Eaton
Eaton Universal-Input Basic PDU G4, 208V and 415/240V, 42 Outlets, Input Cable Sold Separately, End-Entry Input, 72-Inch 0U Vertical (evbagu23x-e)
- SKU:
- 21082568
- MPN:
- evbagu23x-e
- Availability:
- Out of stock
- Stock Update:
- 10/07/2026 04:05:18 PM PST
- Stock Update:
- 10/07/2026 04:05:18 PM PST
Description
This item is brand-new, factory sealed.
Features | 17 Removable Power Cables with 15 Different Plugs Support Universal Input
This universal input PDU (UPDU) G4 is designed to meet your most diverse rack-power needs. Equipped with 42 outlets, the EVBAGU23X-E accommodates power needs ranging from 5kVA single-phase to 23kVA three-phase. Pair the UPDU with any one of 17 removable power cables with 15 different plug options (all sold separately). This UPDU alleviates the cost and complexity of mixing and matching different PDUs for different installations. It also ensures you won't outgrow your PDU as your power needs evolve.
42 Outlets Give You Plenty of Power Options
The EVBAGU23X-E features 24 C13 outlets, which accept C14 connectors, and 18 high-retention C39 combo outlets, which accept both C14 and C20 connectors, adding flexibility to deployments and reducing the quantity of PDUs you will need to purchase and install.
Convenient Box-to-Rack Installation
This UPDU G4 features toolless mounting buttons that allow front- or side-facing rack installation, depending on your rack's layout and your power needs. Choose from a collection of 17 interchangeable AC input cables and 15 plug options (all power cables sold separately) that support a wide variety of voltages and capacities. Low-profile circuit breakers are flush with the lightweight aluminum chassis, and its narrow two-inch width saves space within the rack for revenue-generating equipment.
Package Contents:
- G4 EVBAGU23X-E 42-Outlets PDU
- Mounting Buttons
Features
- G4 EVBAGU23X-E 42-Outlets PDU
- Mounting Buttons
Certifications & Standards:
- ICES (Canada)
- UL 62368-1
- cTUVus
- CE (Europe)
- FCC Part 15 Class A (USA)
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Country of Origin:
Philippines
Specs
| Power Description | |
| Input Frequency | 60 Hz |
| Power Rating (VA) | 23 kVA |
| Power Rating (Watt) | 23 kW |
| Input Voltage Range |
|
| Input Voltage |
|
| Circuit Breaker | Yes |
| Output Voltage |
|
| Input Current | 63 A |
| Physical Characteristics | |
| Form Factor | Vertical |
| Weight (Approximate) | 13.70 lb |
| Product Color | Black |
| Mount Type |
|
| Height | 64.4" |
| Color Family | Black |
| Mounting Orientation | Vertical |
| Width | 2.1" |
| Rack Height | 0U |
| Depth | 2.1" |
| Warranty | |
| Limited Warranty | 3 Year |
| General Information | |
| Brand Name | Eaton |
| Manufacturer Website Address | http://www.eaton.com |
| Marketing Information | Features | 17 Removable Power Cables with 15 Different Plugs Support Universal Input This universal input PDU (UPDU) G4 is designed to meet your most diverse rack-power needs. Equipped with 42 outlets, the EVBAGU23X-E accommodates power needs ranging from 5kVA single-phase to 23kVA three-phase. Pair the UPDU with any one of 17 removable power cables with 15 different plug options (all sold separately). This UPDU alleviates the cost and complexity of mixing and matching different PDUs for different installations. It also ensures you won't outgrow your PDU as your power needs evolve. 42 Outlets Give You Plenty of Power Options The EVBAGU23X-E features 24 C13 outlets, which accept C14 connectors, and 18 high-retention C39 combo outlets, which accept both C14 and C20 connectors, adding flexibility to deployments and reducing the quantity of PDUs you will need to purchase and install. Convenient Box-to-Rack Installation This UPDU G4 features toolless mounting buttons that allow front- or side-facing rack installation, depending on your rack's layout and your power needs. Choose from a collection of 17 interchangeable AC input cables and 15 plug options (all power cables sold separately) that support a wide variety of voltages and capacities. Low-profile circuit breakers are flush with the lightweight aluminum chassis, and its narrow two-inch width saves space within the rack for revenue-generating equipment. |
| Product Type | PDU |
| Product Name | G4 EVBAGU23X-E 42-Outlets PDU |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | EVBAGU23X-E |
| Product Model | EVBAGU23X-E |
| Product Series | G4 |
| Technical Information | |
| Load Capacity (Watt) | 23 kW |
| Receptacle Type |
|
| Receptacle Detail |
|
| Phase | Single Phase/Three Phase |
| Plug/Connector Type | Universal Input |
| PDU Type | Basic |
| Protection Type |
|
| Load Capacity (VA) | 23 kW |
| Environmental Conditions | |
| Maximum Storage Temperature | 149°F (65°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Storage Temperature | -13°F (-25°C) |
| Minimum Operating Temperature | 32°F (0°C) |
