Evga
EVGA SuperNOVA 850GM 850W Power Supply (123GM0850X1)
(No reviews yet)
Write a Review
- SKU:
- 18047883
- MPN:
- 123-gm-0850-x1
- Availability:
- Usually ships the same or next business day. In stock at our PA warehouse.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 05/18/2024 07:01:29 PM PST
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 2 - 3 | and pay only $156.14 each 156.14 |
| Buy 4 - 7 | and pay only $153.51 each 153.51 |
| Buy 8 or above | and pay only $150.36 each 150.36 |
- Stock Update:
- 05/18/2024 07:01:29 PM PST
Description
This item is brand-new, factory sealed.
Specifications
- Mfr Part Number: 123-GM-0850-X1
- Features:
- 100% Japanese Capacitors ensure long-term reliability
- 80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads
- Fully Modular to reduce clutter and improve airflow
- Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)
- Fluid Dynamic Bearing Fan for ultra-quiet operation and increased lifespan
- SFX-Standard Form Factor packs large power into a small space for compatibility with mITX cases and compact gaming systems
- Auto ECO Mode to ensure silent operation under low to medium loads with no configuration necessary
- Active Power Factor Correction
- Unbeatable EVGA 10 Year Warranty and unparalleled EVGA Customer Support
- Maximum Power:850W
- Input:
- Voltage: 100-240V
- Current: 12-6A
- Frequency Range: 60/50Hz
- Efficiency: 90% (115VAC) or Higher Typical
- Output:+3.3V @ 20A,+5V @ 20A, +12V @ 70.8A, -12V @ 0.3A, +5VSB @ 2.5A
- Connectors:
- ?1x 24pin ATX Main Connector
- 2x 8pin (4+4) EPS (CPU) Connectors
- 4x 8(6+2)pin PCI-Express Connectors
- 6x SATA Connectors
- 4x Four-Pin Peripheral Connectors
- 1x Floppy Connector
- Cable Lenth:
- ATX Cable:1x 300mm (m)
- EPS Cable:2x 400mm (m)
- PCIe Cable:1x 400mm, 510mm (m) / 1x 510mm, 620mm (m)
- SATA Cable:2x 300mm, 410mm, 520mm (m)
- Four-Pin Peripheral Cable:1x 300mm, 410mm, 520mm, 630mm (m)
- Floppy Adapter:1x 100mm (m)
- AC Power:1x 1500mm (m)
- Full Modular Cable Type
- Approvals:
- TUV, CB, CE, FCC, RCM, cTUVus, CCC, WEEE, RoHS
- Compliance with ErP Lot 3 2014 Requirement
- Fan Size / Bearing:92mm Fluid Dynamic Bearing
- Operating Temperature:0 to 40 C
- Japanese Capacitors:100%
- ECO Mode:Auto
- MTBF:100,000 Hours
- Size:63mm (H) x 125mm (W) x 100mm (L)
- Net Weight:4.2 lbs
- Warranty:10 Years
Package Contents:
- SuperNOVA 850GM 850W Power Supply
- SFX to ATX Bracket Adapter
Features
Package Contents:
Yes
Taiwan
- SuperNOVA 850GM 850W Power Supply
- SFX to ATX Bracket Adapter
Environmentally Friendly:
Yes
Country of Origin:
Taiwan
Specs
| Power Description | |
| Number of +12V Rails | 1 |
| Output Power | 850 W |
| Output Current |
|
| Input Voltage |
|
| Output Voltage Detail |
|
| Output Voltage |
|
| Physical Characteristics | |
| Form Factor |
|
| Height | 2.5" |
| Width | 4.9" |
| Warranty | |
| Limited Warranty | 10 Year |
| General Information | |
| Brand Name | EVGA |
| Manufacturer Website Address | http://www.evga.com |
| Product Type | Power Supply |
| Product Name | SuperNOVA 850GM 850W Power Supply |
| Manufacturer | EVGA Corporation |
| Manufacturer Part Number | 123GM0850X1 |
| Product Model | 850GM |
| Product Series | GM |
| Product Line | SuperNOVA |
| Technical Information | |
| Specification Compliance | ATX12V/EPS12V |
| Efficiency | 92% |
| Number of Fans | 1 |
| Modular | Yes |
Warranty Information
All Items are Brand New, Factory Sealed and come with a standard warranty. [Read our policies]
View AllClose
EVGA SuperNOVA 850GM 850W Power Supply (123GM0850X1)
$160.62
