Dynatron 271978 Fan J10 2u Active Heatsink With Heat Pipes Embedded Brown Box

This item is brand-new, factory sealed.

J10
Recommend for AMD Genoa Processor Family, Socket SP5, Active Cooler for 2U Server Up, 5 Heatpipes with Aluminum Fin Base and Aluminum Fin Stack, Support CPU Power up to 320 Watts Heat Dissipation.CPU Support
AMDCPU Socket
Genoa, Socket SP5Solution
2U Server and UpMaterial
5 Heatpipes with Aluminum Fin Base and Aluminum Fin StackFan Dimension
60 x 60 x 25 mmSpeed
At Duty Cycle 0-20%: 2300 +/- 200 RPM
At Duty Cycle 50%: 5400 +/- 10% RPM
At Duty Cycle 100%: 11000 +/- 10% RPMRated Voltage
12VBearing
Double BallPower
At Duty Cycle 0-20%: 0.84 W
At Duty Cycle 50%: 2.76 W
At Duty Cycle 100%: 18.0 WAir Flow
At Duty Cycle 0-20%: 11.91 CFM
At Duty Cycle 50%: 28.38 CFM
At Duty Cycle 100%: 58.31 CFMNoise Level
At Duty Cycle 0-20%: 25.8 dBA
At Duty Cycle 50%: 44.4 dBA
At Duty Cycle 100%: 59.8 dBAAir Pressure
At Duty Cycle 0-20%: 1.48 mm-H2O
At Duty Cycle 50%: 7.54 mm-H2O
At Duty Cycle 100%: 28.8 mm-H2OLead Wire Pin Out
Pin Number 1-Black(-)
Pin Number 2- Yellow(+)
Pin Number 3- Green(Tachometer/ Signal Output)
Pin Number 4- Blue (PWM)Thermal Grease
Shin-Etsu 7762 Pre-printedItem Dimension (L"xW"xH")
6 x 5 x 4

Weight
1.4 lbs

Warranty Information
1 year
