Evga
Evga Atx12v Power Supply - Internal (100-w1-0500-kr)
(No reviews yet)
Write a Review
- SKU:
- 18055322
- MPN:
- 100-w1-0500-kr
- Availability:
- Out of stock
- Stock Update:
- 09/26/2025 01:58:58 PM PST
- Stock Update:
- 09/26/2025 01:58:58 PM PST
Description
This item is brand-new, factory sealed.
Specifications
- Mfr Part Number: 100-W1-0500-KR
- Features:
- Heavy-duty Protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection) and OTP (Over Temperature Protection)
- Quiet and Intelligent Auto Fan for near-silent operation
- Maximum Power: 500 W
- Input:
- Voltage: 100 ~ 240 VAC
- Current: 8 A
- Frequency Range: 50 ~ 60 Hz
- Type: ATX12V
- Efficiency: 80% Typical
- Fan: 1x 120mm Fan
- Output: +3.3V @ 24A, +5V @ 20A, +12V @ 40A, +5VSB @ 3A, -12V @ 0.3A
- Connectors: 1x 24Pin ATX Main Power Connector, 1x 8Pin EPS12V Power Connector, 2x 6+2Pin PCI-Express Connectors, 6x SATA Connectors, 3x 4pin Molex Connectors, 1x Floppy Connector
- Approvals: TUV, cUL, UL, CE, FCC, WEEE, RoHS
- Dimensions (WxLxH): 150.0 x 140.0 x 85.0 mm
- Weight: 4.0 lbs
Features
Country of Origin:
China
China
Specs
| Power Description | |
| Number of +12V Rails | 1 |
| Output Power | 500 W |
| Output Current | 40 A |
| Output Voltage Detail | 12 V DC @ 40 A |
| Output Voltage | 12 V DC |
| Physical Characteristics | |
| Form Factor | Internal |
| Weight (Approximate) | 4 lb |
| Length | 5.5" |
| Product Color | Black |
| Height | 3.3" |
| Width | 5.9" |
| Warranty | |
| Limited Warranty | 3 Year |
| Interfaces/Ports | |
| Receptacles | 2 |
| General Information | |
| Brand Name | EVGA |
| Manufacturer Website Address | http://www.evga.com |
| Marketing Information | When building on a budget, the EVGA 500W 80 PLUS is a great choice at a low cost. Supporting 40A on a single +12V rail provides more options without having to reduce your component requirements. Save space with the 500W's compact design, well-placed power switch and fully sleeved cables. The 500W offers the connections and protections needed for basic system builds. With a standard 3 year warranty and ultra quiet fan design the 500W will be a great asset for your next build on a budget. |
| Product Type | Power Supply |
| Product Name | ATX12V Power Supply |
| Manufacturer | EVGA Corporation |
| Manufacturer Part Number | 100W10500KR |
| Technical Information | |
| Specification Compliance | ATX12V |
