Elotouch Electronics
Elotouch Electronics E329262 2794l 27in Wide Fhd Lcd Wva Mntr Open Frame Hdmi Vga Dsp Prt Vid Int
(No reviews yet)
Write a Review
- SKU:
- 21610502
- MPN:
- e329262
- Availability:
- Usually ships the same or next business day. In stock at our NJ warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 08/12/2026 02:39:24 AM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 or above | and pay only $1,006.49 each 1006.49 |
- Stock Update:
- 08/12/2026 02:39:24 AM PST
Frequently bought together:
Description
This item is brand-new, factory sealed.
The Elo 2794L 27-inch open-frame LCD touchscreen features a slim design and narrow outside dimensions due to the state-of-the-art, energy-saving LED backlight, using less electricity to operate and generating less heat. This compact display is designed for touch, with proven Elo expertise and reliability built in. The 2794L provides stable, drift-free operation with outstanding image clarity and light transmission-for accurate touch responses and vivid images. Featuring a brilliant wide viewing angle panel, the open-frame touchscreen instantly grabs and holds the users' attention for kiosks, casino and amusement, retail self-service, and industrial automation environments.Easily integrated.
The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo, long-lasting product availability can be expected as well as backwards compatibility where we can make it possible to help minimize additional enclosure costs.
Touch ready.
Available with a choice of industry-leading touch technologies, in single-, dual- or multi-touch technology, including IntelliTouch® Plus dual-touch surface acoustic wave (SAW), and our latest multi-touch TouchPro™ PCAP two-glass solution (2GS) technology has a zero-bezel that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality-both modes support single or dual latex gloves as well as cloth gloves.
Commercial-grade.
The Elo open frame touchscreen display delivers the quality and reliability Elo is known for, and is backed by our three-year standard warranty. We design, build and are responsible for the complete solution with touch integrated from the start. Using our own touchscreens combined with our software and drivers, everything is designed to work together and is tested as part of our life testing processes. All of our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF.
Other features.
- Viewing angle of 178° (h) x 178° (v), for sharp colors and graphics in both portrait and landscape modes
- Projected capacitive (PCAP) two glass solution (2GS) offers pristine optical clarity and touch durability that passes UL-60950 & IK-07 impact testing
- Display Port and VGA video interfaces
- High definition LCD display offers ultimate HD interactivity, clarity and resolution
- 10-touch TouchPro™ projected capacitive (PCAP) with two-touch Thru-glass capabilities
Package Contents:
- 2794L 27" Open Frame Touchscreen (Rev B)
- HDMI cable
- VGA Cable
- RJ45 OSD Remote
- Touch USB Cable
- User Manual CD
- Quick Install Guide
- "L" (Side Mount) Brackets and w/Screws
- EEI Label
- Japan Class-B TM info sheet
Features
Package Contents:
T?V
Yes
China
- 2794L 27" Open Frame Touchscreen (Rev B)
- HDMI cable
- VGA Cable
- RJ45 OSD Remote
- Touch USB Cable
- User Manual CD
- Quick Install Guide
- "L" (Side Mount) Brackets and w/Screws
- EEI Label
- Japan Class-B TM info sheet
Certifications & Standards:
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
China Restriction of Hazardous Substances (China RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin:
China
Specs
| Power Description | |
| Operating Power Consumption | 27 W |
| Physical Characteristics | |
| VESA Mount Compatible | Yes |
| Weight (Approximate) | 16.10 lb |
| Product Color | Black |
| Height | 14.7" |
| Color Family | Black |
| Width | 24.9" |
| Depth | 1.7" |
| Warranty | |
| Limited Warranty | 3 Year |
| Interfaces/Ports | |
| VGA | Yes |
| USB | Yes |
| DisplayPort | Yes |
| HDMI | Yes |
| Video | |
| Brightness | 300 Nit |
| Maximum Resolution | 1920 x 1080 |
| Contrast Ratio | 3,000:1 |
| Color Supported | 16.7 Million Colors |
| General Information | |
| Brand Name | Elo |
| Manufacturer Website Address | http://www.elotouch.com |
| Marketing Information | The Elo 2794L 27-inch open-frame LCD touchscreen features a slim design and narrow outside dimensions due to the state-of-the-art, energy-saving LED backlight, using less electricity to operate and generating less heat. This compact display is designed for touch, with proven Elo expertise and reliability built in. The 2794L provides stable, drift-free operation with outstanding image clarity and light transmission-for accurate touch responses and vivid images. Featuring a brilliant wide viewing angle panel, the open-frame touchscreen instantly grabs and holds the users' attention for kiosks, casino and amusement, retail self-service, and industrial automation environments. Easily integrated. The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo, long-lasting product availability can be expected as well as backwards compatibility where we can make it possible to help minimize additional enclosure costs. Touch ready. Available with a choice of industry-leading touch technologies, in single-, dual- or multi-touch technology, including IntelliTouch® Plus dual-touch surface acoustic wave (SAW), and our latest multi-touch TouchPro™ PCAP two-glass solution (2GS) technology has a zero-bezel that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality-both modes support single or dual latex gloves as well as cloth gloves. Commercial-grade. The Elo open frame touchscreen display delivers the quality and reliability Elo is known for, and is backed by our three-year standard warranty. We design, build and are responsible for the complete solution with touch integrated from the start. Using our own touchscreens combined with our software and drivers, everything is designed to work together and is tested as part of our life testing processes. All of our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF. Other features. Viewing angle of 178° (h) x 178° (v), for sharp colors and graphics in both portrait and landscape modes Projected capacitive (PCAP) two glass solution (2GS) offers pristine optical clarity and touch durability that passes UL-60950 & IK-07 impact testing Display Port and VGA video interfaces High definition LCD display offers ultimate HD interactivity, clarity and resolution 10-touch TouchPro™ projected capacitive (PCAP) with two-touch Thru-glass capabilities |
| Product Type | Open-frame LCD Touchscreen Monitor |
| Product Name | 2794L 27" Open Frame Touchscreen (Rev B) |
| Manufacturer | Elo Touch Solutions, Inc |
| Manufacturer Part Number | E329262 |
| Product Model | 2794L |
| Technical Information | |
| Viewable Screen Size | 27" |
| Response Time | 12 ms |
| Mount Type | Front Mount |
| Screen Mode | Full HD |
| Backlight Technology | LED |
| Screen Size Class | 27" |
| Aspect Ratio | 16:9 |
| Touchscreen Information | |
| Touchscreen Type | IntelliTouch Surface Wave |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
View AllClose
Elotouch Electronics E329262 2794l 27in Wide Fhd Lcd Wva Mntr Open Frame Hdmi Vga Dsp Prt Vid Int
$1,049.19
