codes and imaging needs.
Features
Ingress Protection (IP) Rating:
IP42
Vietnam
IP42
Additional Information:
USB Cable separate
Application/Usage:
Industrial
Retail
Country of Origin:
Vietnam
Specs
| Physical Characteristics | |
| Form Factor | Handheld |
| Weight (Approximate) | 5.11 oz |
| Product Color | Black |
| Height | 6.4" |
| Color Family | Black |
| Width | 1.6" |
| Depth | 3.6" |
| Interfaces/Ports | |
| Host Interface |
|
| General Information | |
| Brand Name | Datalogic |
| Manufacturer Website Address | http://www.datalogic.com |
| Marketing Information | The popularity of 2D bar codes has spread across all market segments of the data capture industry. Now, with more affordable pricing and virtually no drawbacks with area imaging technology, 2D bar code readers are in high demand with features such as reading from mobile phone displays or in planning ahead for future 2D codes and imaging needs. |
| Product Type | Barcode Scanner |
| Product Name | QuickScan QD2430 Handheld Barcode Scanner |
| Manufacturer | Datalogic S.p.A |
| Manufacturer Part Number | QD2430-BK |
| Product Model | QD2430 |
| Product Line | QuickScan |
| Packaged Quantity | 1 |
| Technical Information | |
| Cable Type Included | USB |
| Reading Angle (Skew) | 360° |
| Maximum Ambient Light | 86000 lux |
| Minimum Element Resolution (Code 39) | 5 mil |
| Scanning Distance | 13.78" |
| Minimum Element Resolution (DataMatrix) | 10 mil |
| Minimum Element Resolution (PDF417) | 6.6 mil |
| Barcode Symbology Supported | <p><b>1D / Linear Codes:</b></p><ul><li>Autodiscriminates all standard 1D codes including GS1 DataBar linear codes.</li></ul><p><b>2D Codes:</b></p><ul><li>Aztec Code</li><li>Aztec Mesas</li><li>Data Matrix</li><li>MaxiCode</li><li>QR Code</li><li>Micro QR Code</li><li>China Han Xin Code</li></ul><p><b>Postal Codes:</b></p><ul><li>Australian Post</li><li>British Post</li><li>Canadian Post</li><li>China Post</li><li>Japanese Post</li><li>KIX Post</li><li>Korea Post</li><li>Planet Code</li><li>Postnet</li><li>Royal Mail Code (RM4SCC)</li></ul><p><b>Stacked Codes:</b></p><ul><li>EAN/JAN Composites</li><li>GS1 DataBar Composites</li><li>GS1 DataBar Expanded Stacked</li><li>GS1 DataBar Stacked</li><li>GS1 DataBar Stacked Omnidirectional</li><li>MacroPDF</li><li>MicroPDF417</li><li>PDF417</li><li>UPC A/E Composites</li></ul> |
| Reading Angle (Pitch) | 65° |
| Scanning Capability |
|
| Scanner Range | Standard Range |
| Reading Angle (Roll) | 60° |
| Maximum Scan Resolution | 4 mil |
| Scan Pattern | Omni-directional |
| Depth of Field | <ul><li>0.2" - 5.9"@5mil - Code 39</li><li>0.2" - 13.8"@13mil - EAN/UPCA</li><li>0.4" - 5.1"@6.6mil - PDF417</li><li>0.4" - 5.1"@10mil - Data Matrix</li></ul> |
| Drop Specification | Withstands repeated drops from 1.5 m / 5.0 ft onto a concrete surface. |
| Motion Tolerance | 25 in/s |
| Image Sensor Type | Imager |
| Connectivity Technology | Cable |
| Minimum Print Contrast | 25% |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
